Repairs - Belrobotics ParcMow Instruction Manual

The table below illustrates the most common problems encountered by users.
For all other problems or anomalies, contact your dealer immediately.
Situation
Alarm message on
screen:
1
"Head..."
Alarm message on
screen:
2
"Lifted"
Alarm message on
screen:
3
"Supply outage"
Alarm message on
screen:
4
"Charge contact?"
B E L R O B
B E L R O B
10.
R
EPAIRS
Explanation
The grass which has been cut was
1 too high and has clogged up one or
more of the cutting heads.
Something is blocking one or more
2 of the cutting heads (e.g. a branch,
fruit etc.)
Someone has lifted the robot while
1
it was working.
The robot has sensed a difference in
2 height because of an anomaly on
the ground (e.g. deep hole, rut etc).
The robot was connected to its
1 charging station but has been
detached.
The robot seems to be connected to
2
the charging port at the station.
Upon returning to the station, the
robot has manoeuvred to connect
1 to the charging port, but has not
detected a charge and has moved
away from the station.
O T I C S
O T I C S
Clean the cutting heads (the
user must wear protective
gloves).
Unblock the cutting heads
(the user must wear
protective gloves).
This alarm has been
activated for safety reasons.
Simply restart the robot.
Fix the problem on the
ground so that the robot no
longer detects an anomaly.
Restart the robot.
If you put the robot back on
charge manually, remember
to press the
continues working again
automatically once fully
charged.
Check whether the station is
connected to the electricity
supply and whether the
charging ports on the station
or robot have rusted.
See §8.C., p.22
Check whether the charging
ports on the station or robot
have rusted.
See §8.C., p.22
Solution
key so that it
24
