Boston
Models: 1200-C & 1700-C Insert
SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
INSTALLER:
Leave this manual with the wood stove.
CONSUMER:
Retain this manual for future reference.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD
BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT
IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
O- T L
Tested &
Portland
Listed By
Oregon USA
C
US
OMNI-Test Laboratories, Inc,
Report # 268-S-06b-2
Contact your local building or fire officials,
This heater meets the U. S. Environmental Protection Agencies emission limits
for wood heaters sold after July 1st, 1990. Under specific conditions this heater
has been shown to deliver heat at rates ranging from 11,479 to 34,196 BTU per
hour for the 1200 and from 9,425 to 31,780 BTU per hour for the 1700.
or the authority having jurisdiction about
restrictions and installation inspection
requirements in your area.
OWNERS MANUAL
50-2362
Advertisement
Table of Contents
Related Manuals for Enviro 1200-C Insert
Summary of Contents for Enviro 1200-C Insert
- Page 1 Boston Models: 1200-C & 1700-C Insert OWNERS MANUAL SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Contact your local building or fire officials, INSTALLER: or the authority having jurisdiction about Leave this manual with the wood stove.
-
Page 2: Table Of Contents
Operating Instructions..................4 Building Your Fire.................5 How It Works..................9 Specifications....................10 Air Control..................10 Specifications..................10 Clearances To Combustibles - 1200-C Insert.........11 Clearances To Combustibles - 1700-C Insert.........12 Dimensions - 1200-C Insert..............13 Dimensions - 1700-C Insert..............14 Installation....................15 Removal From Pallet................15 Modifications For Installation with 19 ”... -
Page 3: Safety Precautions
Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” WOOD STOVE, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: ● Please read this entire manual before you install and use your new woodstove. Failure to follow instructions may result in property damage, bodily injury or even death. Be aware that local Codes and Regulations may override some items in this manual. -
Page 4: Operating Instructions
Wear gloves when handling damaged glass door assembly to prevent personal injury. When the glass door assembly is being transported, it must be wrapped in newsprint and tape and/or a strong plastic bag. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. FIRE EXTINGUISHER AND SMOKE DETECTION: All homes with a solid fuel burning stove should have at least one fire extinguisher in a central location known to all in the household and a smoke detection device in the room containing the stove. -
Page 5: Building Your Fire
Operating Instructions CREOSOTE - ITS FORMATION AND NEED FOR REMOVAL: When wood is burned slowly, it may produce tar and other organic vapors, which combine with expelled moisture to form creosote. The creosote vapors condense in the relatively cool chimney of a slow-burning fire. - Page 6 Operating Instructions NOTE: Until the fire is burning well, leave the air controls fully open. d) Regulate the heat output of the stove by adjusting the air controls to allow a larger fire and vice versa. A short period of experimentation with the control settings will allow you to regulate the heat output to keep your home comfortable.
- Page 7 Operating Instructions some additional kindling may be needed to sustain the fire. DO NOT add more paper after the fire has started. g) Once the kindling has started to burn, add some smaller pieces of seasoned, dry firewood. Note: Adding large pieces at the early stages will only serve to smother the fire. Continue adding small pieces of seasoned dry firewood, keeping the door slightly open until each piece starts to ignite.
- Page 8 Operating Instructions clean, but if you must clean the glass, use a soft cloth with no abrasive and clean only when the unit is cold. Cold firebox temperature and poor draft cause sooting of the glass. Once the firebox temperature and the draft increase, the soot will burn off.
