- Page 1 DIN Rail Uninterruptible Power System User Manual for Models: SDRS-0300-H1 • SDRS-0300-H2 SDRS-0500-H1 • SDRS-0500-H2 300W - 500W...
-
Page 3: Table Of Contents
Table of Contents Section Page Safety Instructions......................4 Introduction........................4 1. Presentation.........................5 2. Installation........................6 3. Operation........................7 4. Alarm..........................7 5. Software........................8 6. Troubleshooting......................9 7. Specifications......................10 8. Warranty........................11... -
Page 4: Safety Instructions
Important Safety Instructions IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS T his Manual Contains Important Instructions that should be followed during Installation and maintenance of the UPS and Batteries. WARNING: Intended for installation in a controlled environment. C AUTION: Do not dispose of batteries in a fire, as they may explode. CAUTION: Do not open or damage the battery, electrolyte may be released which is harmful to the skin and eyes. -
Page 5: Presentation
1. Presentation Front Panel 1. ON/OFF/TEST/SILENCE Button: a. Press the button and hold for more than one second to turn the UPS ON. b. Press the button for less than one second to activate the self-testing (AC MODE), c. Press the button for less than one second to silence the UPS audible alarm (BATTERY MODE), d. -
Page 6: Installation
Bottom Panel 9. AUX DC OUTPUT: Output terminal provides DC power source to the relay card (Optional Dry contact relay box). 10. RS232 communication port: DB-9 connector 11. TEL Surge Protection: Data line surge protection for telephones 2. Installation 2.1 Inspection: Upon receiving the UPS, inspect it. The packaging is recyclable. Save it for reuse or dispose properly. -
Page 7: Operation
3. Operation 3.1 Output Connector: The output connector will provide protection from surges and power failures to the critical loads. 3.2 Switch ON: After connecting the UPS to the utility power, press the ON button until the first beep stops, then release the button immediately. 3.3 Switch OFF: To switch OFF the UPS, press and hold the ON/OFF button until the “AC MODE”... -
Page 8: Software
UPS-MON displays all the diagnostic symptoms on the monitor, such as Voltage, Frequency, Battery level and so on. The software is available for Windows XP, 7,8, 10, Server-2000, 2003, 2008, 2012 and Linux. Call Marathon Power technical support for assistance on OS. -
Page 9: Troubleshooting
6. Appendix A - Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION If UPS does ON/OFF/TEST/SILENCE button not Press the ON/OFF/TEST/SILENCE button not turn ON pushed or push-time too short more than 1 second (OR) Battery voltage less than 10V Recharge the UPS for at least 6 hours LED does not Illuminate PCB failure... -
Page 10: Specifications
CSA C22.2#107.3: 2014 Ed.3 + U1 Approvals Recognized for UL508A Industrial Control Panels CE (230V Models) CAUTION: Risk of Electric Shock – UPS equipment outputs remain live with main disconnect in off position. Part Numbers: 120V: SDRS-0300-H1, SDRS-0500-H1 230V: SDRS-0300-H2, SDRS-0500-H2... -
Page 11: Warranty
Marathon Power warrants to the original purchaser, and not for the benefit of anyone else that this product at the time of its sale by Marathon Power is free of defects in materials and workmanship for three (3) years (batteries for 2 years within the USA, Canada and Mexico, otherwise 1 year) from the original purchase date. - Page 12 Marathon Power, Inc. 2020 2538 E. 54th Street Huntington Park, CA 90255 Office: 310-689-2328 Fax: 310-689-2329 support@marathon-power.com www.marathon-power.com © Marathon Power Inc. 2020 MP_DIN Rail User Manual_Jul_2020...
