Page 1: User Manual
PotsDOCK 9555 Installation & User Manual Suitable for the Iridium 9555 Portable Satellite Telephone Beam Communications Pty Ltd... -
Page 2: User Information
8 Anzed Court, Mulgrave, Victoria, 3170, AUSTRALIA Information furnished by BEAM Communications Pty Ltd (BEAM) is believed to be accurate and reliable. However, no responsibility is assumed by BEAM for its use, or for any infringement of patents or other rights of third parties, which may result from its use. -
Page 3: Package Contents
PotsDOCK 9555 Installation & User Manual Package Contents Check that your PotsDOCK 9555 package contains: ‰ 1 x PotsDOCK 9555 Docking Cradle ‰ 1 x AC/DC power adaptor ‰ 1 x DC power cable / lead ‰ 1 x RAM bracket ‰... -
Page 4: Table Of Contents
Vehicles Posted Facilities Aircraft For Vehicles Equipped with an Air Bag Conventions in this Manual Terminology BEAM Communications About this equipment POTSDOCK 9555 KEY FEATURES Tracking / Alert Monitoring LeoTRAK-Online Global Tracking Portal Equipment Overview: Docking & undocking your 9555 handset... - Page 5 PotsDOCK 9555 Installation & User Manual PotsDOCK 9555 Usage Docking & undocking your 9555 handset Removing the 9555 from vehicle Operation of the PotsDOCK 9555 Starting Up Charging the Iridium 9555 Handset Placing Voice Calls RJ11 POTS Phone Call – Mobile Originating RJ11 POTS Phone Call –...
-
Page 6: Safety Information
Safety Information IMPORTANT! Please read the following information carefully before installing and using the Beam PotsDOCK 9555. Failing to follow instructions may compromise the safety of the product and may result in personal injury and/or equipment damage. Please consult your supplier if you have any further questions. -
Page 7: Safety - Iridium Transceiver 9555
PotsDOCK 9555 Installation & User Manual WARNING: POTENTIALLY EXPLOSIVE ATMOSPHERES • Turn your phone OFF and DO NOT remove your battery or remove the 9555 handset from the cradle when you are in any area with a potentially explosive atmosphere. •... -
Page 8: Antenna Care
◊ Do not operate your satellite telephone when a person is within 1 foot (30 centimeters) of the antenna. A person or object within 1 foot (30 centimeters) of the antenna could impair call quality and may cause the phone to operate at a higher power level than necessary and expose that person to RF energy in excess of that established by the FCC RF Exposure Guidelines. -
Page 9: Other Medical Devices
PotsDOCK 9555 Installation & User Manual Persons with pacemakers: ◊ Should ALWAYS keep the phone more than six inches from their pacemaker when phone is turned ON ◊ Should turn the phone OFF immediately if you have any reason to suspect interference is taking place Other Medical Devices If you use any other personal medical device, consult the manufacturer... -
Page 10: Conventions In This Manual
RJ11 POTS Phone handset is hanged up (end call). Bluetooth® The Bluetooth® word, mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by Beam Communications is under license. Other trademarks and trade names are those of their respective owners. -
Page 11: Beam Communications
PotsDOCK 9555 Installation & User Manual BEAM Communications Beam Communications, a wholly owned subsidiary of World Reach Limited (WRR), listed on the Australian Stock Exchange, is a world leader in design, manufacture and distribution of specialized communications equipment for the Iridium Satellite Network. -
Page 12: About This Equipment
About this equipment POTSDOCK 9555 KEY FEATURES POTSDOCK CRADLE • Securely holds 9555 Handset • Robust design and construction • Charges 9555 handset ready for use • Integrated antenna connection • Integrated USB connectivity POTS/RJ11 • Supports standard cordless & corded telephones (5 REN) • RJ11 can be run 600m (2000 ft) from unit •... -
Page 13: Tracking / Alert Monitoring
PotsDOCK 9555 Installation & User Manual Tracking / Alert Monitoring PotsDOCK has an in-built GPS module that can provide simple tracking, monitoring and alert management in various land and sea based applications within various types of vehicles, vessels or fixed site locations. -
Page 14: Equipment Overview
