Integrated Use & Care
Drawer Storage
DRAWER REMOVAL
IMPORTANT NOTE: Before removing the top drawer from
a drawer unit, you must first disconnect the control cable
as shown in the illustration below.
To remove a storage drawer from your integrated tall or
drawer unit, pull it open until it stops. Raise the drawer
front and pull out as shown in the illustration.
To replace a drawer, raise the front of the drawer up and
place onto the drawer slide tracks. Engage the hook at the
rear of each slide with slots in the back of the drawer tub.
For 36" units, there are tabs on each drawer that
(914)
must be positioned between the hooks. Then engage the
small white pegs at the front of each drawer slide with
holes at the front of the drawer tub. Reconnect the control
cable.
You must first disconnect the control cable before
removing the top drawer of a drawer unit.
Control cable. Drawer removal.
REMOVABLE CRISPER COVER
One lift-up crisper cover is standard with each tall and
drawer refrigerator unit and the drawer combination unit.
The clear-view window allows easy access and visibility of
all vegetables stored in the drawer.
You can easily remove this cover for cleaning with soap
and water, or move it to another drawer by lifting the front
edge up and pulling out from the front. Refer to the illus-
tration below.
IMPORTANT NOTE: For model 700BC(I), drawer combina-
tion unit, the removable crisper cover can only be used in
the upper drawer.
DRAWER DIVIDER
The divider of the upper drawer is easily removed by
pulling forward and sliding the back edge away from the
back of the drawer. Reverse this procedure to insert the
divider, as shown in the illustration below.
The divider of the lower drawer is removable if there is no
ice maker, but screws have to be removed to do so. For
units with an ice maker, the lower divider is not removable.
Crisper cover removal.
subzero.com
Drawer divider removal.
