  • Page 1 VOOK DVR USER MANUAL For 24 and 32-channel digital video recorder All rights reserved VOOK professional monitoring...
  • Page 2  Do not power off the DVR when the device is function. The correct procedure to shut down DVR is to stop recording firstly, and then use “shut down” button from the menu, and finally switching off the main power.

  • Page 3: Table Of Contents

    VOOK Table of Contents 1 Introduction ..............................1 1.1 DVR Introduction ..................................1 1.2 Main Features..................................1 2 Hardware Installation ............................. 4 2.1 Install Hard Drive &DVD Writer ..............................4 2.1.1 Install Hard Drive ........................................4 2.1.2 Install DVD ..........................................6 2.2 Front Panel Descriptions .................................
  • Page 4 4.5.1 Sensor ..........................................29 4.5.2 Motion ..........................................30 4.5.3 Video loss ........................................... 32 4.5.4 Other alarm ......................................... 33 4.5.5 Alarm out ..........................................34 4.6 Network configuration ................................34 4.6.1 Network ..........................................34 4.6.2 Sub stream.......................................... 35 4.6.3 Email ........................................... 36 VOOK professional monitoring...
  • Page 5 5.2 Event search..................................47 5.3 File management ................................... 48 5.4 Image ....................................49 5.5 Backup ....................................49 6 Manage DVR ............................... 51 6.1 Check system information ..............................51 6.1.1 System information ......................................51 6.1.2 Event information ........................................ 51 6.1.3 Log information ........................................51 6.1.4 Network information ......................................
  • Page 6 8.5.1 Installation instruction for BlackBerry Mobile phone Client ..........................87 8.5.2 Operation method for Blackberry mobile phone client ............................89 Appendix A FAQ…..................................92 Appendix B Calculate Recording Capacity..........................99 Appendix C Compatible Devices............................100 Appendix D 24-CH DVR Specifications..........................101 Appendix D 32-CH DVR Specifications..........................102 VOOK professional monitoring...

  • Page 7: Introduction

    1.1 DVR Introduction This model of DVR (Digital Video Recorder) is designed for high performance CCTV solutions. It adopts state of the art video processing chips and embedded Linux system. Meanwhile, it utilizes most advanced technologies, such as standard H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote control, mobile view(by phones), etc., ensuring powerful functions and high stability.
  • Page 8 • Support 128 PTZ presets and 8 auto cruise tracks • Support remote PTZ control through internet SECURITY • Customize user right: log search, system setup, two way audio, file management, disk management, remote login, live view, VOOK professional monitoring...
  • Page 9 Support remote time and event search, and channel playback with picture snap • Support remote PTZ control with preset and auto cruise • Support remote full menu setup, changing all the DVR parameters remotely • Support mobile surveillance by smart phones , symbian, WinCE, Iphone or Gphone, 3G network available •...

  • Page 10: Hardware Installation

    VOOK 2 Hardware Installation Notice: Check the unit and the accessories after getting the DVR. Please disconnect the power before being connected to other devices. Don't hot plug in/out 2.1 Install Hard Drive &DVD Writer 2.1.1 Install Hard Drive Notice: 1. This series support four SATA hard drives or support three SATA hard drives plus one DVD writer. (User can also choose to install eight SATA hard drives or four SATA hard drives plus one DVD writer.
  • Page 11 Install other three HDD according to above-mentioned method. Then cover the upper iron bar and screw it firmly. Put the Step 3: HDD under it and screw firmly as shown below: Step 4: Install other three HDD under the upper iron bar as shown below: VOOK professional monitoring...

  • Page 12: Install Dvd

    Step 3: Connect the power and data cables and install the upper iron bar. Then, screw firmly with screws in the both sides. Note: If the user installs a DVD, he can only install 4 HDD disks due to the too much room taken up. VOOK professional monitoring...

  • Page 13: Front Panel Descriptions

    When access to network , the light is blue indicator Play When playing video, the light is blue Power Power indicator, when connection , the light is blue MENU Enter menu in live INFO Check recording data VOOK professional monitoring...

  • Page 14: Rear Panel Instructions

    Control rewind/fast forward/frame when playing the image. To connect external USB devices like USB flash, USB HDD for USB port backup or update firmware; or connect to USB mouse Rear Panel Instructions Fig2.1 Rear Panel for 24-Channel VOOK professional monitoring...
  • Page 15 Fig 2.2 Rear Panel for 32-Channel Item Name Description Video out Connect to monitor Video input channels(from 1-24 for 24-ch DVR/ 1-32 for Video in 32-ch DVR) POWER INPUT AC 110Vor 110V Connect to monitor as an AUX output channel by channel.

