Ness SecurityGuard III Owner's Manual page 8

open here. remove
cover.
radio Panic Button (rPB) optional
open here. remove
cover.
radio Door Bell (rDB)
oPeRAtion
Press the Door Bell button to sound the door chime at
the securityGuarD iii main unit.
bAtteRy RePLAcement
carefully lift off the rDB Door Bell unit's cover by
unclipping at the bottom using a flat-bladed screw-
* example device
number
driver or blunt knife.
insert a new cr2032 3V lithium battery and then
test the sensor.
the new battery must be inserted in the battery clip
Positive (+)
side up.
with the positive (+) side up.
insert the new
battery. cr2032
3V lithium
battery.
oPeRAtion
Press the red Panic button to sound the Panic alarm.
(as programmed by your installer.)
bAtteRy RePLAcement
carefully lift off the Panic Button's cover by unclip-
ping at the bottom using a flat-bladed screwdriver or
* example device
number
blunt knife.
insert a new cr2477 3V lithium battery and then
test the sensor.
the new battery must be inserted in the battery clip
Positive (+)
side up.
with the positive (+) side up.
insert the new
battery. cr2477
3V lithium
battery.
8
