Quadra-Fire QV36DB-A Owner's Manual page 12

4
6
12
DVP4
DVP6
DVP12
14-1/4
12-3/16
2
MAX.
MIN.
24
36
DVP12A
48
9-7/8
DVP24
O
45.0
10-1/4
DVP45
DVP36
11-1/4
7-1/4
1-1/4 TYP
DVP48
1/2 TYP
8-9/16
12-9/16
NOTE: PIPES OVERLAP 1-1/4 INCHES AT EACH JOINT.
Figure 4. DVP-Series Direct Vent Component Specifications (5-inch inner pipe / 8-inch outer pipe)
12
Quadra-Fire • QV36DB-A • 2018-900 Rev. F • 12/07
