IMPORTANT INSTRUCTIONS & OPERATING MANUAL
Valencia
Wide Screen Log Flame Wall Hanging Electric Fireplace
Item No: VWWF-1/0306
Read these instructions carefully before attempting to assemble, install, operate or maintain
the product. Protect yourself and others by observing all safety information. Failure to comply
with instructions could result in personal injury and / or property damage. Retain instructions
for future reference.
1

Advertisement

loading

  Related Manuals for Frigidaire Valencia

  Summary of Contents for Frigidaire Valencia

  • Page 1 IMPORTANT INSTRUCTIONS & OPERATING MANUAL Valencia Wide Screen Log Flame Wall Hanging Electric Fireplace Item No: VWWF-1/0306 Read these instructions carefully before attempting to assemble, install, operate or maintain the product. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and / or property damage.
  • Page 2: General Safety Information

    GENERAL SAFETY INFORMATION When using this fireplace, basic precautions should always be taken to reduce the risk of fire, electric shock and injury to persons, including the following: CAUTION – Due to the high temperature, keep electrical cords, drapery and other furnishings at least 3 feet from the front, side and rear of the fireplace.
  • Page 3 23. Faulty wall outlet connections may cause the wall outlet to overheat. Be sure that the fireplace plug properly fits into the outlet before each use. During use, make sure the fireplace plug does not overheat. If necessary, have a qualified electrician check and / or replace the wall outlet. 24.
  • Page 4 Sr. No Item Description Quantity Carton Electric Fireplace Foam Protection (Left) Mounting Screws Screw Tube ST5x40 Instruction Manual Remote Control Cable Plug Foam Protection (Right) Helpful Advice Before Installation  Please retain all packaging until you have checked and counted all the parts and other package contents.
  • Page 5 Installation  Do not connect the fireplace to the power supply until properly fixed to the wall and the instructions are carefully read.  Make sure the area to be drilled does not have any hidden electrical wires or water and gas pipes.
  • Page 6 Step One  Keep the top of the fireplace at least 3 feet away from the ceiling or other objects for optimum heat ventilation.  For optimum viewing, place four marks on the wall with respect to the recommended fixed dimensions for the top screws (see figure below).
  • Page 7 Turning On  Plug the fireplace into a power outlet.  Turn on the power switch which is located on the right side of the fireplace. Floor Description of Control Panel...
  • Page 8 Description of Remote Control Power Switch  Plug the fireplace into a power outlet. The fireplace is now in Standby mode.  Press the button once to turn on the fireplace and flame effect. An indicator light will light up to indicate that the function is on.
  • Page 9 Remote Control  The remote control requires 2 AAA batteries, which are not included.  Point the remote control directly at the fireplace.  The range is about 11.5 feet. Replacing the Light Bulb  This fireplace consists of 4 bulbs (E-12, 40W) that illuminate a flame effect. The light bulbs need to be replaced if you notice a dark section of the flame or when the flames lose clarity.
  • Page 10: Troubleshooting

    Troubleshooting Problem Possible Solution · Check if the unit is plugged in the power outlet. · Check if the unit is in Standby mode. If so, turn Unit does not work / does not heat the unit ON. · Check if the heat is turned OFF. ·...

This manual is also suitable for:

Madrid vwwf-1/0307Valencia vwwf-0307Valencia vwwf-1307
