MUSIC HALL mmf-7.1 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
music hall
mmf-7.1
INSTRUCTION MANUAL
music hall
http://www.musichallaudio.com
august 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mmf-7.1 and is the answer not in the manual?

Questions and answers

Related Manuals for MUSIC HALL mmf-7.1

Summary of Contents for MUSIC HALL mmf-7.1

  • Page 1 INSTRUCTION MANUAL music hall http://www.musichallaudio.com august 2007...

  • Page 2: Congratulations On Your Purchase

    3. Object or liquid entry Do not allow foreign objects or liquids into the unit. If this happens, immediately disconnect the power cord from the wall and take the unit to an authorized music hall service center for inspection. 4. Heat Keep the turntable away from naked flames, radiators, heat registers, stoves, or any other heat-producing appliances (including amplifiers).
  • Page 3 11. Damage Requiring Service Stop using the turntable immediately and have it inspected by an authorized music hall service center whenever: 1. The power supply cord or plug has been damaged.
  • Page 5 PARTS INVENTORY AND OPERATION CONTROL DIAGRAM 1. 3 x removable transport screws 2. 1 x stepped motor pulley 3. 1 x drive belt (packaged in parts bag) 4. 1 x sub-platter 5. 1 x platter with felt mat (packaged in bottom of box) 6.

  • Page 6: Getting Started

    The music hall mmf-7.1 turntable is 2-speed belt-driven, audiophile quality turntable with many unique features. It is constructed using a split-plinth design and features an external motor. The mmf-7.1 comes in a high gloss, black piano lacquer finish. THE SPLIT-PLINTH.

  • Page 7: For Your Information

    This manual provides valuable information that will help you get optimum performance from your system. Please contact your authorized music hall dealer for any additional clarifications you may require. Save the music hall mmf-7.1 shipping carton and all enclosed packing material for future use. Shipping or moving the mmf-7.1 in anything other than the original packing material may result in severe damage that is not covered by the warranty.
  • Page 8 SET-UP The music hall mmf-7.1 is supplied partially disassembled and carefully packaged for safe transport. To assemble the turntable, please follow the instructions carefully. 1. Clear a level (use a spirit level) and suitable workspace to assemble the turntable. This may be the final playing location.
  • Page 9 Save it for future use. 16. You will now set the tracking force. The mmf-7.1 comes complete with a factory installed Goldring Eroica H cartridge. We recommend a tracking force of 1.75g.
  • Page 10 The tonearm is now zeroed. Check it, by once again floating the tonearm between the tonearm rest and the platter. If the tonearm doesn’t float parallel to the platter at zero, return to the previous steps and make the necessary adjustments. Return the tonearm to the tonearm rest.
  • Page 11 If you are substituting another cartridge for the Goldring Eroica, you may need to make the following further adjustments to the tonearm (9) and cartridge: If you are a novice, music hall recommends getting professional help. All cartridges with half inch mounting holes can be fitted. Leaving the stylus guard on, fit the cartridge to the head shell (21) using the screws supplied with the cartridge by passing one screw through each slot in the finger lift and the head shell (21).

  • Page 12: Audio Connection

    If you have any further questions regarding the adjustment of your turntable, please contact your music hall dealer. Azimuth Adjustment: Azimuth is the angle of the stylus to the record groove. Viewed from head-on, you want the stylus to be perpendicular to the record groove so as to not favor one channel over the other.

  • Page 13: Mains Connection

    Do not use the record clamp with 7-inch records. MAINTENANCE The mmf-7.1 is designed for a long operational life. To preserve the appearance of your deck and maintain its performance, you should note the following points: * Make sure the stylus guard is on before you begin cleaning * PLINTHS - The plinths are constructed from medium density fiberboard, therefore they should not be subjected to extremes of temperature or direct sunlight.
  • Page 14 BELT - The belt should last for many years. The belt can be cleaned at the same time as the pulley. The best way to clean the belt is to pull it gently through a damp cloth. If the turntable is not going to be used for a long period of time, it is advisable to remove the belt from the platter rim to prevent stretching.
  • Page 15 Gyger II Stylus type: non-replaceable Electrical Characteristics Load resistance: 47Kohms Load capacitance: 100-500pf Internal inductance: 0.2mH Internal resistance: 77ohms Mechanical Characteristics Cartridge weight: 5.5g 0.5”(12.7mm) Fixing centers: Playing weight: 1.5-2.0g(1.7g nom.) music hall reserves the right to make technical modifications.

  • Page 16: Troubleshooting

     Platter bearing dry, dirty, or damaged. SERVICE Should you encounter a problem that you cannot solve, please contact your music hall dealer. Never return a record player without authorization and without safely disassembling it and correctly packing it in the original packaging. Repairs will only be made under warranty if the unit is returned correctly packaged.
  • Page 17 Fit the stylus guard on the cartridge and attach the tonearm locking strap (18) to the tonearm (9). Insert and tighten the transport screws (1). Package the turntable carefully and correctly in its original box.

  • Page 18: Claims Under Warranty

    WARRANTY This entitles you to have the music hall mmf-7.1 repaired free of charge, at our discretion, for one year after the date of purchase, at any authorized music hall Service Center, provided the unit was purchased from an authorized dealer. Your original sales receipt is proof of purchase date.