-
Page 9: How It Works
Operating Instructions orks Exhaust Smoke Convection Heat " Ceramic baffle; reflects heat down to burn the particles in the smoke. Primary air; window air wash (cooler air to Secondary air tubes; keep the glass clean). creates a second burn on the particles in the smoke for a more efficient &... -
Page 10: Specifications
Specifications ontrol The primary air is controlled by the rod located on the right side of the unit. To increase your air, pull the rod out and to decrease, push the rod in. All the units have a secondary air that flows through the tubes at the top of the firebox, just below the baffles. -
Page 11: Clearances To Combustibles - 1200-C Insert
Specifications - 1200-c i learances omBustiBles nsert Table 2: 1200-C Insert Clearance to Combustibles. A Minimum clearance to an unshielded side wall 10” (254 mm) B Minimum clearance to an unshielded 8” (203 21” (533 mm) mm) mantel C Minimum top facing (protruding ¾” [19 mm]) 17½”... -
Page 12: Clearances To Combustibles - 1700-C Insert
Specifications - 1700-c i learances omBustiBles nsert Table 5: 1700-C Insert Clearance to Combustibles. Minimum clearance to an unshielded side wall 10” (254 mm) Minimum clearance to an unshielded 8” (203 24” (610 mm) mm) mantel Minimum top facing (protruding ¾” 19½”... -
Page 13: Dimensions - 1200-C Insert
Specifications - 1200-c i imensions nsert... -
Page 14: Dimensions - 1700-C Insert
Specifications - 1700-c i imensions nsert... -
Page 15: Installation
Installation Failure to follow these instructions carefully could cause personal injury or property damage. emoval allet • Remove the bricks from the unit before starting. • Remove the two lag bolts (shown in Figure 6) that secure the unit to the pallet from inside the firebox. •... -
Page 16: Masonry Fireplace Installation
Installation asonrY ireplace nstallation Unless you are experienced, we recommend installation by your dealer or a professional installer. Install only in a masonry fireplace with a good-condition chimney at least 15 ft (4.6 m) high, both of which have been constructed in accordance with the building code. Refer to Tables 4 and 7 for minimum masonry fireplace dimensions. - Page 17 Installation The flue collar is removable for installations into fireplaces with low openings. a) Remove the rear two (2) secondary air tube and C-Cast Ceramic Baffles, if installed (see c-c eraMic affLe ). Remove the secondary air nstaLLation tubes by placing a screwdriver (any style except flat head) into one of the air holes and tapping it with a hammer/mallet to USA 16”...
- Page 18 Installation Figure 14: Removable flue collar in place. 4. Screw or nail the provided metal plate with the wording “THIS FIREPLACE HAS BEEN ALTERED TO ACCOMMODATE A FIREPLACE INSERT AND SHOULD BE INSPECTED BY A QUALIFIED PERSON PRIOR TO THE RE-USE AS A CONVENTIONAL FIREPLACE.”...
-
Page 19: Modifications For Installation With
Installation usa o nstallation sing lock late If this unit is to be installed into a masonry fireplace or a zero-clearance fireplace with a direct connection you must install a non-combustible seal-off device such as a block-off plate or damper adapter. By installing a block-off plate you seal the chimney, ensuring that no smoke enters the home and sealing the chimney to encourage draft. - Page 20 Installation 4. Using the template make the block- off plate of 24 gauge or thicker steel. Drill two (2) holes in each flange for mounting the plate. 5. Mount the block-off plate using Mantel masonry screws masonry Stainless steel chimney fireplace and sheet metal screws on a connector must extend zero-clearance fireplace (screws need...
