50 Watt Portable PA System with
Thank you for choosing the S222A / SW222A / SW223A /
SW224A Portable PA System from AmpliVox Portable Sound
Systems.
We are excited in introducing this truly unique system. Our sys-
tem combines flexibility with functionality. Please refer to this user
guide as you enjoy the unique capabilities of another quality prod-
uct from AmpliVox Portable Sound Systems.
We encourage you to visit our website www.ampli.com to register
your product for its warranty coverage, sign up to receive our
newsletter, download our catalog, and learn more about the com-
plete line of AmpliVox audio visual products, including portable
PA systems, and lecterns.
The Bluetooth® wordmark and logo is registered trademark owned by Bluetooth SIG, Inc. and any use of such marks
User Guide
by AmpliVox Portable Sound Systems is under license.
1-800-572-2194 • DISPLAYS2GO.COM
TABLE OF CONTENTS
SAFETY INSTRUCTIONS .......................................... 2
.
PACKAGE CONTENTS ................................................ 3
SPECIFICATIONS.................................................3
INSTALL BATTERIES........................................... 4
WIRELESS HANDHELD MICROPHONE .................. 5
AMPLIFIER FEATURES........................................ 6
OPERATION .................................................................7
.........................................7
MICROPHONE STORAGE ............................................7
..
TROUBLESHOOTING .................................................. 8
WARRANTY ................................................................8
