Programming System Features - Directed Electronics Viper 5904 Installation Manual

Programming System Features

The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of
the feature settings using the Control button.
1. Open a door.
2. Turn the ignition on, then off.
3. Select a Menu. Press and hold the Control button. The number of siren chirps indicates the menu num-
ber. 1 chirp indicates menu 1, 2 chirps - menu 2 and 3 chirps for menu 3.
4. When the desired menu chirps are heard, release the Control button.
5. Select a Feature. Press and release the Control button the number of times corresponding to the feature
you wish to change. Then press and hold one more time to select the features.
6. Program the Feature. While holding the Control button, you can program the feature using the remote
control.
For features with only two options;
For features with more than two options;
descending order.
Note: Pressing button resets the feature to the factory default.
AUX
Once a feature is programmed:
• Other features can be programmed within the same menu
• Another menu can be selected
• The learn routine can be exited if programming is complete
To access another feature in the same menu:
1. Press and release the Control button the number of times necessary to advance from the feature you just
programmed to the next one you want to program.
2. Then press the Control button once more and hold it.
To select another menu:
1. Press and hold the Control button.
2. After 3 seconds, the unit advances to the next menu and the siren chirps, indicating which menu has been
accessed.
The learn routine exits if any of the following occurs:
• The open door is closed
• The ignition is turned On
• There is no activity for 30 seconds
• The Control button is pressed too many times
© 2011 Directed Electronics. All rights reserved.
= option 1 while = option 2.
selects the options in ascending order, while
AUX
AUX
AUX
selects them in
AUX
11
