the display of the color bar shown in the full screen Sonar View.
To change the display of the Color Bar:
1. Highlight Color Bar on the Sonar Main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the
display of the color bar. (Off, On, Default = On)
Temperature Graph allows you to display or suppress a water temperature
graph over the main 2D Sonar View to show temperature changes correlated
to recent sonar history.
To change the display of the Temperature Graph:
1. In the 2D Sonar View, highlight Temperature Graph on the Sonar
main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the
display of water temperature. (Off, On, Default = On)

Color Bar

Color Bar allows you to display or suppress
Temperature Graph
(2D Sonar View only, with Temperature input)
Navigation Menu
88

Navigation Menu Tab

Press the MENU key twice to access the
Main Menu System, then press the RIGHT
cursor key to select the Navigation tab.
NOTE: Menu choices will vary depending on
system settings.
