XXX XXX/82315/26MM6636-M313
XXX XXX/82674/26MM6636-O103
XXX XXX/82919/26MM6636-X447
XXX XXX/82698/26MM6636-T401
USE AND CARE GUIDE
CHATHAM ELECTRIC FIREPLACE
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-877-527-0313
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this electric fireplace. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home imporvement
needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY M313 series
Summary of Contents for HAMPTON BAY M313 series
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this electric fireplace. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home imporvement...
-
Page 2: Table Of Contents
Table of Contents Maximum Load Warning ........... 2 Package Contents .............. 6 Safety Information ............. 3 Assembly ..............7 Warranty ..............4 Operation ..............13 Pre-Assembly ............. 5 FCC/ICC Information ............15 Hardware Included ........... 5 Care & Cleaning ............15 Product Specifications ............ -
Page 3: Safety Information
Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at 1-877-527- 0313, 8 a.m.-6 p.m., EST, Monday-Friday. WARNING: This appliance is not a toy. Supervise children playing near it. -
Page 4: Warranty
Warranty 1 Year Limited Warranty: The manufacturer warrants this product to be free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations: Install and operate this Electric Fireplace in accordance with the installation and operating instructions furnished with the product at all times. -
Page 5: Pre-Assembly
Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Bolt PH-BLTBLK001 Wood Dowel PH-DWLNTL001 Shelf Pin PH-SPNPCSPLB2 Screw with Washer Head PH-SCRBLK001 Knob (with bolt, not to scale) Washer PH-WSRBLK001 Euro Hinge PH-HNG35AP01 Connection Plate Bracket PH-BKTZNC001 Floor Glide (pre-attached) PH-GLDBRW001 Adjustable Leveler PH-LVRBLK001 Touch-up Pen... -
Page 6: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Hearth/Base Center Left Side Panel Center Right Side Panel Center Shelf Left Side Panel Right Side Panel Mantel/Top Wood Shelf Left Securing Block Right Securing Block Back Panel Left Front Door Right Front Door Middle Support Panel Top Rear Back Panel Top Left Support Panel... -
Page 7: Assembly
Assembly Installing the center panel Installing the center panel (continued) Locate the Center Left Side Panel (B), Center Right Side Connect the Center Left Side Panel (B), Center Right Panel (C), Center Front Panel (R), Lower Front Panel (S), Side Panel (C), Center Front Panel (R) and Lower Front and set out face down on a scratch-free surface. - Page 8 Assembly (continued) Installing the side panels Installing the securing blocks Locate the Hearth/Base (A) and place the finished side Insert one Wood Dowel (BB) into each of the pre-drilled up on the floor. holes on the Hearth/Base (A). Insert one Wood Dowel (BB) into each pre-drilled hole. Place the Left Securing Block (I) and Right Securing Attach the completed assembly from step 2 to the Block (J) on the Hearth/Base (A), and make sure that...
- Page 9 Assembly (continued) Installing the top support panels Installing the top center panel Insert one Wood Dowel (BB) into each of the pre-drilled Insert one Wood Dowell (BB) into each of the pre- holes of Support panels (P,Q). drilled holes on Middle Support Panel (N). Place the Top Support panels (P, Q) on the top of the assembly from the step 5, as shown in the diagram.
- Page 10 Assembly (continued) Installing the rear panel Installing the doors Attach the Back Panels (K) and Top Rear Back Panel Attach the Knobs (EE) to the Left Front Door (L) and (O) to the back of the completed assembly from step 8. Right Front Door (M), by inserting the pre-assembled Secure the back panels to the assembly using Screws bolts from the Knobs (EE) into the pre-drilled holes in...
- Page 11 Assembly (continued) Installing wood shelves Choose the desired height of each Shelf Panel (H) and place the four Shelf Pins (CC) into the desired hanging locations for each Shelf (H). Insert each Shelf (H) so that they rest on the Shelf Pins (CC). Inserting the fireplace into the mantel assembly Install...
- Page 12 Assembly (continued) Inserting the fireplace into the mantel assembly Install the mounting brackets to hold insert flush against the inside of the mantel front panel. NOTE: Please read all “electric fireplace insert” instructions prior to installing electric insert in your completed fireplace mantel.
-
Page 13: Operation
Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. When a function is changed ° from the control panel or remote control there will be a corresponding indicator (see Figure 1) on the upper-right °... -
Page 14: Replacing The Remote Control Battery
Operation (continued) Replacing the remote control battery Disposing of used batteries The battery may contain hazardous substances that When the remote control stops operating or its range could endanger the enviroment and human health. seems reduced, it is time to replace the battery with new ones. -
Page 15: Fcc/Icc Information
FCC/ICC Information This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio or television reception, which can be determined by turning the equipment off and on. -
Page 16: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Check that the unit is plugged into a There is no power and the logs do not standard 120V outlet. Press the Power button There is no power to the unit. glow. several times, make sure power is set to the “ON”position. -
Page 17: Replacement Parts
Replacement Parts For replacement parts, call our customer service department at 1-877-527-0313, 8 a.m.-6 p.m., EST, Monday-Friday. Part No. Part Description Qty. 26EF023GRA Heater/Blower Assembly Y07-C26-P01 Main Circuit Board Y11-C53-P15 Flame Generator Drive Motor P10-Q Flame Generator/ Spinner Y10-S55-P11 LCD Display Y10-C43-P79 Front Projection Screen Y10-S55-P09... - Page 18 Questions, problems, missing parts? Before returning to the store call Hampton Bay Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-877-527-0313 HAMPTONBAY.COM RETAIN THIS MANUAL FOR FUTURE USE.
