B. S
ENDING THE ROBOT BACK TO THE CHARGING STATION
I. For one cycle (Return to station, F1)
If you want the robot to continue mowing after it has recharged:
a. Stop the machine by raising the hood.
b. Press F1. The screen will display: "O01 GoToChge: √ "
c. Press to start the robot again.
d. Close the hood in the next 8 seconds.
II. For several cycles (Rest at station, F2)
If you want the robot to remain at the charging station until further notice:
a. Stop the machine by raising the hood
b. Press F2. The screen will display: "O02 Stay@Chge: √"
c. Press to start the robot again.
d. Close the hood in the next 8 seconds.
If you want the robot to restart its mowing cycles after an "F2" rest period at the charging
station:
a. Raise the hood of the robot at the station.
b. Press to start the robot again.
c. Close the hood in the next 8 seconds.
d. The robot will leave the station again once its batteries have been fully recharged.
C. V
ISUAL AND AUDIO SIGNALS
Your Belrobotics robot conveys messages about its status through beeps or information
displayed on the screen.
The station also conveys messages about its status through a two-coloured LED light.
ROBOT
Beeps
- 1 long beep: Stop robot or incorrect key
- 1 short beep: Key has been pressed
- 2 long beeps / 10 sec: Charge robot
- 2 short beeps / 1 sec: Cutting heads
starting up
- 1 short beep /2 sec: Alarm
Charge
- FC: Fast Charge, normal mode
- SC: Slow Charge, rest mode
- WU: Wait User
- WT: Wait programmed Timers
- W.BH: Wait Battery too Hot
- W.FT: Wait Freezing ambient
Temperature
B E L R O B
B E L R O B
has been pressed
O T I C S
O T I C S
CHARGING STATION
LED
- Blinking green light: OK, normal mode
- Blinking red light: boundary wire has
been cut or is too long (usually >
1200m)
- Continuous red light: failure of the
station's electronic card or wire is
too short (usually < 200m)
- No colour: the station is not connected
to an electricity supply.
15