Equipment Overview: EJECT Button 9555 Handset Antenna Plug RJ11 Port Mini USB Data 3-Button Panel Port Interface Iridium Antenna (TNC Female) GPS Antenna (SMA Female) Privacy Handset (4-pole, 3.5mm) Alert Loop (In/Out) Input Power (4-way microfit) -
Page 15: Docking & Undocking Your 9555 Handset
PotsDOCK 9555 Installation & User Manual Docking & undocking your 9555 handset WARNING: Ensure that the external antenna grommet at the rear of the 9555 handset is removed prior to inserting the handset into the PotsDOCK cradle. To dock the 9555 handset place the base of the 9555 handset into the seat if the PotsDOCK ensuring that the pins on the bottom of the 9555 handset line up with that on... -
Page 16: Installation Guidelines
Installation Guidelines This guide outlines the details for installing the Beam PotsDOCK 9555 in conjunction with an Iridium 9555 Portable Handset. This kit must not be used with any other device other than the Iridium 9555 Handset. ◊ The units must be protected from dirt and moisture. ◊... -
Page 17: Guidelines For Electrical Connections
PotsDOCK 9555 Installation & User Manual ◊ Keep all in-line connectors accessible. ◊ The suggested path for routing cables in vehicles without wiring troughs is alongside the drive shaft hump, under the carpet. Guidelines for Electrical Connections The System is designed to operate in negative ground 9 to 32 Volt DC electrical systems only. -
Page 18: Unpacking And Testing
Unpacking and Testing Unpack all components and assemble them on a service bench. Position the antenna several meters from the other components to avoid potential interference. Following the next steps, use the AC power adaptor or a bench power supply in place of the vehicle battery, verify that all components are functioning properly. -
Page 19: B: Powering From The "Dc Power Cable / Lead
PotsDOCK 9555 Installation & User Manual B: Powering from the “DC power cable / lead” The DC power cable / lead can be used where AC power is unavailable. This can be connected to a 9 to 32V DC power source (such as a vehicle battery). -
Page 20: Installation Procedure
Installation Procedure Installing the PotsDOCK Cradle Install the components in the following order: Mount/Install PotsDOCK cradle Install External Iridium / GPS Antenna (ordered as extra option) Install RJ11 PSTN Telephone (optional) Install external Alert Button (optional) Install Privacy Handset (ordered as extra option) Connect Power Configure Bluetooth®... -
Page 21: Cradle Mounting
PotsDOCK 9555 Installation & User Manual Cradle Mounting The PotsDOCK is supplied with a universal RAM-mount bracket that enables mounting to any flat surface (vertical or horizontal) within a vehicle or on a wall or table as required. Attached one pivot base to the rear of the PotsDOCK using the M4 screws supplied. -
Page 22: Iridium Antenna Connection
Iridium Antenna connection The Antenna connections exit from the rear of the PotsDOCK cradle, on foot-long antenna loom. Connect your Iridium antenna cable to the TNC-Female connector on the cable coming from the rear of the PotsDOCK. Iridium antenna cable (outer screen) is automatically connected to the GND (0V) of the PotsDOCK (via the... -
Page 23: Rj11 / Pots Telephone (Optional)
PotsDOCK 9555 Installation & User Manual NOTE: Antenna should only be connected to the GPS receiver when the PotsDOCK is not powered. Do not connect or disconnect the GPS Antenna when the GPS receiver is running as the receiver calibrates the noise floor on power-up only. Connecting the antenna after power-up can result in prolonged acquisition time. -
Page 24: Privacy Handset (Optional - Extra Order)
Privacy Handset (optional – extra order) The PotsDOCK provides a 4-pole 3.5mm audio socket on the rear cable loom, for connection to the Beam Privacy Handset. This provides local handset function, conveniently mounted next to the PotsDOCK cradle. The Privacy Handset Kit (purchased/ordered separately) contains a mounting bracket, space plate, and fasteners. -
Page 25: Call Test
PotsDOCK 9555 Installation & User Manual Call Test To confirm that the phone is working properly: Make a call from the analogue RJ11 Telephone and confirm opera- tion. Take the Telephone “OFFHOOK” and listen for dial tone. Dial (using the full country codes) on the RJ11 Telephone keypad. Allow up to 5 seconds for the call to be issued to the 9555 Handset, at which point the message appears on 9555: “DPL Call In Progress”. -