  • Page 16: Remote Controller

    2. Check the remaining charge in the batteries 3. Check IR controller sensor is mask If it still doesn't work, Please change a new remote controller to try, or contact your dealers The interface of remote controller is shown in Fig2.3Remote Controller. VOOK professional monitoring...
  • Page 17 Name Function Power Button Soft switch off to stop firmware running. Do it before power off. INFOR Button Get information about the DVR like firmware version, HDD information REC Button To record manually Digital Button Input digital or choose camera...

  • Page 18: Control With Mouse

    Operation processes with remote controller to control multi-DVR The device ID of the DVR is 0. It’s not necessary to reset the device ID when a remote is to be used to control a single DVR. However when controlling multiple DVR with multiple remote controllers, the user would need to configure the device ID, please...

  • Page 19: Use Mouse

    In backup: Click left button to choose the options. Click right button to return to previous picture. In PTZ control: Click left button to choose the buttons to control the PTZ. Click right button to return to live. Notice: Mouse is the default tool in all the operation below unless Exceptional indication. VOOK professional monitoring...

  • Page 20: Basic Function Instruction

    By keyboard and mouse: Menu  select “System Shut Down” icon. Then the Shut down window will appear. Step1: enter into Step2: after clicking OK, the unit will power off after a while. Step3: disconnect the power. VOOK professional monitoring...

  • Page 21: Login

    VOOK 3.2 Login User can login and logout the DVR system. User cannot do any other operations except changing the multi-screen display once logout. Fig 3-1 Login Notice: the default user name and password is “admin” and 123456. The concrete operation steps for change password, add or delete user please refer to User management configuration for more details.

  • Page 22: Live Playback

    VOOK 3.3.1 Live playback Click Play button to playback the record. Refer to Figure3-3. User can do concrete operation by click the buttons on screen. Fig 3-3 live playback VOOK professional monitoring...

  • Page 23: Main Menu Setup Guide

    Record: Click this button, user can start manual record. Playback: Click this button, the device can playback the record files. User can click button and drag the tool bar anywhere on screen display with the left mouse. Click Menu button to VOOK professional monitoring...

  • Page 24: Basic Configuration

    Device name: the name of the device. It may display on the client end or CMS that help user to recognize the device remotely. Video format: two modes: PAL and NTSC. User can select the video format according to the camera. Fig 4-3 basic configuration-basic VOOK professional monitoring...

  • Page 25: Time & Date

    Step2: set the date format, time format, time zone in this interface; tick off “sync time with NTP server” to refresh NTP server date; user also can adjust system date manually Fig 4-4 basic configuration-time & date VOOK professional monitoring...

  • Page 26: Dst

    User can self-define the camera name. Click Shift button, user can input Capital letters; click Shift button again, user can input Chinese characters. Step2: tick off camera name; click “setting” button, a window will pop-up as Fig 4-7: Fig 4-6 live configurationlive VOOK professional monitoring...

  • Page 27: Main Monitor

    Step4: while selecting the split mode, user can setup the current picture group. Click button to setup the previous channel groups of dwell picture and click button to set the latter channel groups of dwell picture. Fig 4-8 live configuration-host monitor VOOK professional monitoring...

  • Page 28: Spot

    Click Apply button to save the setting. Delete mask area: select a certain mask area and left click to delete that mask area. Then click Apply button to save the setting. Fig 4-10 live configuration-mask VOOK professional monitoring...

  • Page 29: Record Configuration

    Step2: tick off record, audio and record time Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup. Parameter Meaning Record Record switch every channels Audio Enable live record audio Fig 4-11 record configuration-enable VOOK professional monitoring...

  • Page 30: Record Stream

    Range from: 64 Kbps, 128 Kbps, 256 Kbps, 512 Kbps, 768 Kbps, 1Mbps, 2 Mbps 4.3.3 Time Step1: enter into system configurationrecord configuration time; refer to Fig 4-13: Pre-alarm record time: the record time before event happen i.e. record time before motion detection or sensor alarm is triggered. VOOK professional monitoring...

  • Page 31: Stamp

    User can use cursor to drag the camera name and time stamp in random positions, referring to below Figures: Step3: user can setup all channels with same parameters. Tick off “all” to do relevant setup. Fig 4-14 record configuration-stamp VOOK professional monitoring...

