- Page 1 Sprint Series Line-Interactive Uninterruptible Power Supply USER MANUAL...
- Page 3 Introduction & Important Safety Instructions Dear Customer, Thank you for selecting a Marathon Power Uninterruptible Power Supply (UPS). You can rest assured that you have purchased a product consistent with our reputation for quality and reliability. It will provide you with years of protection against disruptive and costly powerdisturbances. As future needs arise, we hope you will consider other products of ours.
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS 1. WARNING (Save These Instructions): This Manual Contains Important Instructions that should be followed during Installation and Maintenance of the UPS and Batteries. 2. The equipment can be operated by any individual. No previous experience is required. 3. -
Page 5: Table Of Contents
Table of Contents Section Page 1. Overview ..............1 2. -
Page 6: Overview
1. Overview The Sprint series is made up of a broad range of line-interactive models in both Tower and 19" Rack-Mount configurations. Line interactivity implies Automatic Voltage Regulation which uses buck / boost circuitry to correct for input voltage variations ranging from 75% to 125% of nominal, without the need to transfer to battery, while maintaining a constant output to the load. -
Page 7: Functionality
3. Functionality – Front Views 425VA / 525VA / 625VA TOWER 800VA / 1000VA / 1200VA / 1500VA / 2200VA TOWER 3.4a 3.4a 3.4a ON/TEST 1500VA / 2200VA RACK-MOUNT (not to scale) 3.4b 3.1 3.9 3.2 3.3 AC NORMAL SILENCE SWITCH BATTERY FAULT BUZZER... - Page 8 3.7 OVERLOAD Indicator (19" Rack-Mount models - 1500VA / 2200VA) Allows the UPS to be powered down & serviced without interrupting power to thte connected equipment. 3.8 “BUCK" (AVR) Indicator This LED illuminates when the UPS is correcting a voltage swell or over-voltage condition. 3.9 “BOOST"...
-
Page 9: Installation
3.12 TELEPHONE / MODEM SURGE PROTECTION Sockets Surge protection for telephone and modem lines. 3.13 AC SURGE PROTECTION Socket (s) (Some models only) Surge protection for an additional load. (This outlet is not backed-up). 3.14 INPUT CIRCUIT BREAKER / FUSE A circuit breaker that trips when the connected loads exceed the protected receptacle’s capacity or when a short circuit occurs. -
Page 10: Operation
4.7 Site Wiring Fault Indicator Inspection (Applicable models only) After connecting the loads and the UPS, check the site wiring fault indicator on the rear panel. See section 3 for location of the indicator on the rear panel. It will illuminate if the UPS is connected to an improperly wired AC power outlet. -
Page 11: Alarms
If the UPS fails the self-test, it immediately returns to on-line operation and the “REPLACE BATTERY” LED will illuminate. The loads are not affected. Recharge the battery overnight and per- form the self-test again. If the “REPLACE BATTERY” LED is still illuminated, call tech support for battery replacement instructions. -
Page 12: Software Options
7. Software Options 7.1 Power Monitoring Software NOTE: Please refer to the back of the software CD holder for installation instructions. For operational instrucions, install the software, launch the program then click HELP in the upper left corner of the software application screen. The software is applied via the standard RS-232 or USB interface to perform monitoring functions, as well as to implement an orderly shutdown of a computer in the event of a continuous power failure. -
Page 13: Computer Interface Port
• Remove watches, rings, and other jewelry. • Use tools with insulated handles. Marathon Power strongly recommends that the user contact tech support for assistance with battery replacement. To change the battery in the 425VA, 525VA & 625VA Tower units: 1. - Page 14 8. Place the new battery in the same position / direction as before and reconnect the wires. Connect the RED wire to Positive (+) and the BLACK wire to Negative (-). 9. Follow the reverse of steps above to re-assemble the UPS. 10.
-
Page 15: Storage
11. Storage 11.1 Storage Conditions Store the UPS covered, upright and in a cool, dry location, with its battery fully charged. Before storing, charge the UPS for at least 4 hours. Remove any accessories from the unit slot and disconnect any cables connected to the computer interface port to avoid draining the battery. 11.2 Extended Storage During extended storage in environments where the ambient temperature is +5 to +86°F (-15 to +30°C ), charge the UPS’s battery every 6 months. -
Page 16: Specifications
13. Specifications Tower Models GENERAL 425VA, 525 VA, 625 VA, 800VA, 1000 VA, 1200 VA, 1500VA, 2200VA Rated Capacity: Line-interactive topology with simulated sinewave output on battery Technology: INPUT Phase: Single phase plus ground Input Voltages: 110V, 115V, 120V or 220V, 230V, 240V Input Voltage Range: ±... - Page 17 13. Specifications (Cont'd) All Models ALARMS AND INDICATORS Battery Backup: Slow beeping tone (approx. 0.25Hz) Battery Low: Rapid beeping tone (approx. 1.00Hz) Overload: Continuous tone Front Panel Display: LED's LED Display Parameters: On Line (AC normal), On Battery (AC failure), Battery Fault (425VA ~ 625VA models) LED Display Parameters: On Line (AC normal), On Battery (AC failure), Battery Fault, AVR Boost, AVR Buck...
-
Page 18: Product Warranties
13. Specifications (Cont'd) Tower Models Capacity 425VA / 255 W 525VA / 315 W 625VA / 375 W 800VA / 480 W Removable IEC cord Input Connection Fixed power cord Output Connection 6 x NEMA 5-15R (3 backed up and 3 surge only) 5 x NEMA 5-15R Battery Type &... - Page 19 Take the following stps to file a warranty claim: Contact us at Marathon Power, Inc., Attn: Returns, 2538 E. 54th Street, Huntington Park, California 90255 or call (310) 689-2328 within 30 days of the occurrence. Be prepared to provide detailed information about the event, any damage, the UPS model number, purchase date and location.
- Page 20 Copyright Marathon Power, Inc. 2007 www.marathon-power.com sprintuserman2007rev2...
