Athlon Series True On Line, Double Conversion Uninterruptible Power Supply USER MANUAL...
Page 3
Introduction & Important Safety Instructions Dear Customer, Thank you for selecting a Marathon Power Uninterruptible Power Supply (UPS). You can rest assured that you have purchased a product consistent with our reputation for quality and reliability. It will provide you with years of protection against disruptive and costly powerdisturbances. As future needs arise, we hope you will consider other products of ours.
1. Overview For use in the most critical applications, these models are true on-line, double conversion designs that provide a continuous, true sine-wave output with less than 3% total harmonic distortion (THD). They allow for a wide input voltage range of +-27% and also feature power factor correction and dual microprocessors for control of all functions.
EMC Statements FCC Part 15 NOTICE: Pursuant to section 15 of the FCC rules, this product has been tested and thereby complies with the conditions of a Class B (700-2000VA) and Class A (3000VA) digital device, which have been established for offering sufficient protection against dangerous interference for installation in a residential area.
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS 1. This Manual Contains Important Instructions that should be followed during Installation and Maintenance of the UPS and Batteries. 2. The equipment can be operated by any individual. No previous experience is required. 3. CAUTION (UPS with Internal Batteries): Risk of electric shock - Hazardous live parts inside this unit are energized from the battery supply even when the input AC power is disconnected.
3. Functionality – Front Views 3.01 (not to scale) 3.02 3.03 LINE BY PASS LINE BACKUP BY PASS FAULT BACKUP BATT FAULT 20 % 40 % 60 % 80 % 100 % LOAD BATT SELECT 20 % 40 % 60 % 80 % 100 % 20 %...
Page 9
3.07 BACKUP: Indicates unit is operating in backup mode during a power disturbance or loss of power. 3.08 FAULT: Indicates an internal electronic fault. 3.09 BATTERY LEVEL BAR GRAPH: This graph shows the charge/energy level of the battery in 20% increments. 3.10 LOAD LEVEL BAR GRAPH: This graph shows how much of the units available capacity is being utilized in 20% increments.
Page 10
3. Functionality – Rear Views 3.19 3.21 3.21 3.14 3.15 3.16 3.17 3.18 700 / 1000 / 1500VA TOWER MODELS 3.18 NOTES: 1. Illustrations not to scale 2. All illustrations shown with NEMA receptacles. IEC and European style receptacles are available for all models. 3.20 3.
“SNMP manageable”, providing local and remote real time UPS and system status information for networks and over the internet. NOTE: For more information on an SNMP kit, please contact Marathon Power sales or technical support 3.15 AC OUTPUT POWER RECEPTACLES 3.16 OUTPUT CIRCUIT BREAKERS / FUSES...
4.3 Power Source Connection 4.31 Cord connected models Connect the AC power cord to a properly wired and grounded outlet to energize the UPS. 4.32 Hardwired models The terminal block is used to “hardwire” the UPS, thus allowing connection of input/output wiring. Use #8 AWG wire (Twisted wire cable) for possible 3/4”...
Page 13
Vertical and Wall-Mount Installation The following diagrams illustrate how to install or mount the UPS (and battery packs when applicable) in either vertical or wall-mount applications: Vertical Installation Wall-mount Installation...
Page 14
19” Rack-Mount Installation The following diagrams illustrate how to install or mount the UPS (and battery packs when applicable) in 19” rack-mount applications: Lower Slide Rail Installation Rear Bracket Installation...
Page 15
Unit Stack Installation The following diagrams illustrate how to stack the units (and battery packs when applicable): Stacking Units...
5. Operation 5.1 Turn-ON With the UPS connected to an A/C power source, press the ON/TEST button more than 2 seconds to energize the UPS. It will perform a self-test each time it is switched ON. Where applicable verify the circuit breaker on rear panel is ON.
5.8 Manual Bypass Mode The UPS can be 'forced' into manual bypass by simultaneously pressing the ON and OFF buttons for 3 seconds. The UPS will then be in bypass mode and the load will be connected directly to the source. The Bypass icon on the LCD display will be illuminated.
8. Care & Maintenance 1. Keep the unit clean and vacuum the ventilation intake periodically. 2. Wipe with a soft, damp cloth. 3. Check for loose and/or bad connections monthly. 4. Never leave the unit on an uneven surface. 5. Position the unit to allow at least 1/2” (1.3 cm) clearance between the rear panel and the wall. 6.
• Use tools with insulated handles. Marathon Power recommends that you contact our tech support for assistance with battery replacement. To change the batteries for the Tower units: 1. Unplug the UPS unit from the AC power source and disconnect all connected equipment.
UPS‘s battery every 6 months. During extended storage in environments where the ambient temperature is +86 to +113°F (+30 to +45°C), charge the UPS‘s battery every 3 months. 12. External Battery Pack Installation ATHLON SERIES RACK-MOUNT UPS + ONE RACK-MOUNT BATTERY PACK 4. Installation 12.1 Connecting The EBP's and the UPS The EBP comes with a suitably rated interconnecting cable with a polarized plug on each end.
13.Troubleshooting Problem Possible Cause Corrective Action Unit will not turn ON ON/TEST button not pushed or P ress the ON/TEST button for more than not pushed long enough 2 seconds to power up the UPS & load Remove connected loads from the UPS Circuit breaker has tripped by unplugging equipment and resetting the circuit breaker...
14. Specifications 13.1 120V Models GENERAL Rated Capacity: 700VA, 1000 VA, 1500 VA, 2000 VA, 3000 VA with a power factor of 0.7 Technology: True on-line, double conversion topology with integral automatic bypass INPUT Phase: Single phase plus ground Input Voltage Range: 100V: 76-130V 110V: 80-138V 115V: 83.5-140V 120V: 87-140V Input Power factor: 0.98...
Page 23
13.3 All Models ALARMS AND INDICATORS Battery Backup: Slow beeping tone (approx. 0.25Hz) Battery Low: Rapid beeping tone (approx. 1.00Hz) Overload: Continuous Tone Front Panel Display: High Intensity LCD panel Display Parameters: Input voltage, Output voltage, Input Frequency, Output Frequency, Load (%), Internal Temperature (°C) Communication (std): RS-232 bi-directional communication port and solid state signaling...
Page 24
120V Tower Models Capacity 700VA / 490 W 1000VA / 700W 1500VA / 1050W 2000VA / 1400W 3000VA / 2100W Hardwire Terminals Input Connection Fixed power cord Output Connection 4 x NEMA 5-15R 8 x NEMA 5-15R + Hardwire Terminals Battery Type &...
Page 25
230V Tower Models Capacity 700VA / 490 W 1000VA / 700W 1500VA / 1050W 2000VA / 1400W 3000VA / 2100W Input Connection IEC 320 (10A) IEC 320 (16A) 8 x IEC 320 (10A) 4 x IEC 320 (10A) Output Connection 8 x NEMA 5-15R 4 x NEMA 5-15R Options...
Take the following stps to file a warranty claim: Contact us at Marathon Power, Inc., Attn: Returns, 2538 E. 54th Street, Huntington Park, California 90255 or call (310) 689-2328 within 30 days of the occurrence. Be prepared to provide detailed information about the event, any damage, the UPS model number, purchase date and location.
Page 28
Copyright Marathon Power, Inc. 2007 www.marathon-power.com athlonuserman2007...
