A. M
OWING MODE
The Belrobotics robot uses a "random" mowing method. The random mode means that it
chooses its route in an unsystematic manner. When it comes across an obstacle or the
boundary wire, the onboard computer selects a new direction. Thus, the route and the
directions the robot takes will be different every time. By the end of the process, every
square metre of the lawn will have been mown. In areas where the lawn is denser, the robot
will automatically adapt its mowing mode by slowing down or mowing one square at a time.
When the batteries need to be recharged, the robot follows the boundary wire to its
charging station. After the batteries have been fully recharged, it automatically continues
the process.
If the lawn does not need to be mown, the robot detects this and waits at its charging
station for an extended period. It then starts mowing again at a later date. It only mows
when necessary.
B. M
OWING HEIGHT
I. How to set the mowing height
The mowing height can be set between 'x' mm and 'y' mm (see table on page 11) by setting
intermediary fixed values.
a. Raise the hood
C. S
AFETY SENSORS
The robot is equipped with a sonar system and several collision sensors, meaning that it can
slow down and change direction when it comes across an obstacle at least 50cm high and
10cm wide.
It is also equipped with a system which instantly stops the rotation of the cutting heads if it
detects it is being lifted.
B E L R O B O T I
B E L R O B O T I
5.
G U
UIDE TO
b. Lift the adjustment
valve
C S
C S
SE
c. Slide along the
adjustment rod to the
desired height.
12
