INCLUDES:
•
Wheeled Carrying case
•
New S805A/SW805A Multimedia Stereo Amplifier
•
Professional Cardioid Microphone
•
Gooseneck Mic holder with Tripod floor stand
•
Two Speakers with Tripod Stands
SET UP:
INSTALL POWER SUPPLY
Battery pack is standard.
International AC Adapter/Recharger (110/220V, 50/60Hz). Model S1462, 12 Volt DC adapter
(automotive cigarette lighter plug-in). Model S1465, NiCad Battery Pack.
TO INSTALL OR REPLACE BATTERIES
Remove all plugs from amplifier. Slip a fingernail under battery door, and slide it out. Lift out
battery holder from amplifier. Insert 10 new Alkaline "D" cell batteries. Be careful to observe
polarity. Carefully replace battery pack. Replace battery door.
Do not mix battery types or attempt to recharge alkaline batteries – equipment damage, safety
hazard or fire could result.
TO OPERATE:
Plug microphone into DYNAMIC Microphone jack.
Plug speaker leads into SPEAKER jacks. Turn Amplifier on (switch is located on the front of the
amplifier). The red light will go on, showing that power is available. Rotate VOLUME control
knob to obtain desired loudness level throughout the coverage area.
ON-OFF
When switch is in the ON position, the red light will be on.
DC IN
Connection for optional adapters:
•
S1460 International AC Adapter/Recharger
•
S1462 12 Volt DC (automotive cigarette lighter) Adapter
AUX OUT
Connection for 12 to 15V DC accessory
VOLUME
Rotate clockwise to increase amplification.
MICROPHONE INPUTS
VOICE CARRIER
PORTABLE PUBLIC ADDRESS SYSTEM
MODEL S230A/SW230A
Alternate Power Supplies may be substituted.
Model S1460,
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AmpliVox S230A
Summary of Contents for AmpliVox S230A
- Page 1 Connection for optional adapters: • S1460 International AC Adapter/Recharger • S1462 12 Volt DC (automotive cigarette lighter) Adapter AUX OUT Connection for 12 to 15V DC accessory VOLUME Rotate clockwise to increase amplification. MICROPHONE INPUTS VOICE CARRIER MODEL S230A/SW230A Model S1460,...
