INSTRUCTION BOOK FOR
Multi-Mask Imager

Advertisement

Table of Contents
loading

Related Manuals for Da-Lite Multi-Mask Imager

Summary of Contents for Da-Lite Multi-Mask Imager

  • Page 1 INSTRUCTION BOOK FOR Multi-Mask Imager...

  • Page 2: Important Safety

    Mounting The Frame Professional mounting techniques should be adhered to. Da-Lite Screen Company cannot be liable for substandard or faulty installations. Frame Assembly Unpacking and Unrolling the Screen Assembly of the screen should be in a clean environment.

  • Page 3: Electrical Wiring

    Mounting The Frame Electrical Wiring Attaching the Screen Surface to Frame Electrical wiring is required for each mask roller motor. The vertical masking systems have one motor at the frame top. 1. Place the frame over the screen surface. Horizontal masking systems have one motor at the frame top 2.
  • Page 4 Multi-Mask Imager Installation Installing the High Voltage Switch Control (Standard) Three standard 3-position wall switches are supplied. The high-voltage control is connected to the electrical source. It alternates directions of mask motion by means of a hot lead, using the 3-position switches.
  • Page 5 Hanging The Screen On The Wall Operating The Mask Attach the wall brackets to the wall using appropriate fasteners When you lower or retract a mask, it will stop at its present limit. at previously marked locations. If an obstacle (such as a person or furniture) gets in the path of a mask as it is lowered, you should use the switch control to stop Attach the Side Covers to the frame by sliding the Bolts on the the mask's motion;...

  • Page 6: Screen Care And Cleaning

    Screen Care And Cleaning With reasonable care, you expect many years of trouble-free use of your Da-Lite projection screen. We encourage you to keep your screen clean. Avoid getting any foreign material on the screen. It may not be possible to remove scratches, paint, ink, etc.

  • Page 7: Troubleshooting

    Troubleshooting Refer to the following guidelines if you encounter a difficulty in the operation of your Da-Lite Multi-Mask Imager screen. Problems related to electrical or motor function may require a qualified service person or electrician. Should you have a problem that is not addressed here, call the Da-Lite Screen Company.
  • Page 8 OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