  • Page 32: Recycle Record

    The volume means the seven days of a week from Monday to Sunday, the row means 24 hours of a day. Click the grid to do relevant setup. Blue means checked area and gray means unchecked area. Step1: enter into system configurationschedule configurationschedule; referring to Fig 4-15: VOOK professional monitoring...

  • Page 33: Motion

    ② If user wants to apply the schedule setting of certain channel to other or all channels, just only select channel and click “Copy” button. 4.4.2 Motion Step1: enter into system configurationschedule configurationmotion; refer to Fig 4-17: Step2: the setup steps of motion are familiar with schedule; user can refer to 4.4.1 Schedule for details. VOOK professional monitoring...

  • Page 34: Sensor

    Note: the default schedule of sensor is full-selected, that is, the color of schedule setting interface is blue. Fig 4-18 schedule configuration-sensor 4.5 Alarm configuration Alarm configuration includes five sub menus: sensor, motion, video loss, other alarm and alarm out. VOOK professional monitoring...

  • Page 35: Sensor

    Alarm handling Step1: enter into system configurationalarm configurationsensoralarm handling; referring to Fig 4-20: Step2: select hold time and click Trigger to display a screen as shown in Fig 4-21: Fig 4-20 alarm configuration-sensor-alarm handling Fig 4-21 alarm handling-trigger VOOK professional monitoring...

  • Page 36: Motion

    Note: the default schedule of sensor is full-selected, that is, the color of schedule setting interface is blue. Fig 4-22 sensor-schedule 4.5.2 Motion Motion includes two sub menus: motion and schedule. ① Motion Step 1: enter into system configurationalarm configurationmotion; refer to Fig 4-23: VOOK professional monitoring...
  • Page 37 Click icon to save the setting; click icon to exit current interface. VOOK professional monitoring...

  • Page 38: Video Loss

    Step 1: enter into system configurationalarm configurationvideo loss; refer to Fig 4-26: Step 2: the setup steps of video loss trigger are familiar with alarm handling; user can refer to Chapter 4.5.1 Sensor alarm handling for more details. Step 3: user can setup all channels with same parameters. VOOK professional monitoring...

  • Page 39: Other Alarm

    Fig4-27 other alarm corresponding function. Step 2: select a hard disk in the pull down list box. When the disk capacity is lower than that value, there will appear some text VOOK professional monitoring...

  • Page 40: Alarm Out

    Step 2: HTTP port: the default value is 80. If the value changed, user needs to add the port number when typing IP address in IE address blank .i.e. set HTTP port to 82, IP address: http://192.168.0.25, user needs to input that address: http://192.168.0.25:82 into IE browser. VOOK professional monitoring...

  • Page 41: Sub Stream

    IP address, subnet mask, and gateway IP and DNS server. Step 4: enable PPPoE to directly connect the DVR to internet via ADSL, and then input the user name and password. Next, click TEST button to test the effectiveness of the relevant information.

  • Page 42: Email

    Receive address: receiver’s email address. Here user can add at least three mail addresses. Click TEST button to test the validity of the mailbox. Attaching image: After selecting it, the system will attach images when sending the emails. Fig 4-31 network configuration-email VOOK professional monitoring...

  • Page 43: Other Settings

    Fig 4-32 network configuration-other settings Enable UPnP: User may select UPnP and then enable UPnP function in the user’s router. Then user can access DVR through WAN. When accessing the DVR through IE, user can check the IP address by the following method: Double-click the “My Network Places”...
  • Page 44 1． Domain name Registration （Take www.dyndns.com for example） Note: Users can self-define the hostname, username and password. Input www.dyndns.com address bar, user access domain name registration interface. Click” ””Create Free Hostname” to register. For example: Hostname is “abc.dyndns.tv. The picture is shown as follows: VOOK professional monitoring...
  • Page 45 Next, create user account. For example, the username is “bcd”, password is “123456”. Click” Create Account” button to create user account. 2． DVR Setting （1） Domain name According to the domain name registration of “DDNS”，the domain name for DVR is “abc.dyndns.tv” VOOK professional monitoring...

