- Page 1 INSTRUCTION MANUAL music hall http://www.musichallaudio.com...
-
Page 2: Congratulations On Your Purchase
If the turntable is exposed to moisture, immediately disconnect the power cord from the wall. Take the deck to an authorized music hall service center for inspection. Do not touch the turntable, power cord, or plug with wet hands. - Page 3 Damage Requiring Service Stop using the turntable immediately and have it inspected by an authorized music hall service center whenever: 1. The power supply cord or plug has been damaged. 2. Liquid has been spilled onto the motor or into the bearing well.
- Page 5 PARTS INVENTORY AND OPERATION CONTROL DIAGRAM 1. 1 x electronic speed control 2. 1 x platter with felt mat, packaged in bottom of box 3. 1 x anti-skating weight, (packaged in a pink bag inside the parts bag) 4. 1 x anti-skating rod 5.
-
Page 6: Getting Started
1 x universal DC power supply GETTING STARTED Thank you for purchasing the music hall mmf-3.3 turntable. It is a 3-speed belt- driven, audiophile turntable that comes complete with a Ortofon cartridge mounted in a high-quality carbon tonearm. The alloy platter runs on a precision, stainless steel and brass bearing assembly to provide fluid and quiet operation. - Page 7 4. Install the drive belt (10) for 33⅓ and 45 rpm play. Loop the belt around the smaller diameter rim of the stepped motor pulley (11) and around the rim of the sub-platter (12). Change the speed by pressing speed control button on the chassis.
- Page 8 Using your left hand, lift, position, and hold the tonearm (6) between the tonearm rest (7) and the platter (2). To avoid damage, be careful not to allow the cartridge to contact the plinth (the turntable base). With your free hand turn the counterweight counterclockwise or clockwise until the tonearm floats freely, without the aid of your hand, in mid-air and parallel to the platter.
- Page 9 If you are substituting another cartridge for Ortofon 2M Red, you may need to make the following further adjustments to the tonearm (6) and cartridge: If you are a novice, music hall recommends getting professional help. All cartridges with half inch mounting holes can be fitted. Leaving the stylus guard...
-
Page 10: Mains Connection
VTA positions slightly above or below parallel and choose the position you prefer. If you have any further questions regarding the adjustment of your turntable, please contact your music hall dealer. *Save all packing materials, parts, and screws for possible future transport. -
Page 11: Audio Connection
back. Plug the transformer into the wall. Turn the motor ‘ON’ (22) and check that the platter (2) spins. AUDIO CONNECTION The supplied Ortofon cartridge is a moving-magnet cartridge. Connect the interconnect cable to the audio output connectors (24) on the bottom of the turntable and connect the ground lead to the screw. -
Page 12: Technical Specifications
Stylus Shape: Elliptical Stylus Type: Replaceable Load Impedance: 47,000 Ohm Cartridge Weight: 7.2g Fixing Center: 0.5” (12.7mm) Playing Weight 1.6 – 2.0g (2.0g nom.) Music Hall reserves the right to make technical modifications. Check our website for the latest updates. -
Page 13: Troubleshooting
SERVICE Should you encounter a problem that you cannot solve, please contact your dealer. If the problem cannot be resolved by the dealer please contact music hall for further advice. Never return a record player without authorization and without making sure that is it safely disassembled and correctly packaged in the original packaging. -
Page 14: Packing Instructions
PACKING INSTRUCTIONS Please remove and store the following parts: dust cover (20), anti-skating weight (3), platter (2), sub-platter (12), and belt (10). Fit the stylus guard on the cartridge and lock the tonearm (18). Package the turntable carefully in its original box using thick, 1¼ inch Bubble Wrap. -
Page 15: Claims Under Warranty
WARRANTY This entitles you to have the music hall mmf-3.3 repaired free of charge, at our discretion, for one year after the date of purchase, at any authorized music hall service center, provided the unit was purchased from an authorized dealer. Your original sales receipt is proof of purchase date.