Page 26: Bluetooth® Data Configuration
Once paired, the PotsDOCK will automatically connect to this device every time the PotsDOCK powers up. You may repeat this process to pair more than one headset (up to 17 total devices including data) – ensure only one device is switched on during subsequent paring configuration. -
Page 27: Potsdock 9555 Usage
PotsDOCK 9555 Installation & User Manual PotsDOCK 9555 Usage Docking & undocking your 9555 handset WARNING: Ensure that the external antenna grommet at the rear of the 9555 handset is removed prior to inserting the handset into the PotsDOCK cradle. To dock the 9555 handset place the base of the 9555 handset into the seat if the PotsDOCK ensuring that the pins on the bottom of the 9555 handset line up with that on... -
Page 28: Operation Of The Potsdock 9555
Operation of the PotsDOCK 9555 Starting Up Retract the antenna on the 9555 handheld phone. Place the handset into the PotsDOCK as per the previous instructions. If using ACC system, switch the vehicle ignition to ACC or ON position; 9555 handset and PotsDOCK will automatically power up. Wait for the 9555 handset to register on the Iridium network. -
Page 29: Placing Voice Calls
PotsDOCK 9555 Installation & User Manual Due to the increased heating effects of the phone whilst it is docked and in charging mode, it is ideal for the ambient temperature to be approximately 10 degrees below this for the handset to charge the battery whilst docked. -
Page 30: A Bluetooth® Phone Call - Mobile Originating
A Bluetooth® Phone Call - Mobile Originating A Bluetooth® call can be started by using the 9555 keypad. The Bluetooth® connection to the Audio Headset is required [check the Bluetooth® LED is on, blue - half intensity]. Dial (using the full country codes) on the 9555 keypad. The message appears on 9555: “Call In Progress”. -
Page 31: Mute & Earpiece-Jack Mode
PotsDOCK 9555 Installation & User Manual Mute & Earpiece-Jack Mode Mute functionality The mute function of the PotsDOCK allows the user to mute the uplink (RJ11, Bluetooth®, or Privacy) audio to the 9555 handset whilst docked in the PotsDOCK. During a call, Press the Mute button on the face of the PotsDOCK, a LED will illuminate at the Mute button to confirm... -
Page 32: Earpiece-Jack Mode
Earpiece-Jack Mode The PotsDOCK allows a user to utilise a 2.5mm earpiece plugged into the right side of the 9555 handset. During a call, to enable Earpiece-Jack Mode, press and hold the Mute button for 1.5 seconds. The LED on the mute button will start flashing orange to indicate that the PotsDOCK is in privacy mode. -
Page 33: Activate Alert Mode
PotsDOCK 9555 Installation & User Manual Activate Alert Mode Alert mode can be activated by: Press and hold buttons together for 2 seconds. A single beep will sound. Press and hold the external panic button (optionally wired into the Alert Loop wires). Once triggered into Alert state, the Track LED turns RED. -
Page 34: Potsdock Front Panel
PotsDOCK Front Panel LOCATION BUTTON MODE LED/SOUND Out of Call: LED off. Toggle Ringer Mode Ringer choice sounds as preview. During In-Call RJ11 or LED is when MUTE. Bluetooth: Mute (single press) During In-Call RJ11 or LED flashes ORANGE. Bluetooth: Earpiece-jack (1.5 seconds press) Subsequent single press, exits Earpiece-jack Bluetooth®... -
Page 35: Data Communications
PotsDOCK 9555 Installation & User Manual Data Communications The PotsDOCK provides the convenience of accessing Iridium data services while the phone is docked in the cradle. You should consult your service provider for full details on the availability of this service with your account. -
Page 36: Usb Driver Installation
USB Driver Installation The PotsDOCK 9555 USB data port requires an interface driver to be installed on the user’s computer prior to undertaking data communication. This driver supports the following operating systems: Windows 2000, Windows XP, & Windows Vista You can download Windows driver for the PotsDOCK 9555 from http://www.beamcommunications.com/support/potsdock9555 Iridium supplies Direct Internet 2 software only for the Microsoft Windows based operating systems. -
