Technical Information
PC Setup
The following should be done to set up the PC:
Using
Windows
Step
1
2
3
4
5
6
7
8
9
Page C-4
Action
Run WINDOWS
Select the PROGRAM MANAGER.
Select TERMINAL.
Select SETTINGS.
Select COMMUNICATIONS.
Select the COM PORT to use.
Select 9600 for BAUD RATE.
Select 8 for DATA BITS.
Select 2 for STOP BITS.
Select NONE for PARITY.
Select OK.
Select SETTINGS.
Select BINARY TRANSFERS.
Select KERMIT.
Select OK.
08/99
Comments
The COM PORT select should be the
same as the one that the cable from the
AH30 is connected to.
