D. D
5
G M
IAGRAM OF REEN OW PARTS
B E L R O B O T I C S
B E L R O B O T I C S
1 Bodywork
2 Sonar obstacle detection
3 /
4 Charging port
5 Control panel and display
6 Main switch – robot ON/OFF
7 Mowing height regulator
8 Battery area
9 Case containing electronic motherboard
10 Cutting heads (x2)
11 Protective buffers
12 Drive wheels
13 Front wheels (x1)
14 Sensor to detect boundary wire signal
15 Charging station
16 Charging arm
17 Sonar station
18 LED for displaying signals
10
