To get VP-404R(H) / VP-4048R(H) up and running via local keyboard, a keyboard is required. The
interface of VP-404R(H) / VP-4048R(H) operation is as following figure.
1
2~13
14 15
16
1. Esc: Cancel
Provide cancel and close function. When pressing "Esc", it will close current setting menu and
returns to the previous level.
2. F1: Menu
Provide main menu display function. When users press "F1", it will display the main menu on the
screen, and press "Left/ Right/ Up/ Down" button to select, and then press "Enter" for
confirmation.
3. F2: Playback
Press "F2" to enter playback list, and press "Up/ Down" button to select the recorded file, and then
press "Enter" or "F5" to play the video.
4. F3: Local (view live image immediately)
When pressing "F3", users can view the live image immediately.
5. F4: Screen
Press "F4" to switch display setting from Single, Quad, 8 splits and 16 splits. Press "Up/ Down"
button to select, and then press "Enter" to make sure the selection.
6. F5:
(Play)
When pressing "F5", the recorded data will start to play. Users also can press "F5" to skip the crash
video and play next time period continuously.
7. F6:
(Pause)
When pressing "F6", users can pause the playing video.
8. F7:
(Stop)
When pressing "F7", users can stop the playing video.
9. F8: Speed (switch playing speed)
When pressing "F8", users can switch the playing speed.
10. F9:
(Seek Backward)
When pressing "F9", users can backward seek the video.
11. F10:
(Step Backward)
When pressing "F10", users can backward the video frame step-by-step.
Appendix A: Operation via local keyboard
17
18 19
I
Appendix
