Selecting the quantity of coffee in the cup

The appliance is set by default to automatically make the
following quantities of coffee:
- espresso coffee, when the
(≃40ml);
- long coffee when the
- two espresso coffees, when the
- two long coffees, when the
To change the quantity of coffee the appliance delivers
automatically into the cup, proceed as described below:
- press the button corresponding to the quantity to be
modified and hold it down until the light flashes and the
appliance starts delivering coffee. Release the button;
- when the coffee in the cup reaches the required level, press
the same button again to memorise the new amount.
The quantity of coffee in the cup has now been programmed.

Adjusting the coffee mill

The coffee mill is preset in the factory to make coffee correctly
and should not require adjusting initially.
However, if after making the first few coffees you find that the
coffee is too thin and not creamy enough or that delivery is too
slow (a drop at a time), this can be corrected by adjusting the
grinding adjustment dial (fig. 13).
Please note :
The grinding adjustment dial must only be turned when the
coffee mill is in operation.
If the coffee is delivered too slowly or
not at all, turn one click clockwise.
For fuller bodied creamier coffee,
turn one click anticlockwise (do
not turn more than one click at a
time otherwise the coffee could be
delivered a drop at a time).
These adjustments will only be evident after at least 2 cups of
coffee have been delivered.
If this adjustment does not obtain the desired result, turn the
dial another click.

Setting the temperature

To modify the temperature of the water used to make the
coffee, proceed as follows:
1. With the appliance off and the main switch in the I
position (fig. 3), press the
down until the lights on the control panel come on.
2. Press the
temperature:
button is pressed
button (≃120ml) is pressed;
button is pressed;
button is pressed.
button and hold it
button to select the required
LOW
3. Press the
lights go off.

Tips for a hotter coffee

For a hotter coffee, before delivery you are recommended to:
• rinse the appliance through by pressing the
button. Hot water flows out of the coffee spouts and
heats the internal circuit of the machine so that the coffee
delivered will be hotter.
• warm the cups with hot water (using the hot water
function);
• set a hotter coffee temperature (see section "Setting the
temperature").

making coffee using coffee beans

Important!
Do not use caramelised or candied coffee beans as they could
stick to the coffee mill and damage it.
1. Fill the container with coffee beans (fig. 9).
2. Place under the coffee spouts:
- 1 cup if you want one coffee (fig. 10);
- 2 cups if you want 2 coffees (fig. 11).
3. Lower the spouts as near as possible to the cup. This makes
a creamier coffee (fig. 12).
4. Press the button corresponding to the number of coffees
required
1 espresso
2 espresso
5. Preparation begins and the light corresponding to the
selected button flashes on the control panel.
Once the coffee has been made, the appliance is ready for use
again.
Please note :
• While the coffee maker is making coffee, delivery can be
interrupted at any moment by pressing one of the coffee
buttons.
• At the end of delivery, to increase the quantity of coffee
12
HIGH
button to confirm the selection. The
1 long coffee
2 long coffees
