- Page 1 INSTRUCTION MANUAL music hall http://www.musichallaudio.com...
-
Page 2: Congratulations On Your Purchase
If the turntable is exposed to moisture, immediately disconnect the power cord from the wall. Take the deck to an authorized music hall service center for inspection. Do not touch the turntable, power cord, or plug with wet hands. - Page 3 11. Damage Requiring Service Stop using the turntable immediately and have it inspected by an authorized music hall service center whenever: 1. The power supply cord or plug has been damaged. 2. Liquid has been spilled onto the motor or into the bearing well.
- Page 5 19. 1 x belt changing tool packaged in parts bag 20. 1 x on/off switch 21. 1 x head shell fitted with music hall cartridge 22. 1 x motor 23. 3 x feet (1 x foot located in the parts bag) 24.
-
Page 6: Getting Started
GETTING STARTED Thank you for purchasing the music hall mmf-2.3 turntable. It is a 2-speed belt- driven, audiophile turntable that comes complete with a music hall cartridge mounted in a high-quality carbon tonearm. The alloy platter runs on a precision, stainless steel and bronze bearing assembly to provide fluid and quiet operation. - Page 7 8. You will now set the cartridge tracking force. The mmf-2.3 comes complete with a factory-installed music hall cartridge. We recommend a tracking force of 2.0g. Please note; the tracking force scale (6a) on the counterweight (6) has no decimal point.
- Page 8 (12). NOTE If you are substituting another cartridge for the music hall 'Spirit', you may need to make the following further adjustments to the tonearm (9) and cartridge: If you are a novice, music hall recommends getting professional help.
- Page 9 Tighten the cartridge mounting screws. VTA Adjustment: The VTA for the installed music hall cartridge has been properly set at the factory. To adjust the VTA for other cartridges, lay a record on the platter (5).
-
Page 10: Mains Connection
(5) spins. AUDIO CONNECTION The supplied music hall cartridge is a moving-magnet cartridge. Connect the interconnect cable (14) to the audio output connectors (24) on the bottom of the turntable and connect the ground lead to the screw. Connect the other end of the interconnect cable and ground cable (14) to the MM (Moving Magnet) phono input on your receiver, integrated amp, or pre-amplifier. -
Page 11: Maintenance
hands. Replace the platter and felt mat. Please note, for singles (7 inch records with a large center hole), you may need to use the black 45 rpm adaptor. Simply, center the adapter over the spindle and set it on top of the felt mat. Place the single on the platter and play. -
Page 12: Technical Specifications
Cantilever: Alloy tube Load Impedance: 47,000 Ohm Stylus Construction: Bonded Round Shank Cartridge Weight: 5.7g Fixing Center: 0.5” (12.7mm) Playing Weight 1.5 – 2.5g (2.0g nom.) Music Hall reserves the right to make technical modifications. Check our website for the latest updates. -
Page 13: Troubleshooting
SERVICE Should you encounter a problem that you cannot solve, please contact your dealer. If the problem cannot be resolved by the dealer please contact music hall for further advice. Never return a record player without authorization and without making sure that is it safely disassembled and correctly packaged in the original packaging. -
Page 14: Packing Instructions
PACKING INSTRUCTIONS Please remove and store the following parts: dust cover (10), anti-skating weight (16), platter (5), sub-platter (4), and belt (3). Fit the stylus guard on the cartridge, insert the red motor-transport screws (1), and lock the tonearm (18). Package the turntable carefully in its original box using thick, 1¼... -
Page 15: Claims Under Warranty
WARRANTY This entitles you to have the music hall mmf-2.3 repaired free of charge, at our discretion, for one year after the date of purchase, at any authorized music hall service center, provided the unit was purchased from an authorized dealer. Your original sales receipt is proof of purchase date.
