For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: _______________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
42701-01 • 01/25/06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hunter 42701-01
Summary of Contents for Hunter 42701-01
- Page 1 For Your Records and Warranty Assistance Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: _______________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. 42701-01 • 01/25/06...
-
Page 2: Table Of Contents
• Read this entire manual carefully before beginning installation. Save these instructions. • Use only Hunter replacement parts. • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions, and use only the hardware supplied. - Page 3 Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation fl exibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profi le, Standard, or Angle mounting. e steps in this manual include instructions for all three Installer’s Choice mounting methods.
-
Page 4: Getting Ready
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •... -
Page 5: Installing The Ceiling Plate
CAUTION: To avoid possible electrical shock, before installing your fan, disconnect the power by turning off the circuit breakers to the outlet box and associated wall switch location. If you cannot lock the circuit breakers in the off position, securely fasten a prominent warning device, such as a tag, to the service panel. -
Page 6: Assembling And Hanging The Fan
3-1. Unbundle the wires from the fan. For Standard or Angle mounting: 3-2. To assemble fan to hang down from a flat or angled ceiling, insert the downrod through the canopy. Feed the wires from the fan Canopy through the downrod. -
Page 7: Wiring The Fan
• e white wire from the ceiling to the white wire from the fan • e black wire from the ceiling to the black and the black/white wire from the fan 4-2. -
Page 8: Installing The Canopy
Steps 5-1– 5-3 Mounting Screw Hunter Fan Company 5-1. Holding the canopy, raise the fan off the hook. 5-2. Align the holes in the canopy with the mounting holes on the ceiling plate. 5-3. Insert and tighten the mounting screws securely. -
Page 9: Assembling The Blades
Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws. -
Page 10: Operating And Cleaning Your Ceiling Fan
Ceiling fans work best by blowing air downward (counterclockwise blade rotation) in warm weather to cool the room with a direct breeze. In cold weather, having the fan draw air upward (clockwise blade rotation) will distribute the warmer air trapped at the ceiling around the room without causing a draft. -
Page 11: Troubleshooting
1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade iron screws. 3. Turn power off , support fan very carefully, and check that the hanger ball is properly seated. If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com.