-
Page 21: Model 1200-C Brick Placement & Tube Locations
Installation 1200-c B & t odel rick lacement ocations COMPLETE THE STOVE AND SMOKE PIPE INSTALLATION BEFORE PLACING THESE BRICKS. Tube E Tube D Tube A 1. Place the three (3) full size bricks along each side of the firebox and one (1) full size brick on either side of the back of the firebox. -
Page 22: Model 1700-C Brick Placement & Tube Locations
Installation 1700-c B & t odel rick lacement ocations COMPLETE THE STOVE AND SMOKE PIPE INSTALLATION BEFORE PLACING THESE BRICKS. Tube C Tube B 1. Place the four (4) full size Tube A bricks along each side of the firebox and one (1) full size brick on either side of the back of the firebox. -
Page 23: C-Cast Ceramic Baffle Installation
Installation eramic aFFle nstallation 1. Slide the right C-Cast Ceramic Baffle in over the secondary air tubes at the top of the firebox. The tab must be on the top and pointing towards the center and the smooth side is to face down. 2. -
Page 24: Fan Wiring Diagrams
Installation iring iagrams This appliance, when installed, must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE. Part 1, SAFETY STANDARDS FOR ELECTRICAL INSTALLATIONS, or THE NATIONAL ELECTRICAL CODE ANSI / NFPA 70 in the USA. -
Page 25: Disassembly
Disassembly CAUTION: ENSURE POWER CORD IS UNPLUGGED AND UNIT IS COLD BEFORE ATTEMPTING ANY DISASSEMBLY. emoval 1. Open the door and loosen the 1/4” screws using a 3/8” wrench. 2. Remove the cast top from the unit by lifting up and forward. (For re-assembly, ensure that slots in the brackets are fully seated on the bolts) Figure 25: Removal of Cast Top... -
Page 26: Removal Of Cast Side Panels
Disassembly emoval anels 1. Loosen (but do not remove) the three 1/4” screws on the side casting using a 3/8” wrench. 2. Lift the side casting up and out. (Repeat steps 1 and 2 for other side) Figure 27: Cast Side Panel Screws emoval rackets 1. -
Page 27: Removal Of Surround Panel
Disassembly emoval urround anel Figure 29: Removal of Surround Panel 1. Remove the fan control dial by gently pulling straight up. 2. Remove the two screws on the left side with a 5/16” socket and then do the same for the three screws on the right. Be sure to support the panel before removing the last screws. -
Page 28: Removal Of Lower Front Casting
Disassembly emoval ower ront asting 1. Use a 3/8” socket to remove the three 1/4” bolts. Figure 30: Lower Front Casting Removal emoval ower 1. Use a 3/8” wrench to loosen the two 1/4” bolts. 2. The cast trim bracket can now be lifted off the keyslots. -
Page 29: Removal Of Fan Assembly
Disassembly emoval ssemBlY 1. Follow the disassembly steps from Figures 25- 28 (Left side only). 2. Pull off the fan control dial by lifting up. 3. Unplug the wire connections. A light wiggle will help loosen the connectors. 4. Use a 3/8” socket to remove the two 1/4” bolts. -
Page 30: Rating Label
Rating Label DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE Tested & LISTED SOLID FUEL SPACE HEATER / IDENTIFIE COMME UN FOYER A COMBUSTIBLE SOLIDE Listed By Serial No. / No. De Serié: Model / Modèle: Kodiak 1200 FS Kodiak 1200 Insert Kodiak 1700 FS Kodiak 1700 Insert... -
Page 31: Parts List
Parts List Reference # Description Part # 120F (49C) Ceramic Fan Temperature Sensor EC-001 FPI Fan Controller 115V EC-039 Domestic Power Cord 115V EC-042 Heyco Strain Relief EC-044 Wood Door Gasket EF-168 Glass with Tape 10-000 1200 & 1700 Front Secondary Air Tube A 50-1099 1700 Rear Secondary Air Tube C 50-1100... -
Page 32: Parts Diagram
Parts Diagram... -
Page 33: Warranty
Industries, our commitment to the highest level of quality and customer service is the most important thing we do. Each Enviro stove is built on a tradition of using only the finest materials and is backed by our Exclusive Lifetime Limited Warranty to the original purchaser. With Enviro, you’re not just buying a stove, you’re buying a company with years of unequalled performance and quality. - Page 34 If you are not satisfied with the service provided by the Enviro dealer, write to Sherwood Industries Ltd. at the address listed on the last page of the Owner’s Manual. Include the date you bought the product and a description of the problem.
- Page 35 If the stove is used for commercial purposes, it is excluded from the Limited Warranty. 23. No dealer, distributor, or similar person has the authority to represent or warrant Enviro products beyond the terms contained within the Limited Warranty. Sherwood Industries Ltd. assumes no liability for such warranties or representations.
-
Page 36: Installation Data Sheet
NAME OF INSTALLER: MODEL:___________________________________ SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: ______________ (dd/mm/yyyy) ADDRESS: DATE OF INSTALLATION:___________ (dd/mm/yyyy) _________________________________________ INSTALLER’S SIGNATURE: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com February 15, 2011 C-12378...
