Page 3
Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include instructions for all three Installer’s Choice mounting methods.
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 42783-01 • 08/19/09 • Hunter Fan Company Isolator Ceiling Plate 3” Wood Screw...
3-1. Unbundle the wires from the fan. For Standard or Angled mounting: 3-2. To assemble fan to hang down from a flat or angled ceiling, insert the downrod through the canopy and canopy trim ring. Feed the wires from the fan through the downrod.
4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42783-01 • 08/19/09 • Hunter Fan Company 4 • Wiring the Fan fsdfsdf...
2. Press firmly on opposite sides of the ring toward the canopy. The tabs will flex out releasing the trim ring from the canopy. 42783-01 • 08/19/09 • Hunter Fan Company Step 5-2 Canopy Steps 5-4 – 5-5 Canopy...
Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws.
7 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture.
Page 11
190 Watts. Exceeding that limit or the marked limit on this product may result in fire hazard or improper operation. 42783-01 • 08/19/09 • Hunter Fan Company Steps 7-6 – 7-7 Lower Switch Housing...
Page 12
7-8. First install B10 candelabra bulbs (60 Watt Maximum) into the sockets. 7-9. Thread the light and fan pull chains through the hole in the center of the glass bowl. Then, thread the light pull chain through the hole in the center of the cover plate.
Page 13
7-21. Once you have uninstalled the light fixture, continue with Step 7-6. Male Dummy Terminal Female Dummy Terminal 42783-01 • 08/19/09 • Hunter Fan Company Lower Switch Threaded Rod Steps 7-17 – 7-19 Plug Button Housing Step 7-21...
8 • Operating and Cleaning Your Ceiling Fan 8-1. Turn on electrical power to the fan. 8-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings.
Problem: Lights shut off suddenly 1. Turn the power to the fan off at the wall switch. Wait 30 seconds, then resume power to the fan. 42783-01 • 08/19/09 • Hunter Fan Company 9 •...
