ASCOM Smart Series AH30 Operating Manual page 111

PC Interfacing
Real Time
Press the [EXIT/PR.MENU] key twice.
•
Interfacing
Setup
continued
• Use the [
• Use the [
• Use the [EXIT/PR.MENU] key to return to the Main Menu display.
PC Setup
The following should be done to set up the PC:
Using
Windows
Step
1
2
3
4
5
6
7
8
9
Ascom Hasler Mailing Systems, ® Inc.
Set Meter Banks
PC Configuration
] key to select [Serial Port 1], press the [ENTER] key.
Baud Rate
Stop Bits
] key to select and set the following:
[Baud Rate]
[Stop Bits]
[Parity]
[Length]
Action
Run WINDOWS
Select the PROGRAM MANAGER.
Select TERMINAL.
Select SETTINGS.
Select COMMUNICATIONS.
Select the COM PORT to use.
Select 9600 for BAUD RATE.
Select 8 for DATA BITS.
Select 2 for STOP BITS.
Select NONE for PARITY.
Select OK.
Select SETTINGS.
Select BINARY TRANSFERS.
Select KERMIT.
Select OK.
9600
Two
No
8
Comments
The COM PORT select should be the
same as the one that the cable from the
AH30 is connected to.
08/99
AH30
Page 12-9