  • Page 46: User Management Configuration

    Click Save button to save the setting ③ Login IE browser and input registered domain name “http://www.abc.dyndns.tv”, connect to DVR client. If the value changed, user needs to add the port number when typing IP address in IE address blank .i.e. set HTTP port to 82, IP address: http://192.168.0.25, user needs to input that address: http://192.168.0.25:82 into IE browser.
  • Page 47 Note: when the default value of binding PC MAC address is 0, the user is not bind with the specify computer; the, the user can log in DVR on the binding computer after set the specific binding MAC address. ②...

  • Page 48: Configuration

    PELCOD, LILIN, MINKING, NEON, STAR, VIDO, DSCP, VISCA, SAMSUNG, RM110, HY, N-control. ③ Advance Step 1: enter into system configuration P.T.Z configurationadvance; refer to Fig 4-37: Step 2: in the Advance interface, click preset “Setting” button to see a dialog box as Fig 4-38: VOOK professional monitoring...
  • Page 49 OK button to save the setting; click Exit button to exit current interface. Step 3: in the Advance interface, while clicking cruise “Setting” button, a dialog box will pop-up as Fig 4-40: VOOK professional monitoring...
  • Page 50 OK button to save the setting; click Exit button to exit current interface. Step4: in the Advance interface, while clicking track “Setting” button, a dialog box will pop-up as Fig 4-42: Fig 4-42 track setting Fig 4-41 cruise set-modify cruise line VOOK professional monitoring...

  • Page 51: Advanced

    Here authorized user can prohibit computer users within a certain IP address segment from accessing to DVR or admit computer users within a certain IP address segment into DVR. For example, if authorized user don’t want computer users within IP address segment from 196.168.000.002 to 196.168.000.004 to access to DVR, authorized user can tick off Block list, and then input such IP address segment.

  • Page 52: Record Search & Playback And Backup

    Step 3: Use the grid on the left hand side to identify the presence of data as per the required time. Blue patches indicate presence of data. This can be selected by clicking a particular grid or by entering the specific value in the time field. VOOK professional monitoring...

  • Page 53: Event Search

    Note: when the monitor resolution is VGA800*600, the time search interface will appear a hide button, click this button, the whole interface can be expanded. 5.2 Event search Step 1: enter into Search configurationevent search; refer to Fig 5-2: Fig 5-2 Search configuration-event search VOOK professional monitoring...

  • Page 54: File Management

    Step 2: After clicking Search, the searched files will be displayed in the file list box; user can select date and channels accordingly. Lock: select a file and click Lock button to lock this file, after that, that file will not be deleted or covered. Unlock: select a locked file and click Lock button to unlock this file VOOK professional monitoring...

  • Page 55: Image

    Step 4: in the backup information interface, user can check the relevant information of backup files, storage type, save file type, etc. click Start button to starting backup. Note: when the monitor resolution is VGA800*600, the file management interface will appear a hide button. Click this button to expand the whole interface. VOOK professional monitoring...
  • Page 56 VOOK Fig 5-4 backup configuration VOOK professional monitoring...

  • Page 57: Manage Dvr

    VOOK 6 Manage DVR 6.1 Check system information Check system information includes five submenus: system, event, log, network and online user. 6.1.1 System information In this interface, user can check the hardware version, MCU version, kernel version, device ID, etc.

  • Page 58: Disk Management

    At present, it only supports USB update. Get the software from your vendor when there is a new software version, and make sure it is corresponding with the DVR. User can check the USB information in Disk management. Upgrade method: the user needs to copy the upgrade software which gets from vendor into the USB storage device and then connect it to the USB port.

  • Page 59: Remote Surveillance

    Step 2: Enter Record Setup to set network video parameters like resolution, frame rate etc. Step 3: Open IE on a computer on the same network. Input the IP address of the DVR in IE address bar and press enter.
  • Page 60 ISP. Next, click ‘Apply’. The DVR will connect to the server and would give a confirmation message. Step 2: When accessing the remote interface of DVR, user can input WAN IP to access directly (user can enter into Main menuInformationNetwork interface to check IP address).

  • Page 61: Remote Surveillance Through Apple Pc

    If the browser is the earlier MACOS version, the default setting is 32-bit mode and the setting can be skipped. The Setting steps are as follows: First: Right click safari icon and select “Show in Finder”. Second: Select ApplicationsRight click “Safari. App”Select “Get Info”. Third: Select “open in 32- bit mode”. VOOK professional monitoring...