Page 37: At Commands
PotsDOCK 9555 Installation & User Manual AT Commands When utilizing the USB data communication port the PotsDOCK must ensure that users do not enter in AT commands that could interrupt the PotsDOCK’s synchronization with the 9555 handset. Therefore the PotsDOCK will block or limit AT commands that could cause any ad- verse effects to the functional operation of the cradle. -
Page 38: Iridium 9555 Display Definitions
Iridium 9555 Display Definitions Display Status indicators and Icons The following icons will appear in your 9555 handset display to provide you with various information about the phone’s activity. Main Screen Components Menu Components... -
Page 39: Power-On Messages
PotsDOCK 9555 Installation & User Manual Power-On Messages Once your phone is powered on, you may see: MESSAGE DESCRIPTION Searching... The phone is attempting to establish communications with satellite network. Registering... Your phone is registering with the network. When the process is complete, you will see Registered. -
Page 40: Assuring Quality Of Iridium Service
Assuring Quality of Iridium Service Iridium is committed to providing subscribers around the world consist- ent, reliable, quality voice and data access all day every day. The Iridium satellite system is monitored for call performance from numerous loca- tions 24 hours a day, 7 days a week in order to achieve this. There are conditions that can compromise the quality of the service you may receive. -
Page 41: Rf Interference
PotsDOCK 9555 Installation & User Manual RF Interference All wireless devices, including satellite telephones, are susceptible to RF (radio frequency) interference from other electronic devices. This problem is more evident when numerous antennas and broadcasting devices are located within close proximity to each other. Symptoms of RF Interference Symptoms of RF interference often resemble those that arise when an Iridium phone is being operated with an obstructed view of the sky. -
Page 42: Specification Summary
Specification Summary Electrical & Environmental Specifications POWER SPECIFICATIONS Rated Input 9-32V DC, 2A max AC Power Pack 90-250V AC 50-60Hz, Output 12V 45W Average Power Current Power Consumption @ 12V Watts Standby, *handset + RJ11 90mA 1.1W Transmit, handset + RJ11 0.5A Sleep Mode 25mA 0.3W INTERFACES... - Page 43 Legal The Bluetooth® word, mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by Beam Communications is under license. Other trademarks and trade names are those of their respective owners. GPS MODULE (INTERNAL)
-
Page 44: Cradle Mounting Dimensions
Cradle Mounting Dimensions PotsDOCK Dimensions in millimeters 46.05 23.01 61.92 30.17 15.08 5.53 19.05 19.05... -
Page 45: Trouble Shooting
PotsDOCK 9555 Installation & User Manual Trouble Shooting This chapter provides information to help you troubleshoot problems you may encounter while running the PotsDOCK. No power on PotsDOCK Check power is connected to the interface unit. If applicable, check the vehicle ignition is in ACC or IGN or ON position. Ensure the Connector cable to the PotsDOCK is firmly fitted Check all the connection cables to and from the PotsDOCK. -
Page 46: For Additional Product Support
Turning the PotsDOCK OFF then back ON will clear this false triggering. For additional product support: BEAM Communications Pty Ltd 8 Anzed Court, Mulgrave Victoria, 3170, AUSTRALIA Web: www.beamcommunications.com... -
Page 47: Beam Warranty Conditions
BEAM which appear within (12) months and (24) months replacement warranty for SatDOCK, PotsDOCK, IntelliDOCK cradles ONLY, from the date of shipment by BEAM Communications to the Customer. BEAM Communications will repair or replace, at our option, any defective product,provided that our analysis and/or inspection discloses that such defects developed under normal and proper use. - Page 48 WEB: www.beamcommunications.com EMAIL: info@beamcommunications.com PHONE: +61 3 8588 4500 FAX: +61 3 9560 9055 AFRICA | ASIA | AUSTRALIA | EUROPE | MIDDLE EAST | NORTH AMERICA | SOUTH AMERICA...
