Integrated Use & Care
Refrigerator Storage
DELI DRAWER AND SHELF
The one-piece deli drawer and shelf assembly in models
700TR, 700TCI and 736TR is easily removed for cleaning
and repositioning. The deli drawer is convenient for
storage of small items and for keeping deli items fresh.
Refer to the illustration below
Remove this assembly in much the same way you remove
the adjustable glass shelves.
CRISPER (MODEL 736TCI)
The sealed crisper with two dividers in model 736TCI
offers convenient storage of fruits and vegetables.
To remove the crisper, first lift the glass shelf off of the
plastic side supports, then lift the crisper bin up off of the
bin cradle. Refer to the illustration below.
To replace the crisper, place the bin on top of the bin
cradle. The groove across the bottom of the bin should
align with the crossbar at the front of the cradle. Place the
glass shelf on top of the side plastic side supports.
Deli drawer and shelf. Crisper (736TCI).
STORAGE DRAWERS AND CRISPER (MODEL IC-27R)
Column model IC-27R has two storage drawers and a
high-humidity crisper. The drawer front panel is clear so
you can easily view the contents. Be sure to unload the
storage drawers and crisper before removal.
To remove a storage drawer or the crisper, pull the drawer
out until it stops. Lift the front of the drawer slightly and
pull straight forward. Refer to the illustration below.
IMPORTANT NOTE: If the door is limited to a 90° door
opening, the shallow door shelves will need to be removed
in order to remove a drawer.
To reinstall, push the drawer slides back into the refrigera-
tor. Align the drawer with the slides, then push the drawer
straight back on to the slides until it stops. Press down-
ward on the front of the drawer to engage the slides.
Storage drawer (IC-27R).
