Page 1: User Manual
GCR2000xx User Manual User Manual GCR2000xx 10/100/1000Mbps to 1000Base-XX Fibre Optic Media Converter Version 1.1 September 2010 Alloy Computer Products Pty Ltd Copyright ©2010... - Page 2 A EN60555-3 IEC1000-4-2(1995) 4K V CD, 8KV, AD IEC1000-4-3(1995) 3V/m IEC1000-4-4(1995) 1KV – (power line), 0.5KV – (signal line) Australian C-Tick Compliance. This equipment is compliant with the required Australian C-Tick standards Alloy Computer Products Pty Ltd Copyright ©2010...
-
Page 3: Model Description
Multimode, Single Mode, WDM and CWDM Connectivity to your media converter. The GCR2000xx can be used as a standalone unit or as a slide-in module for the DCR12xx 19" converter rack (up to 12 units) for use at a central wiring closet. The GCR2000 Series... - Page 4 This Users Manual CD-ROM Please notify your supplier immediately if any of the aforementioned items are missing or damaged. Fig. 1.1 Front Panel of GCR2000SC Fig. 1.2 Front Panel of GCR2000SFP Fig. 2 Rear Panel Alloy Computer Products Pty Ltd Copyright ©2010...
-
Page 5: Installation
1550nm Single-Mode 20Km RX (Receive) 1310nm Note: The 1310nm and 1550nm models must be installed in pairs. i.e. install 1310nm model at one end of the fibre run and 1550nm model at the other end. Alloy Computer Products Pty Ltd Copyright ©2010... -
Page 6: Link Fault Pass Through
Remote GbE Fibre Switch Station Switch Fibre Cable Fig. 6 Normal status via LFP converter Remote GbE Fibre Switch Station Switch Fibre Cable Fig. 7 The status as TP Cable A is broken Alloy Computer Products Pty Ltd Copyright ©2010... -
Page 7: Led Description
Switch 1 – 2 LFP LFP Enabled (Default) or Disabled Note: When set to Cut Through Mode jumbo frame size supports up to 9216Bytes max. In Normal mode maximum frame size is 2048. Alloy Computer Products Pty Ltd Copyright ©2010... -
Page 8: Cable Limitations
(Converter DC Current Consumption: 2A when operation at full load) Fig. 3 DC+5V Input Jack and Dimension Keep the AC-DC adapter as spare parts when Media Converter is installed in a 19-inch Media Converter Rack. Alloy Computer Products Pty Ltd Copyright ©2010... -
Page 9: Technical Specifications
• Data Transfer Rate: 1000Mbps / 1,488,000 PPS 100Mbps / 148,800 PPS 10Mbps / 14,880 PPS • Power Requirement: 1A@+5VDC • Ambient Temperature: 0° to 50°C • Humidity: 5% to 90% • Dimensions: 26.2(H) × 70.3(W) × 94(D) mm Alloy Computer Products Pty Ltd Copyright ©2010...
