  • Page 1 INSTALLATION GUIDE Integrated Refrigeration...

  • Page 2: Table Of Contents

    Integrated Refrigeration ......3 To ensure the safe and efficient installation of Sub-Zero equipment, please take note of the following types of Model Specifications .

  • Page 3: Integrated Refrigeration

    Any questions or problems regarding the installation TOOLS AND MATERIALS REQUIRED should be directed to your authorized Sub-Zero dealer or • Appliance dolly able to support 500 lbs (227 kg) Sub-Zero customer care at 800-222-7820.

  • Page 4: Model Specifications

    (13) ± ADJUSTMENT IN LEVELING LEGS (102) (102) (13) 24" 24" (610) (610) " " (117) (117) " " " (648) (495) (648) DIMENSIONS WILL VARY WITH PANEL THICKNESS DIMENSIONS WILL VARY WITH PANEL THICKNESS MODELS IC-27R AND IC-27FI MODELS 700TR, 700TFI AND 700TCI...
  • Page 5 Model Specifications subzero.com/specs Overall Dimensions 36" TALL MODELS (914) 36" 24" (914) (610) 14" (356) " (33) " (1976) 80" (2032) TO TOP OF " OPENNG (10) " " (337) (13) " " (876) (260) " (518) " (248) 4" HEIGHT DIMENSIONS ±...
  • Page 6 Model Specifications Overall Dimensions DRAWER MODELS SPECIFICATIONS Shipping Weight (kg) 27" 24" " (686) (610) (10) IC-27R, IC-27FI, 700TR, 700TFI and 700TCI (163) 736TR, 736TFI and 736TCI (218) 700BR, 700BF(I) and 700BC(I) (86) " " (337) (13) " (876) "...

  • Page 7: Site Preparation

    25" (635) (635) OPENING DEPTH 25" (635) OPENING DEPTH OPENING OPENING WIDTH HEIGHT SIDE VIEW FRONT VIEW Opening Dimensions IC-27R and IC-27FI 27" 81" (686) (2057) 700TR, 700TFI, 700TCI 27" 80" (686) (2032) 736TR, 736TFI, 736TCI 36" 80" (914)

  • Page 8: Electrical Requirements

    Site Preparation Electrical Requirements The electrical supply should be located within the shaded area shown in the illustrations below. Follow the National The outlet must be checked by a qualified electrician Electrical Code and local codes and ordinances when to be sure that it is wired with the correct polarity. Verify installing the receptacle.

  • Page 9: Plumbing Requirements

    Do not use self-piercing valves. WALL 6" " (152) A saddle valve kit is available from your authorized (38) " Sub-Zero dealer. (64) " (64) " An in-line filter is required when water conditions have (343) a high sediment content.
  • Page 10 Site Preparation Anti-Tip Bracket Installation WOOD FLOOR APPLICATIONS Use the six #12 x 2 " wood screws and the six " flat To prevent the unit from tipping forward and provide a stable installation, the unit must be secured in place washers provided.
  • Page 11 Site Preparation subzero.com/specs Anti-Tip Bracket Installation Position the Unit INSTALL CONCRETE WEDGE ANCHORS: 1) Drill a " diameter hole any depth exceeding the (10) Before moving the integrated unit into position, secure minimum embedment. Clean the hole or continue the door closed, remove drawers and protect any finished flooring.

  • Page 12: Integrated Installation

    Integrated Installation Position the Unit Level the Unit Plug the power cord into the grounded electrical outlet. Level the integrated unit by turning the front leveling legs With power applied to the appliance, check for lighting clockwise to raise or counterclockwise to lower the unit. and cooling.
  • Page 13 Integrated Installation subzero.com/specs Molding Installation Water Line Connection Install the decorative white molding strips to the top and QUICK CONNECT WATER VALVE sides of the integrated unit for a finished look. The top For units with an ice maker, the quick connect water valve molding strip, used on column and tall models, must be and PEX tubing are located on the bottom right side of the installed before the side molding can be attached.
  • Page 14 Check panel dimensions before proceeding. Additional Turn power back on to the electrical outlet. panel information can be found in the Sub-Zero design IMPORTANT NOTE: The unit must be allowed to have guide and on our website, subzero.com.
  • Page 15 Integrated Installation subzero.com/specs Panel Considerations TYPICAL PANEL DIMENSIONS " " " (679) (679) (908) PANEL WIDTH PANEL WIDTH PANEL WIDTH " " " " " " (1953) (1153) (1153) " " " (2054) (2029) (2029) " " " " (345) (345) "...
  • Page 16 Integrated Installation Panel Considerations DOOR PANEL HEIGHT TOE KICK CLEARANCE The height of the door panel can extend beyond the The toe kick clearance can vary with the height of the typical panel height, provided you do not exceed the panel panel.
  • Page 17 Integrated Installation subzero.com/specs Panel Installation DOOR PANEL INSTALLATION Before attaching the door panel to the door, place a screw in the center of the upper and lower mounting positions, Remove the two pieces of mounting hardware attached to just enough that the slotted holes on the hinge side door the front of the door and set aside.
  • Page 18 Integrated Installation Panel Installation PANEL BRACKET POSITIONING The illustrations below show placement of panel mounting brackets. Dimensions are based on a 4" toe kick and (102) " reveal. A reveal of up to " is possible, but panel dimensions need to be adjusted accordingly. "...
  • Page 19 Integrated Installation subzero.com/specs Panel Installation DRAWER PANEL INSTALLATION With the two mounting brackets in place, install the drawer panel by engaging the top tabbed bracket first, Remove the mounting hardware provided and set aside. then slide the lower L-bracket onto the positioning screws. As with the door panel, you should work on the back side Each drawer panel can be adjusted "...

  • Page 20: Dual Installations

    To engage the door stop, use the blade edge of a Dual installation kits are available through your authorized standard screwdriver and rotate the cam in the center Sub-Zero dealer. portion of the hinge. You must make this adjustment to IMPORTANT NOTE: If a 27"...

  • Page 21: Installation Checklist

    Have stainless steel panels been inspected for any imperfections? This is to be done by the authorized Sub-Zero dealer or installer with the customer, upon completion of installation. Stainless steel panels are covered by a limited 60-day warranty for cosmetic...

  • Page 22: Service Information

    If you are storing or disposing of your old refrigerator or service. freezer, please do it safely. Remove the For the name and number of Sub-Zero factory certified doors or tightly secure service nearest you, check the contact & support section the doors closed.
  • Page 23 The information and images in this guide are the copyright property of Sub-Zero, Inc. Neither this guide nor any information or images contained herein may be copied or used in whole or in part without the express written permission of Sub-Zero, Inc. ©Sub-Zero, Inc. all rights reserved.
