MUSIC HALL MMF-5.1 Instruction Manual

Hide thumbs

Advertisement

Table of Contents

music hall
mmf-5.1
INSTRUCTION MANUAL
music hall
http://www.musichallaudio.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMF-5.1 and is the answer not in the manual?

Questions and answers

Related Manuals for MUSIC HALL MMF-5.1

Summary of Contents for MUSIC HALL MMF-5.1

  • Page 1 INSTRUCTION MANUAL music hall http://www.musichallaudio.com...

  • Page 2: Congratulations On Your Purchase

    If the turntable is exposed to moisture, immediately disconnect the power cord from the wall. Take the deck to an authorized music hall service center for inspection. Do not touch the turntable, power cord, or plug with wet hands.
  • Page 3 11. Damage Requiring Service Stop using the turntable immediately and have it inspected by an authorized music hall service center whenever: 1. The power supply cord or plug has been damaged. 2. Liquid has been spilled onto the motor or into the bearing well.
  • Page 5 Parts Inventory and Operation Control Diagram 1. 3 x removable transport screws 2. 1 x stepped motor pulley 3. 1 x drive belt (packaged in parts bag) 4. 1 x sub-platter 5. 1 x platter with felt mat (packaged in bottom of box) 6.

  • Page 6: Getting Started

    Shipping or moving the mmf-5.1 in anything other than the original packing material may result in severe damage that is not covered by the warranty. Be sure to keep the original sales receipt;...
  • Page 7 3. Remove the 3 transport screws (1) from the turntable and save for future use. 4. If you are placing the mmf-5.1 on an un-level shelf, level the turntable. The mmf-5.1 comes with a bubble level (24) for this purpose. Please note; the feet on the mmf-5.1 are non-adjustable.
  • Page 8 tracking force of 1.75g. Please note; the tracking force scale (6a) on the counterweight (6) has no decimal point. 10 on the tracking force scale (6a) is actually 1.0 g. 15 is actually 1.5g, etc. 1.75 g is between 17 and 18g on the scale (6a).
  • Page 9 If you are substituting another cartridge for the Goldring 1012GX, you may need to make the following further adjustments to the tonearm (9) and cartridge: If you are a novice, music hall recommends getting professional help. All cartridges with half inch mounting holes can be fitted. Leaving the stylus...
  • Page 10 VTA positions slightly above or below parallel and choose the position you prefer. If you have any further questions regarding the adjustment of your turntable, please contact your music hall dealer. Azimuth Adjustment: Azimuth is the angle of the stylus to the record groove.

  • Page 11: Audio Connection

    tonearm rest (8). Remove the anti-skating weight (16) from the anti-skating rod (15). Hold the anti-skating rod (15) between your thumb and forefinger and unscrew it using a clockwise rotation. Lift the tonearm (9) up about 2 – 3 inches out of the tonearm rest (8).

  • Page 12: Maintenance

    7-inch records. MAINTENANCE The mmf-5.1 is designed for a long operational life. To preserve the appearance of your deck and maintain its performance, you should note the following points: * Make sure the stylus guard is on before you begin cleaning * PLINTH - The plinth is constructed from medium density fiberboard, therefore it should not be subjected to extremes of temperature or direct sunlight.

  • Page 13: Technical Specifications

    Stylus type: replaceable Electrical Characteristics Load resistance: 47Kohms Load capacitance: 150-200pf Internal inductance: 570mH Internal resistance: 660ohms Mechanical Characteristics Cartridge weight: 6.3g Fixing centers: 0.5” (12.7mm) Playing weight: 1.5-2.5g (1.7g nom) music hall reserves the right to make technical modifications.

  • Page 14: Troubleshooting

    SERVICE Should you encounter a problem that you cannot solve, please contact your music hall dealer. Never return a record player without authorization and without safely disassembling it and correctly packing it in the original packaging. Repairs will only be made under warranty if the unit is returned correctly packaged.
  • Page 15 Fit the stylus guard on the cartridge and attach the tonearm locking strap (18) to the tonearm (9). Insert and tighten the transport screws (1). Package the turntable carefully and correctly in its original box.

  • Page 16: Claims Under Warranty

    WARRANTY This entitles you to have the music hall mmf-5.1 repaired free of charge, at our discretion, for one year after the date of purchase, at any authorized music hall service center, provided the unit was purchased from an authorized dealer. Your original sales receipt is proof of purchase date.
