4-Pin Satellite Harness

Blue (-) Status Output
When the remote start goes active this wire supplies a (-) 200mA output. It can be used to activate an immo-
bilizer bypass or key sense.
(-) Accessory Output
This output supplies (-) 200mA output to activate additional accessories, you must use a relay inline.
(-) 2nd Starter Output
This output supplies (-) 200mA output to activate additional starters, you must use a relay inline.
(-) Ignition Output
This output supplies (-) 200mA output to activate additional ignitions, you must use a relay inline.
16