  • Page 62: On Lan

    VOOK 7.2.1 On LAN Step 1: After starting Apple computer, click icon. The following window will pop up. Please select “System Preferences””Internet &Wireless”click “Network” VOOK professional monitoring...
  • Page 63 Step 2: Enter into Network interface and then click “Ethernet Connected” to check the internet connection of Apple PC. Step 3: After acquiring the IP address, Subnet Mask and so on, please enter into the DVR’s Main MenuSetupNetwork interface to manually input IP address, Subnet Mask and Gateway according to the configuration of PC. The network segment should be the same as the PC.

  • Page 64: On Wan

    DVR. 7.2.2 On WAN There are also two ways for DVR to connect to Internet. 1. Connect the DVR to internet through router or virtual server Step 1: The network setups are the same as step one to step four of point 1 on WAN of IE remote surveillance.

  • Page 65: The Remote Live Preview Interface

    Snap pictures Click “Snap” icon, the system will automatically capture pictures and save those pictures in the computer. User should set up the save path for those picture in the Remote Preview interfaceConfigurationLocal configuration. Color adjustment: VOOK professional monitoring...
  • Page 66 Drag the scroll bar to adjust rotating speed of the dome. 'Iris' button. Click button near 'Iris' button to increase light of the dome. Click button near 'Iris' button to decrease light of the dome. VOOK professional monitoring...
  • Page 67 Light button When clicking the right mouse on the live interface, a pull-down menu will appear as below Stream: this DVR supports master stream and sub stream. Master stream has higher frame rate, max 25FPS （PAL） /30 FP（NTSC）for every channel, but it needs higher network bandwidth simultaneously;...

  • Page 68: Remote Playback & Backup

    Fig 7-4: Select the record date and channels; double-click the file name in the file list box, user can play that file and preview the picture. Fig 7-4 Play record file interface VOOK professional monitoring...
  • Page 69 VOOK This DVR supports remote time search, event search and file management. By Time Search: Step1: Enter into Searchtime search; refer to Fig 7-5: Fig 7-5 time search interface Step2: click “Search” button. The record data will be displayed in the data information list box; the highlight date in the area②...
  • Page 70 VOOK research, etc. refer to Fig 7-6: Fig 7-6 Time search playback By Event Search: Step1: Enter into Searchevent search; refer to Fig 7-7: VOOK professional monitoring...
  • Page 71 Step2: click the highlight date, select record channels and then tick off the event type: motion and sensor, click “search” button Step3: the events will be display in the event list box. Double-click a certain item to playback. VOOK professional monitoring...
  • Page 72 Lock: select certain file item in the file list box and click “Lock” button to lock this file that ca not be deleted or overlaid Unlock: select a locked file and click “unlock” button to unlock this file Delete: select an unlock file and click “delete” button to delete this file from file list VOOK professional monitoring...

  • Page 73: Remote Backup

    Step1: select channels, set the start and end time, and then click “search’ button. The file information will be displayed in the file list Step2: select backup files, click “browse” button to set the save path, and then click “backup” button to start backup. The backup files will be saved on user’s PC. VOOK professional monitoring...

  • Page 74: Remote System Configuration

    Click Config to enter into the below interface refer to Fig 7-10: Fig 7-10 remote menu setup The sub menu lists and the options in every item are similar with those on the DVR. Please refer to Chapter 3 Main Menu Setup Guide for more details.

  • Page 75: Remote Management

    IP address and so on. Enter into INFO→Log, user can set the start time to view the log record as follows: Fig 7-11 Remote information search Note: There may be subtle differences with respect to functions of remote surveillance between through IE and through Apple PC. Here we only take IE remote access for example. VOOK professional monitoring...

  • Page 76: Mobile Surveillance

    This DVR supports mobile surveillance by Iphone, Gphone，blackberry or smart phones with Windows mobile and symbian OS. At the same time, it supports 3G network. We tested Dopod D600 (WM5) and Dopod S1 (WM6), which work fine with the DVR.

  • Page 77: By Phones With Symbian

    Notice: User name password here are the same with that used on the DVR. The default is admin and 123456. 8.2 By Phones with Symbian Please use the smart phones with symbian version supported by this unit. The detail information is as follows:...
  • Page 78 Step1：Firstly enable the network access on mobile phone. Then run Web browser. Step2：Input the DVR server’s IP address in a new-built bookmark. Click this bookmark to connect to the DVR. Refer picture in the left: Step3：A welcome window will pop up and requires a package. Click the software name to download. Refer picture in the right: Step4：A security windows will pop up after downloading and ask if install the package.
  • Page 79 Step9：Enter Live View, it will connect the server and display pictures. Refer picture in the left: Notice: User name and password here are the same with that used on the DVR. The default is admin and 123456. Step10：In Live View, users can do snapshot, change channels and control PTZ. Refer picture in the right:...

