For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE T Models
42747-01 • 09/21/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 42747-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunter 42747-01

  • Page 1 Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. installation and operation manual for Hunter Ceiling Fans TYPE T Models 42747-01 • 09/21/07...
  • Page 2: Table Of Contents

    © 2007 Hunter Fan Company Welcome ® Your new Hunter ceiling fan is an addition to your home or office that will provide comfort and performance for many years. This installation and operation manual gives you complete instructions for installing and operating your fan.
  • Page 3 Ceiling Outlet Box Angled Mounting Style Angled Mounting recommended for a vaulted or angled ceiling 42747-01 • 09/21/07 • Hunter Fan Company Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include instructions for all three Installer’s Choice mounting methods. Considering Optional Accessories Consider using Hunter’s optional accessories, including a wall-mounted...
  • Page 4: Getting Ready

    Checking Your Fan Parts Carefully unpack your fan to avoid damage to the fan parts. Check for any shipping damage to the motor or fan blades. If one of the fan blades was damaged in shipment, return all the blades for replacement.
  • Page 5: Installing The Ceiling Plate

    2-1. Drill two pilot holes into the wood support structure through the outermost holes in the outlet box. The pilot holes should be 9/64” in diameter. 2-2. Your fan comes with four neoprene noise isolators (“Isolators”). Position the isolators between the ceiling plate and ceiling by inserting the raised areas on each isolator into the holes in the ceiling plate.
  • Page 6: Assembling And Hanging The Fan

    (steps 3-3 – 3-4). Note: For low profile mounting, the downrod is replaced with the low profile washer. 3-1. To assemble fan to hang down from a flat or angled ceiling, insert the downrod through the canopy and canopy trim ring. Feed the wires from the fan through the downrod.
  • Page 7: Wiring The Fan

    4-3. Connect the bare or green ground wired (grounded) from the ceiling to the green ground wire (grounded) from the ceiling plate and the green ground wire from the fan. 4-4. Connect the white wire (ungrounded) from the ceiling to the white wired (ungrounded) from the fan.
  • Page 8: Installing The Canopy And Canopy Trim Ring

    Ceiling Plate Canopy Trim Canopy Ring Step 5-3 Steps 5-4 – 5-5 42747-01 • 09/21/07 • Hunter Fan Company 5-1. Holding the canopy, raise the fan off the hook. 5-2. Align the slots in the canopy with the tabs on the ceiling plate. 5-3. Raise the canopy over the ceiling plate. Rotate the canopy clockwise until the tabs on the ceiling plate totally engage with the slots in the canopy. 5-4. Partially install the three canopy screws into the canopy one at a time.
  • Page 9: Assembling The Blades

    Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws. If you used grommets, the blades may appear slightly loose after screws are tightened.
  • Page 10: Installing The Switch Housing

    Assembly Switch Screw Housing Lower Switch Housing Step 7-4 42747-01 • 09/21/07 • Hunter Fan Company 7-1. To attach the upper switch housing, partially install two #6-32 x 3/8” housing assembly screws into the switch housing mounting plate. 7-2. Align the keyhole slots in the housing with the housing assembly screws. 7-3. Turn the housing counterclockwise until the housing assembly screws are firmly situated in the narrow end of the keyhole slots.
  • Page 11: Operating And Cleaning Your Ceiling Fan

    8 • Operating and Cleaning Your Ceiling Fan 8-1. Turn on electrical power to the fan. 8-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings. • Release slowly to prevent the chain from recoiling into the blades. • The chain uses a breakaway connector that separates if the chain is jerked. If this happens, simply reinsert the chain into the connector.
  • Page 12 Hunter ceiling fan! With this purchase, you are doing your part to protect the environment. In 2010, ENERGY STAR qualified ceiling fans are projected to cut air pollution by more than 500 million pounds! Your new ceiling fan has earned the ENERGY STAR label because it meets high energy efficiency specifications set by the Environmental Protection Agency (EPA). ENERGY STAR labeled ceiling fans save energy because they have more efficient fan motors and air delivery due to more aerodynamic blade configurations. Ceiling fan models bearing the ENERGY STAR label move air 14 - 20% more efficiently than typical ceiling fan models. For more information on ENERGY STAR visit www.energystar.gov. 42747-01 • 09/21/07 • Hunter Fan Company...
  • Page 13: Troubleshooting

    6. Check and tighten the screws in the switch housing mounting plate and in the upper and lower switch housing. Problem: Excessive wobbling. 1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade and/or blade iron screws.
