Service Parts List
IMPORTANT: THIS IS DATED INFORMATION. When Requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
ITEM
Log Set Assembly
1 Log 1
2 Log 2
3 Log 3
4 Log 4
5 Log 5
6 Non Combustible board
7 Refractory Kit (Sold as set only)
8 Log Grate
9 Andirons, Cast
10 Base Refractory NG, LP
11 Surround
12 Glass Door Assembly
13 Burner
14 Junction Box
Mesh
Glass Latch Assembly
Exhaust Restrictor
Pilot Tube
Thermocouple
Thermopile
Lava Rock Bag
Mineral Wool
Gasket Assembly
Includes: Vent, Seal Cap, Burner Neck, Shutter
Bracket, and Valve Plate Gaskets
Touch Up Paint
Conversion Kit NG
Conversion Kit LP
Regulator NG
Regulator LP
Pilot Orifice NG
Pilot Orifice LP
Additional service part numbers appear on following page.
DESCRIPTION
Quadra-Fire • QV36DB-A • 2018-900 Rev. F • 12/07
SERIAL # PART NUMBER
LOGS-2018
SRV2018-701
SRV385-736
SRV278-704
SRV2018-704
SRV780-707
385-401
BRICK-292
2018-001
80784
2018-100
2026-108
GLA-6TRXI
2018-005
4021-013
Mesh -6000
386-122A
2027-102
SRV485-301
446-511
060-512
060-721
050-721
385-402A
TUP-GBK-12
NGK-2018
LPK-2018
060-518
060-519
446-505
446-517
QV36DB-A
Stocked
at Depot
Y
N
N
N
N
N
N
N
N
N
N
N
Y
Y
Y
Y
Y
N
Y
Y
Y
N
N
N
N
Y
Y
Y
Y
Y
Y
5