  • Page 80: The Software Installation For Iphone Mobile Clients

    1. Install through iphone. Step 1. Open App Store function of iphone Step 2. Enable “search” function to search “SuperCam” Step 3: Click SuperCam, enter into “introduce” interface and then click “FREE”. It will change into “INSTALL” VOOK professional monitoring...
  • Page 81 Note: if it was the first time for user to operate, please enter user ID; if there is no Store account, user needs to apply one. 2. Install through PC. Step 1: Install iTunes store in PC and then login Step 2: Connect iPhone and PC VOOK professional monitoring...
  • Page 82 Step 3: Enable “search” function to search “SuperCam” Step 4: Click “free application” button Step 5: Input apple ID and password, then click “acquire” Step 6: Tick off “synchronously apply program” and “SuperCam”, and then click “apply” button VOOK professional monitoring...
  • Page 83 【Image】 image view 【Log】 log record 【Server List】 device list 【Live】 live view 【Settings】 software setting 【Information】 device information view 【Help】 software help center 【Logoff】 logoff and return to login interface Live View Interface VOOK professional monitoring...
  • Page 84 Rightward rotates the PTZ Stop rotating the PTZ Zoom In/Focus In/Iris Add Zoom Out/Focus Out/Iris Sub Preset elect the preset point Group Set the cruise line Speed Rotate speed of the PTZ H-Reverse Horizontal- Reverse V-Reverse Vertical- Reverse VOOK professional monitoring...
  • Page 85 Record Playback interface, refer below picture in the right: Click the record file to playback. Server list Interface, refer to below picture in the left: Config interface, refer to below picture in the right: Main parameters for mobile phone video config VOOK professional monitoring...

  • Page 86: The Installation & Operation Methods For Android Mobile Clients

    Remember display order: User can choose whether to remember display order or not. Alarm config：Select Audio Alarm. When Video Loss/Sensor/Motion happens，trigger sound alarm. Select shake Alarm. When Video Loss/Sensor/Motion happens，trigger vibrate alarm. Information View Interface 8.4 The installation & operation methods for Android mobile clients Software Installation VOOK professional monitoring...
  • Page 87 VOOK Step 1: run Google Market program Step 2: search”SuperCam” Step 3: press “Install” button Step 4: click “OK” button VOOK professional monitoring...
  • Page 88 Step 5: user can view the download and install process in notifications. Finished downloading, the software will install automatically. Login Enter into server’s IP address (or domain name), user’s ID and password. Click “Remember server” to save the setting; click button can quick input saved server address, user name and password. Main menu VOOK professional monitoring...
  • Page 89 【Log】 log record 【Server List】 device list 【Live】 live view 【Settings】 software setting 【Information】 device information view 【Help】 software help center 【Logoff】 logoff and return to login interface Live view （Fig 2） ( Fig 1） VOOK professional monitoring...
  • Page 90 Rightward rotates the PTZ Stop rotates the PTZ Zoom In/Focus In/Iris Add Zoom Out/Focus Out/Iris Sub Preset Select the preset point Group Set the cruise line Image view Previous Next Zoom out Delete Return to main Zoom in menu VOOK professional monitoring...
  • Page 91 VOOK Record playback Play/pause Full screen stop Return to record file interface (Fig 3) （Fig 3） （Fig 4） Click the record file (Fig 3) to playback (Fig 4) Server list Config interface VOOK professional monitoring...
  • Page 92 Video clip size Single video size. When the video size is greater than setup value, change another video files Remove all recorder files before delete all current video files Information view VOOK professional monitoring...

  • Page 93: Installation And Operation Methods For Blackberry Mobile Phone Client

    1. Open the browser of BlackBerry phone and enter sever address 2. Click “SuperCam” to link 3. Click “Download” button on the popup interface and the download progress will be shown. 4. Finished downloading, the software will be installed automatically. VOOK professional monitoring...
  • Page 94 Note: If the software fails to download, please check in accordance with the following steps: Check whether the network of mobile phone is normal or not Check whether DVR server connect network normally or not Modify the option of Browser Configuration.

