Change for Life
Split Air Conditioner
Owner's Manual
Residential Air Conditioners
Thank you for choosing Residential
manual carefully before operation and retain it for future reference.
MODEL:
GWH09TB-D3DNA1A
GWH12TB-D3DNA1A
GWH18TC-D3DNA1A
GWH24TD-D3DNA1A
Air Conditioners, please read this owner's
Advertisement
Table of Contents
Related Manuals for Gree GWH09TB-D3DNA1A
Summary of Contents for Gree GWH09TB-D3DNA1A
- Page 1 Change for Life Split Air Conditioner Owner's Manual Residential Air Conditioners MODEL: GWH09TB-D3DNA1A GWH12TB-D3DNA1A GWH18TC-D3DNA1A GWH24TD-D3DNA1A Thank you for choosing Residential Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS ■ ..............Safety Precautions ..............■ Name of Parts ........■ Operation of wireless remote controller ■ ............Emergency Operation ■ .............. Care and Cleaning ■ Troubleshooting ..............■ ..............Operation Tips Never attempt. Be sure to follow this instruction The physical product may differ from the drawing in this manual for different display. -
Page 3: Safety Precautions
If the power cord or ediately and then contact with signal control wire of air Gree authorized maintenance conditioner is damaged,please center. replace it by the professional with specified power cord. - Page 4 Safety Precautions Select the most appropriate For safety, be sure to turn ★ ★ ★ Always ensure effective off the circuit beaker before temperature. earthing. performing any maintenance or cleaning or when the product is not used for an extended period of time. Keep room about ℃...
- Page 5 Safety Precautions ★ ★ To change the airflow direction, adjust the vertical Do not cut off or damage the power cords or control cords. If they are damaged, please and horizontal air flow direction by using the contact the dealer or qualified service remote controller.
-
Page 6: Name Of Parts
Name of Parts Indoor unit Air in ⑵ ⑷ ⑹ ⑸ ⑶ Air out The icons displayed: ：Cool ⑴ ：Dry ：Heat Power ⑴ ： Remote controller ：Set temp. ⑵ Front panel ⑶ Filter ⑷ Horizontal louver Outdoor unit ⑸ Wall pipe ⑹... -
Page 7: Operation Of Wireless Remote Controller
Operation of wireless remote controller Name and function of wireless remote controller Note: Besure that there are no obstructions between receiver and remote controller; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. -
Page 8: Remote Controller
Operation of wireless remote controller Name and function of wireless remote controller Note: Besure that there are no obstructions between receiver and remote controller; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. -
Page 9: Name/Function Of Wireless Remote Controller
Operation of wireless remote controller Name and function of wireless remote controller This wireless remote control is universal, and it could be used for many units, some buttons of this control which are not available to this unit will not be described below. TIMER ON TIMER ON BUTTON Timer On sett ing : Sign al “ON”... - Page 10 Operation of wireless remote controller Name and function of wireless remote controller Press this button, can select Sleep 1 ( ), Sleep 2 ( ● Sleep 3 ( ) and cancel the Sleep, circulate between these, after electrified, Sleep Cancel is defaulted. Sleep 1 is Sleep mode 1, in Cool, Dehumidify modes: sleep status ●...
- Page 11 Operation of wireless remote controller Name and function of wireless remote controller (3) Under the initial presetting temperature 69 F～81 F, after Sleep function started up, the temperature will decrease 1 F ～2 F in every hour, after 1 F ～2 F decreased, this temperature will be maintained.
- Page 12 Operation of wireless remote controller Guide for operation- general operation 1. After powered on, press ON/OFF button, the unit will start to run. (Note: When it is powered on, the guide louver of main unit will close automatically.) 2. Press MODE button, select desired running mode. 3.
- Page 13 Operation of wireless remote controller ★ About lock Press buttons simultaneously to lock or unlock the keyboard. If the remote controller is locked, the icon will be displayed on it, in which case, press any button, the mark will flicker for three times. If the keyboard is unlocked, the mark will disappear. ★...
-
Page 14: Changing Batteries And Notices
Operation of wireless remote controller Changing batteries and notices 1.Slightly to press the place with , along the arrowhead direction to push the back cover of wireless remote controller. (As show in Fig 1. ) 2.Take out the old batteries. 3.Insert two new AAA1.5V dry batteries, and pay attention to the polarity. -
Page 15: Emergency Operation
Emergency Operation Emergency Operation When the remote controller is lost or damaged, please use the manual switch on the main unit. In that case, the unit will operate in AUTO mode and the temperature setting or fan speed can not be changed. The manual switch can be operated as below: Manual switch Turn on the unit: Press AUTO/STOP button to... -
Page 16: Care And Cleaning
Care and Cleaning Caution ● Disconnect the power supply before cleaning and maintenance. ● Do not splash water on the units for cleaning, as electric shocks may occur. ● Wipe the units with a dry soft cloth, or a cloth slightly moistened with water or cleaner (not with volatile liquid such as thinner or gasoline). - Page 17 Care and Cleaning Check before Use ① Be sure that nothing obstructs the air outlet and inlet. ② Check if the batteries of remote controller are replaced. Check if the installation stand of the outdoor unit is damaged. ③ If damaged, consult the technicians. Maintenance after Use ①...
-
Page 18: Troubleshooting
Troubleshooting CAUTION The air conditioner is not user serviceable.Incorrect repair may cause electric shock or fire so please contact an authorized service center for professional repair. Following checks prior to contact may save your time and money. Phenomenon Troubleshooting The unit does not operate: The unit does not operate if it is turned on ●... - Page 19 Troubleshooting Phenomenon Troubleshooting Is the power cut off? ● The unit can not be started up: Is the circuit protection device tripped off? ● Is voltage higher or lower? ● (Tested by professionals) Breaking off Is the TIMER correctly used? ●...
- Page 20 Troubleshooting Phenomenon Troubleshooting Indoor unit can not blow air: In HEAT mode, when the temperature of indoor ● heat exchanger is very low, air flow is stopped in order to prevent cold air. (Within 2 minutes) ● In HEAT mode, when the outdoor temperature is low or humidity is high, frost will be formed on the outdoor heat exchanger.
-
Page 21: Operation Tips
Operation Tips Cooling Operation Principle: Air conditioners absorb heat in the room and transmit it to the outdoor unit, so that the room temperature is decreased. The cooling capacity will increase or decrease according to outdoor ambient temperature. Antifreezing Function: If the unit is operating in COOL mode and in low ambient temperature, frost may be formed on the heat exchanger. -
Page 22: Tips For Energy Saving
Operation Tips Tips for energy saving: Do not overcool or overheat . Setting temperature at a moderate level helps energy saving. Cover windows with a blind or a curtain. Blocking sunlight and air from outdoors is favorable for cooling (heating). Clean air filters once per two weeks. - Page 23 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com 66162853...
