1. Press down and lift the battery cover in the direction of the arrow
to open the battery compartment.
2. Install or replace 4 "AA" 1.5 V Alkaline batteries according to
the indication inside the compartment.
3. Replace the battery cover by inserting the bottom tabs first, then
push in the top end of the battery cover.
Replace batteries when:
1. Low battery icon appears on display.
2. The On / Off / Start button is
pushed and nothing appears
on display.
1. Connect the AC adapter with the AC adapter jack in the
back of the unit.
2. Plug the AC adapter into the socket.
Please use a Physio Logic
AC adapter (12V DC, 600mA).
Caution:
1. Please unload the batteries when operating with the AC mode
for a longer period of time. Leaving the batteries in the
compartment for a long time may cause leakage, which may lead
to damage of the unit.
2. No batteries are needed when operating in the AC mode.
3. Please contact the distributor for compatible AC adapters.

Installing Batteries

Using the AC Adapter
