Datamax Mark II Operator's Manual page 65

WiFi Configuration Page
WLAN Network Settings
SSID
WLAN Network Type
Ad Hoc Mode Channel
Access Point Density
WLAN Region Code
WLAN Security Settings
Wireless Security Mode
WPA Passphrase
(Preshared Key)
Re-enter Passphrase
Leap User ID
Leap Password
Re-enter Leap Password
WEP Authentication
Default Key
WEP Key 1 through 4
Appendix C – Ethernet Setup
Service Set Identifier that identifies the Module to connect to an AP. To make this
connection, the Module and AP must have the same SSID. The SSID cannot contain
spaces. Default setting is the MAC address of the wireless module.
Specifies the type of network in which the Module will be used:
Infrastructure = connects to WLAN using an AP.
Ad Hoc = used to connect two peer-to-peer devices.
Unique = resets card to Adhoc Mode and uses the MAC address as the SSID
(default)
When Wireless Network Type is Ad Hoc, selects the channel used for communication.
The two peer-to-peer devices must use the same channel. Range is 1 to 14 channels.
Default channel is 1.
Specifies a rate that, if not sustainable with the current association, causes the Module
to look for an AP with which it can maintain the specified rate. A high setting causes the
Module to more readily switch to another AP.
Low = 2 Mbps cannot be sustained. (default)
Medium = 5.5 Mbps cannot be sustained.
High = 11 Mbps cannot be sustained.
Module Operation Region
Specifies the wireless channels allowed. This setting only applies when the Module is
operating in Ad Hoc Mode. The AP controls the channel used during Infrastructure
Mode. Default is US.
Configures the security settings.
Disable = security is disabled. (default)
wep64 = 64-bit key length (sometimes referred to as 40-bit)
wep128 = 128-bit key length
wpa-psk = WPA Pre-Shared Key
wpa-leap = WPA LEAP
wpa-leap64 = Migration Mode w/ Cipher suite TKIP+40 bit WEP using EAP(LEAP).
wpa-leap128 = Migration Mode w/Cipher suite TKIP+128 bit WEP using EAP(LEAP).
wpa-psk64 = Migration Mode w/Cipher suite TKIP+40 bit WEP using WPA PSK.
wpa-psk128 = Migration Mode w/Cipher suite TKIP+128 bit WEP using WPA PSK.
Requires WPA Passphrase.
Enter your WPA passphrase.
Confirms WPA passphrase entry
User ID for Leap security mode
Password for Leap security mode
Confirm password for Leap security mode
Enables or disables WEP authentication:
Automatic = automatically detects the authentication. (default)
Open System = communicates the key across the network.
Shared Key = allows communication only with devices with identical WEP settings.
Selects the default WEP Key from 1 – 4 if Shared Key or Both is selected for WEP
Authentication. Default is WEP Key 1.
Specify up to four WEP Key values:
If WEP Encryption = 64, enter 10 hexadecimal digits for each key.
If WEP Encryption = 128, enter 26 hexadecimal digits for each key.
Requires LEAP username and password.
Require LEAP username and password.
Requires WPA Passphrase.
57
