Page 1: User Manual
FCR200xx User Manual User Manual FCR200xx Fast Ethernet Fibre Optic Media Converter with Advanced LFP Version 1.1 January 2010 Alloy Computer Products Pty Ltd Copyright ©2008... - Page 2 A EN60555-3 IEC1000-4-2(1995) 4K V CD, 8KV, AD IEC1000-4-3(1995) 3V/m IEC1000-4-4(1995) 1KV – (power line), 0.5KV – (signal line) Australian C-Tick Compliance. This equipment is compliant with the required Australian C-Tick standards Alloy Computer Products Pty Ltd Copyright ©2008...
-
Page 3: Model Description
Before you start installing your equipment, verify that the package contains the following: • The FCR200xx Fast Ethernet Media Converter • DC Power Supply • This Users Manual CD-ROM Please notify your supplier immediately if any of the aforementioned items are missing or damaged. Alloy Computer Products Pty Ltd Copyright ©2008... -
Page 4: Installation
10/100 TP port supports AUTO MDI-X sensing. Default: 100FDX Fibre Port "100FDX"/"100HDX" setting, see Fig. 13 S1—Bit 5 Fig. 1 View of the LFP Bridge Media Converter 100FX Fibre TP-to-100FX Network Converter 10/100Base-TX Network Fig. 2 Basic Network Connection Alloy Computer Products Pty Ltd Copyright ©2008... - Page 5 Fig. 3 Bridge Media Converter Front Panel Fig. 4 Bridge Media Converter Side Panel Fig. 5 Bridge Media Converter Rear Panel and Power Select Button 5VDC 5VDC Slide Switch Slide Switch Fig. 6-1 Fig. 6-2 Alloy Computer Products Pty Ltd Copyright ©2008...
- Page 6 The 1310nm and 1550nm models must be installed in pairs, i.e., install 1310nm model at one end and 1550nm model at the other one. FX TP /ACT /COL Bridge Media Converter 10/100Base-TX to 100Base-FX Single Fiber Fig. 7 WDM Single Fibre Converter Front Panel Alloy Computer Products Pty Ltd Copyright ©2008...
- Page 7 Note: LFP will only function if both devices support this feature. LFP will not function on this media converter if it is connected to a network switch that does not support the LFP Function. In most cases these will need to be used in pairs. Alloy Computer Products Pty Ltd Copyright ©2008...
-
Page 8: Led Description
(Converter DC Current Consumption: 2A when operation at full load) Fig. 11 DC+5V Input Jack and Dimension Keep the AC-DC adapter as spare parts when Media Converter is installed in a 19-inch Media Converter Rack. Alloy Computer Products Pty Ltd Copyright ©2008... -
Page 9: Dip Switches
FDX or HDX when TP at Force S1-4 LFP LFP enabled(default) or disabled S1-5 Fibre port duplex: 100FDX(default) or 100HDX Note: 1. S1-2 and S1-3 will take effect only when S1-1 is set at TP-FORCE. Alloy Computer Products Pty Ltd Copyright ©2008... -
Page 10: Technical Specifications
Backpressure flow control for half-duplex • Power Requirement: 1A@+5VDC from AC-DC Adapter 0.5A@+5VDC from USB port • Ambient Temperature: 0° to 50°C • Humidity: 5% to 90% • 26.2(H) × 70.3(W) × 94(D) mm Dimensions: Alloy Computer Products Pty Ltd Copyright ©2008...
