Hunter 42753-01 Owner's Manual And Installation Manual

Type 3 models ceiling fan

Advertisement

Quick Links

For Your Records and
Warranty Assistance
For reference, also attach your receipt or a copy
of your receipt to the manual.
__________________________________________
Model Name
__________________________________________
Model No.
__________________________________________
Date Purchased
__________________________________________
Where Purchased
Form# 42753-01
20091230
©2009 Hunter Fan Co.
Type 3 Models
Type 3 Models
Type 3 Models
Owner's Guide and Installation Manual

Advertisement

Table of Contents
loading

Summary of Contents for Hunter 42753-01

  • Page 1 For reference, also attach your receipt or a copy of your receipt to the manual. __________________________________________ Model Name __________________________________________ Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form# 42753-01 20091230 ©2009 Hunter Fan Co. Type 3 Models Type 3 Models Type 3 Models Owner’s Guide and Installation Manual...
  • Page 2: Table Of Contents

    • READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING INSTALLATION. SAVE THESE INSTRUCTIONS. • Use only Hunter replacement parts. • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions, and use only the hardware supplied.
  • Page 3 Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angle mounting. The steps in this manual include instructions for all three Installer’s Choice mounting methods.
  • Page 4: Getting Ready

    • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...
  • Page 5: Installing The Ceiling Plate

    Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 42753-01 • 09/12/30 • Hunter Fan Company Isolator Ceiling Plate 3” Wood Screw...
  • Page 6: Assembling And Hanging The Fan

    3-1. Unbundle the wires from the fan. For Standard or Angle mounting: 3-2. To assemble fan to hang down from a flat or angled ceiling, insert the downrod through the canopy and canopy trim ring. Feed the wires from the fan through the downrod.
  • Page 7: Support System

    4-8. Return to the fan so you can complete the fan wiring. Steps 4-2 – 4-3 Steps 4-4 – 4-5 3mm (1/8") Support Brace Outlet Box Braided Ceiling Cable 42753-01 • 09/12/30 • Hunter Fan Company Step 4-1 Steps 4-6 – 4-7...
  • Page 8: Setting The Remote Transmitter And Receiver

    CAUTION: The remote control device complies with part 15 of the FCC rules. Changes or modifications not expressly approved by Hunter Fan Company could void your authority to operate this equipment. Operation is subject to the following two conditions: 1.
  • Page 9: Wiring The Fan

    6-5. Using the small wire connector, connect the wires from the fan as follows: • The black wire from the fan to the black wire from the receiver (marked on white tag “FAN”) • The white wire from the fan to the white wire from the receiver (marked on white tag “LIGHT AND FAN COMMON”)
  • Page 10: Installing The Canopy And Canopy Trim Ring

    2. Press firmly on opposite sides of the ring towards the canopy. The tabs will flex out releasing the trim ring from the canopy. 42753-01 • 09/12/30 • Hunter Fan Company Step 7-2 Canopy Steps 7-4 – 7-5 Canopy...
  • Page 11: Assembling The Blades

    Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 8-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 8-2. Attach each blade to a blade iron using three blade assembly screws.
  • Page 12: Completing Your Installation With Or

    9 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture.
  • Page 13 Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. 42753-01 • 09/12/30 • Hunter Fan Company Steps 9-6 – 9-7 Lower Switch...
  • Page 14 190 Watts. Exceeding that limit or the marked limit on this product may result in fire hazard or improper operation. 42753-01 • 09/12/30 • Hunter Fan Company Light Bulbs (B10 Candelabra Base 60 Watt Maximum)
  • Page 15 9-18. Once you have uninstalled the light fixture, continue with step 9-6. Male Dummy Terminal Female Dummy Terminal 42753-01 • 09/12/30 • Hunter Fan Company Lower Switch Threaded Rod Steps 9-13 – 9-15 Plug Button Housing Step 9-17...
  • Page 16: Operating The Remote Control And Mounting The Holder

    10-6. You can mount the remote holder to any toggle switch plate with the screws already in the switch plate. Or, you can simply mount the remote holder on the wall. 42753-01 • 09/12/30 • Hunter Fan Company Fan Speed High Fan Speed Steps 10-1 –...
  • Page 17: Operating And Cleaning Your Ceiling Fan

    11 • Operating and Cleaning Your Ceiling Fan 11-1. Turn on electrical power to the fan. 11-2. The power to the fan is controlled by the remote. The remote control has four settings in sequence: High, Medium, Low, and Off.
  • Page 18: Troubleshooting

    3. Check the plug connection in the switch housing. 4. Push motor reversing switch firmly left or right to ensure that the switch is engaged. 5. Push the fan speed buttons on the remote to ensure the fan is on. 6. Remove the shipping bumpers. Problem: Noisy operation.
