- Page 1 Instruction manual for Belrobotics robot lawnmowers – 2013 models EN Version 18/09/2013...
-
Page 2: Table Of Contents
2. Safety recommendations & Warning symbols ....5 3. Description ................ 7 Overview ........................7 Diagram of BigMow parts ................... 8 Diagram of ParcMow parts ..................9 Diagram of GreenMow parts ..................10 4. Technical Specifications ..........11 5. Guide to Use ..............12 Mowing mode ...................... -
Page 3: For Your Personal And Collective Safety
OR YOUR PERSONAL AND COLLECTIVE SAFETY The Belrobotics robot lawnmower is designed with user safety in mind. For example, the cutting heads are covered by a special patent. If the lawnmower comes into contact with an object, the heads retract automatically. This is one of the major advantages of the mower. -
Page 4: Maintenance And Storage
E. L IABILITY Belrobotics refuses all liability in cases where the robot is used in a way which is not in accordance with the instructions provided. Do not modify your robot without prior agreement from Belrobotics. Any unauthorised modification could render your robot dangerous and could lead to serious injury when used. -
Page 5: Safety Recommendations & Warning Symbols
& W AFETY RECOMMENDATIONS ARNING SYMBOLS Read this instruction booklet carefully and familiarise yourself with the content before using your robot for the first time. This automatic lawnmower device could be dangerous if used incorrectly. The instructions for use and safety recommendations must be respected at all times so that the device can be used as effectively and safely as possible. -
Page 7: Description
ESCRIPTION A. O VERVIEW The Belrobotics robot is a fully automatic lawnmower. It can be used to maintain up to 2 hectares of lawn, providing the owner with a consistent and independent method of maintaining their lawn. The robot works independently in its mowing area, which is marked out by a boundary wire buried underground. -
Page 8: Diagram Of Bigmow Parts
B. D IAGRAM OF OW PARTS Bodywork Sonar obstacle detection Tactile bumper for obstacle detection Charging port Control panel and display Main switch – robot ON/OFF Mowing height regulator Battery area Case containing electronic motherboard Cutting heads (x5) Protective buffers Drive wheels Front wheels (x4) Sensor to detect boundary wire signal... -
Page 9: Diagram Of Parcmow Parts
C. D IAGRAM OF OW PARTS Bodywork Sonar obstacle detection Tactile bumper obstacle detection Charging port Control panel and display Main switch – robot ON/OFF Mowing height regulator Battery area Case containing electronic motherboard Cutting heads (x3) Protective buffers Drive wheels Front wheels (x2) Sensor to detect boundary wire signal Charging station... -
Page 10: Diagram Of Greenmow Parts
D. D IAGRAM OF REEN OW PARTS Bodywork Sonar obstacle detection Charging port Control panel and display Main switch – robot ON/OFF Mowing height regulator Battery area Case containing electronic motherboard Cutting heads (x2) Protective buffers Drive wheels Front wheels (x1) Sensor to detect boundary wire signal Charging station Charging arm... -
Page 11: Technical Specifications
ECHNICAL PECIFICATIONS BigMow ParcMow GreenMow 125W Thrust 2 wheels, φ45cm 2 wheels, φ36cm 2 wheels, φ26cm Working speed 3.6 km/h 2.9 km/h 2.2 km/h Maximum incline Battery type / capacity Li-Ion / 15Ah Li-Ion / 10Ah Li-Ion / 10Ah Max. energy... -
Page 12: Guide To Use
A. M OWING MODE The Belrobotics robot uses a “random” mowing method. The random mode means that it chooses its route in an unsystematic manner. When it comes across an obstacle or the boundary wire, the onboard computer selects a new direction. Thus, the route and the directions the robot takes will be different every time. -
Page 13: Initial Setup
(one notch every 2 days). If the grass height is irregular, the Belrobotics robot will mow the higher patches of grass more slowly (leading to a better result). If the cutting resistance is too high, the robot will mow one square at a time. -
Page 14: Instructions For Use
NSTRUCTIONS FOR USE A. U SING THE CONTROL PANEL AND DISPLAY SCREEN The control panel has a total of 17 keys: 10 "Numbers” keys and 7 "Action" keys. When it starts up, the display shows the time and date on the system, as well as the battery voltage. -
Page 15: Sending The Robot Back To The Charging Station
The robot will leave the station again once its batteries have been fully recharged. C. V ISUAL AND AUDIO SIGNALS Your Belrobotics robot conveys messages about its status through beeps or information displayed on the screen. The station also conveys messages about its status through a two-coloured LED light. -
Page 16: Using The Menu
D. U SING THE MENU I. Infos In this menu you will find basic information about your Belrobotics robot such as the series number of the main electronic card, the programme version, statistics and the robot’s events log. See below for details of the 4 sub-menus under the “... - Page 17 The “S ” menu and its 7 sub-menus allow you to adjust several settings in order to ETTINGS adapt and configure your Belrobotics robot to your needs. Below you will find explanations of the 7 sub-menus. 1. R ESTS SETTINGS This sub-menu allows you to programme up to 4 rest periods during which your robot will not work.
- Page 18 2. C LOCK With this sub-menu users can set the time and date which are displayed on the screen of the robot. 1. When "C " is displayed, press # once. LOCK 2. Enter the time in hours and minutes using the numeric keys.
-
Page 19: Using Options
E. U SING OPTIONS This sub-menu contains 11 options. Options can be selected ' ' or deselected ' - ' with the key by your dealer to suit your mowing area. Caution is advised when using this sub-menu as modifications can significantly alter the effectiveness of the robot. - Page 20 Option "O02 – Stay@Chge ": This option forces the robot to return to its charging station and stay there until further instruction from the user. From the "M " screen, press O02 Stay@Chge: " - ", the robot continues working normally. O02 Stay@Chge: "...
- Page 21 Option "O09 – HeadRotInv": This option alternates the direction in which the cutting heads rotate after each mowing cycle. From the "O " screen, press # – 9 and use the key to select or deselect the PTIONS option. O09 HeadRotInv: "...
-
Page 22: Service
A. B ATTERIES Belrobotics robot lawnmowers are equipped with the latest generation Li-Ion batteries. Their capacities differ depending on the model of robot. The battery lifespan is optimised when the robot is allowed to function automatically. Users must therefore leave the robot to manage its own work cycles independently as often as possible. -
Page 23: Cutting Heads
E. C UTTING HEADS The cutting heads are the main determiners of the mowing result. You are advised to check them at least once a month and replace them when they are worn out. It is advisable to change them at the beginning of the season and during the month of June. Use the following procedure for changing the cutting heads: 1. -
Page 24: Repairs
EPAIRS The table below illustrates the most common problems encountered by users. For all other problems or anomalies, contact your dealer immediately. Situation Explanation Solution The grass which has been cut was Clean the cutting heads (the too high and has clogged up one or user must wear protective Alarm message on more of the cutting heads. - Page 25 Situation Explanation Solution Screen displays: SC (see §7.C, p.15) This situation is normal. The grass in the mowing area has The robot will continue its been adequately cut. The robot is work cycle again when now resting at the station to save necessary.
