MENU Key

The MENU key is used to access the menu system.
Start-Up Options Menu - Press the MENU key during the power up sequence to view the Start-Up
Options menu.
TM
X-Press Menu - Press the MENU key once for the X-Press
access frequently-used settings without having to navigate through the whole menu system. When
the X-Press TM menu is displayed, you can use the UP or DOWN Cursor keys to move to a particular menu
choice. As soon as you alter a parameter (using the RIGHT or LEFT Cursor keys) the X-Press
collapse temporarily, and the screen will update if it is affected by your menu setting change, allowing
you to see the effects of your action immediately. Reactivate the X-Press
DOWN Cursor keys.
Main Menu - Press the MENU key twice for the tabbed Main Menu System. The Main Menu System is
organized under tabbed headings to help you find a specific menu item quickly: Alarms, Sonar, Navigation,
Setup and Accessories tabs are part of your tabbed Main Menu System. Use the LEFT or RIGHT 4-WAY Cursor
Control key to select a tab; then use the DOWN or UP key to select the menu item, and the LEFT or RIGHT
key to alter a menu setting.

4-WAY Cursor Control Key

The 4-WAY Cursor Control Key has multiple functions, depending on the situation:
Freeze Frame - Pressing any arrow on the 4-WAY Cursor Control key will freeze the
display in the Sonar View and a cursor and cursor dialog box will be displayed. The cursor can be
positioned on the Sonar View using the 4-WAY Cursor Control key.
Active Cursor - In the Bird's Eye View, the 4-WAY Cursor Control key controls the motion of the eyepoint.
In the Chart and Combo Views, the 4-WAY Cursor Control key pans the charts.
Menu Selection - Use the DOWN or UP arrow keys to select a menu choice from the menu list, then use
the LEFT or RIGHT arrow keys to change a menu setting.
NOTE: Menu choices are implemented and saved immediately - no further action is required.

MARK Key

Press the MARK key while in any view to mark the position of a waypoint, either at the
current boat location, or, if the Cursor is active, at the current Cursor location.
26
TM
Menu. The X-Press
TM
Menu by using the UP or
TM
menu allows you to
TM
menu will