  • Page 95: Operation Method For Blackberry Mobile Phone Client

    Main interface Playback playback record file Image image view log record Server List device list Information device information Help software help view center Logoff logoff and return to Settings software setting login interface Live live view Live view VOOK professional monitoring...
  • Page 96 VOOK Note: User can click Return button on the Blackberry phone to return the previous interface. VOOK professional monitoring...
  • Page 97 Stop rotating the PTZ Upward rotates the PTZ Downward rotates the PTZ Leftward rotates the PTZ Rightward rotates the PTZ Zoom In/Focus In/Iris Add Zoom Out/Focus Out/Iris Sub Preset Select the preset point Group Set the cruise line Server list VOOK professional monitoring...
  • Page 98 VOOK Software configuration Information view VOOK professional monitoring...

  • Page 99: Appendix A Faq

    Connection problem. Please check the cable and the ports of camera and DVR. b. Camera problem. Please check the cameras. c. The video format of the DVR is different from that of the cameras. Please change DVR system format. Q5. Cannot find HDD a.
  • Page 100 Not detected. Plug/unplug several times. c. The mouse is incompatible. Please change a mouse. Q8. Cannot download ActiveX control. a. IE browser blocks ActiveX. Please do setup following below. ① Open IE browser. Click Tools-----Internet Options…. VOOK professional monitoring...
  • Page 101 ③ Enable all the sub options under “ActiveX controls and plug-ins” refer to Fig 8-2 ④ Then click ok to finish setup. b. Other plug-ins or anti-virus block ActiveX. Please uninstall or close them. Fig8-1 Fig8-2 Q9: How to deal with when DVR starts, it displays “please wait…”all the time VOOK professional monitoring...
  • Page 102 When DVR only uses one hard disk, the hard disk removed from one to another same type DVR can work normally without format. However, when a DVR adds to a new hard disk, it will identify the hard disk as a new one and inquire whether to format no matter whether this hard disk used or not in another same type DVR before.
  • Page 103 If user gets this problem, may have two ways to fix it: a. Enter Control PanelUser Account and Family Safety  User Account Control(refer to below picture); click Turn User Account on or off. Cancel Use User Account Control (UAC) to help protect your computer. VOOK professional monitoring...
  • Page 104 VOOK b. Right click IE browser (refer to Fig 14-2), select Run as administrator to run browser. VOOK professional monitoring...

  • Page 105: Appendix B Calculate Recording Capacity

    VOOK Appendix B Calculate Recording Capacity Users can calculate the size of hard disk according to the saving time and DVR recording settings. The DVR uses fixed video bit rate. The below are the details at different settings. Resolution Frame Rate...

  • Page 106: Appendix C Compatible Devices

    512MB, 1G, 2GB Netac Kingston Aigo Smatter vider SanDisk Tab C.1 Compatible USB drive 2. Compatible SATA CD/DVD writers after test Brand Model TECLAST GH22NP20/TL-22XD BENQ DW220S-0K4 LITEON DH—20A6S01C LITEON DH-20A4P02C SAMSUNG TS-H653B Tab C.1 Compatible CD/DVD writers VOOK professional monitoring...

  • Page 107: Appendix D 24-Ch Dvr Specifications

    Seagate Barracuda 7200.10 ST3250310AS 250G support Seagate Barracuda 7200.11 ST3160813AS 160G support Seagate Barracuda 7200.10 ST380815AS support Maxtor Diamondmax 21 STM3160215AS 160G support HITACHI Deskstar HDS721616PLA380 160G support HITACHI Deskstar 80G support WD WD1600JS 160G support Sanmsung HD161HJ 160G support VOOK professional monitoring...

  • Page 108: Appendix D 32-Ch Dvr Specifications

    RS485 x 2; USB2.0 x 2(one for backup, another for USB mouse) Disk info SATA x 3+DVD-RW x 1 or SATA x 4(SATA x8 optional) Remote controller Power Supply AC 220V or 110V Temperature 0℃-50℃ Humidity 10%-90% Average Operating Power （Excluding HDD） ≤50W VOOK professional monitoring...
  • Page 109 RS485 x 2; USB2.0 x 2(one for backup, another for USB mouse) Disk info SATA x 3+DVD-RW x 1 or SATA x 4（SATA x8 optional） Remote controller Power Supply AC 220V or 110V Temperature 0℃-50℃ Humidity 10%-90% Average Operating Power （Excluding HDD） ≤50W VOOK professional monitoring...
