For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE T Models
42749-01 • 05/04/07
Advertisement
Table of Contents
Related Manuals for Hunter 42749-01
Summary of Contents for Hunter 42749-01
- Page 1 Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. installation and operation manual for Hunter Ceiling Fans TYPE T Models 42749-01 • 05/04/07...
-
Page 2: Table Of Contents
• READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING INSTALLATION. SAVE THESE INSTRUCTIONS. • Use only Hunter replacement parts. • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions, and use only the hardware supplied. - Page 3 Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angle mounting. The steps in this manual include instructions for all three Installer’s Choice mounting methods.
-
Page 4: Getting Ready
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •... -
Page 5: Installing The Ceiling Plate
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 2 • Installing the Ceiling Plate 3” Wood Screw 42749-01 • 05/04/07 • Hunter Fan Company Isolator Ceiling Plate Step 2-2 Steps 2-3 –... -
Page 6: Assembling And Hanging The Fan
3-1. Unbundle the wires from the fan. For Standard or Angle mounting: 3-2. To assemble fan to hang down from a flat or angled ceiling, insert the downrod through the canopy and canopy trim ring. Feed the wires from the fan through the downrod. -
Page 7: Wiring The Fan
4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 4 • Wiring the Fan 42749-01 • 05/04/07 • Hunter Fan Company fsdfsdf Wire Connector... -
Page 8: Installing The Canopy And Canopy Trim Ring
2. Press firmly on opposite sides of the ring towards the canopy. The tabs will flex out releasing the trim ring from the canopy. Canopy Screw 42749-01 • 05/04/07 • Hunter Fan Company Step 5-2 Ceiling Plate Canopy Trim Canopy Ring Step 5-3 Steps 5-4 –... -
Page 9: Assembling The Blades
Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws. -
Page 10: Installing The Switch Housing
Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. Note: You can customize your Hunter fan with a number of accessory light kits. 7 • Installing the Switch Housing 42749-01 •... -
Page 11: Operating And Cleaning Your Ceiling Fan
8 • Operating and Cleaning Your Ceiling Fan 8-1. Turn on electrical power to the fan. 8-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings. -
Page 12: Troubleshooting
9 • Troubleshooting If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 42749-01 • 05/04/07 • Hunter Fan Company...
