Hunter 42737-01 Installation And Operation Manual

Hunter fan fan user manual
Hide thumbs

Advertisement

Quick Links

Download this manual
42737-01 • 11/14/06

Advertisement

loading

Related Manuals for Hunter 42737-01

Summary of Contents for Hunter 42737-01

  • Page 1 42737-01 • 11/14/06...

  • Page 2: Table Of Contents

    Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation fl exibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profi le, Standard, or Angle mounting. Th e steps in this manual include instructions for all three Installer’s Choice mounting methods.

  • Page 3: Getting Ready

    • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...

  • Page 4: Assembling And Hanging The Fan

    (steps 3-3 – 3-4). Note: For low profi le mounting, the downrod is replaced with the low profi le washer. Downrod 3-1. To assemble fan to hang down from a fl at or angled ceiling, insert the downrod through the canopy and canopy trim ring. Feed the Canopy wires from the fan through the downrod.

  • Page 5: Installing The Canopy And Canopy Trim Ring

    fl ex out releasing the trim ring from the canopy. 42737-01 • 11/14/06 Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades.
  • Page 6 7 • Completing Your Installation With or Without a Light Fixture Your Hunter fan comes with an integrated light fi xture assembly and an optional switch housing cap and plug button. Th is feature gives you the option of installing the fan with OR without the included light fi xture.

  • Page 7: Operating And Cleaning Your Ceiling Fan

    8 • Operating and Cleaning Your Ceiling Fan 8-1. Turn on electrical power to the fan. 8-2. Th e fan pull chain controls power to the fan. Th e pull chain has four settings in sequence: High, Medium, Low and Off .
