  • Page 1: Service Manual

    Service Manual Model : iDP-562 Rev. Issued Japan CBM Corporation Information Systems Div.

  • Page 2: Table Of Contents

    Service Manual Contents 1. External Appearance and Name of Each Part......................3 2. Method of detaching Each Part ..........................4 2.1. Detaching Printer Cover..........................4 2.2 Detaching Upper Case.............................4 2.3 Detaching Control Board ..........................5 2.4 Detaching Power Source ..........................7 2.5 Detaching Print Head ............................8 3.

  • Page 3: External Appearance And Name Of Each Part

    Service Manual 1. External Appearance and Name of Each Part Fig. 1-1 Front View Fig. 1-2 Rear View CITIZEN...

  • Page 4: Method Of Detaching Each Part

    Service Manual 2. Method of detaching Each Part Please pull out power plug from the outlet before any detaching work.. 2.1. Detaching Printer Cover The printer cover can be detached by lifting it up along the direction of the arrow as shown in Fig 2.1-1.

  • Page 5: Detaching Control Board

    Service Manual 2) put the printer body upside down again, in order to detach the upper case. 2.3 Detaching Control Board 1) Put the printer body upside down, then, remove 2-pieces of screws for fixing the bottom cover. Fig. 2.3-1...
  • Page 6 Service Manual 3) Remove 2-pieces of screws for fixing the control board. Fig. 2.3-3 [1] Screws for fixing control board BTP 3 x12 [2] Screws for fixing control board STP 3 x 14 [3] Flat cable for printer connecting use [4] Power board connector 4) Pull out the power board connector.

  • Page 7: Detaching Power Source

    Service Manual 2.4 Detaching Power Source The power source consists of power cord, power switch, transformer, etc.. they are build on power board. The procedures of detachment are shown as below: 1) Pull out the power board connector (see 2.3) 2) Detach the upper case.

  • Page 8: Detaching Print Head

    Service Manual 2.5 Detaching Print Head 1) Pull out the printer’s flat cable from the control board. (see 2.3) 2) Detach the upper case. (see 2.2) 3) Hold up the print head, and slide it ahead, then it can be detached.

  • Page 9: Interface Circuits

    Service Manual 3.1 Interface Circuits 3.1.1 Parallel interface of iDP562-CNL The input data of interface connector CN1 can be read in the PA-port of I / O 8155 by the strobe (STB). The relevant “Timing chart” is denoted in Fig 3.1.1-2 Fig 3.1.1-1 Circuit...

  • Page 10: Serial Interface Of Idp562-Rsl And Idp562-Rsl2

    Service Manual 3.1.2 Serial Interface of iDP562-RSL and iDP562-RSL2 There are several types of RS-232C, TTL, current loop, in the category of serial interface. The input data can be read in from the receive data (RD) terminal of interface connector CN1.

  • Page 11: Printer Head Signal

    Service Manual 3.2 Printer Head Signal The circuit for the input from print head. The drive circuits are denoted in 3.2.3. Relevant print control makes the printer head actuating, when “on” states of the motor, and simultaneously, 20ms “on” of main solenoid are realized.
  • Page 12 Service Manual 3.2.2 Timing Chart Fig.3.2.2-1 Timing Chart CITIZEN...
  • Page 13 Service Manual 3.2.3 Drive Circuit Fig 3.2.3-1 3.3 Key Switch and LED Indictor Circuit The front panel provides key switches and LED indicators. Fig 3.3-1 CITIZEN...
  • Page 14 Service Manual 3.4 Initial Reset Circuit Fig 3.4-1 Initial Reset Circuit of iDP562-CNL Fig 3.4-2 Initial Reset Circuit of iDP562-RSL and iDP562-RSL2 3.5 Power Source All voltage needed in actuating the printer are supplied. They are DC +5V and DC +12V.
  • Page 15 Service Manual 3.5.1 Power Circuit Fig. 3.5.1-1 CITIZEN...

  • Page 16: Circuit Diagram

    Service Manual 4. Circuit Diagram 4.1 Model IDP562-CNL CITIZEN...

  • Page 17: Model Idp562-Rsl

    Service Manual 4.2 Model IDP562-RSL CITIZEN...

  • Page 18: Model Idp562-Rsl2

    Service Manual 4.3 Model IDP562-RSL2 CITIZEN...

  • Page 19: Parts Position

    Service Manual 5. Parts Position 5.1 IDP562-CNL Control PCB Parts Position CITIZEN...

  • Page 20: Idp562-Rsl Control Pcb Parts Position

    Service Manual 5.2 IDP562-RSL Control PCB Parts Position CITIZEN...

  • Page 21: Idp562-Rsl2 Control Pcb Parts Position

    Service Manual 5.3 IDP562-RSL2 Control PCB Parts Position CITIZEN...

  • Page 22: Power Pcb Parts Position

    Service Manual 5.4 Power PCB Parts Position CITIZEN...

  • Page 23: Exploded View Model Idp562Cnl/Ul

    Service Manual 5.5 Exploded View Model IDP562CNL/UL CITIZEN...

  • Page 24: Exploded View Model Idp562Rsl, Rsl2/Ul

    Service Manual 5.6 Exploded View Model IDP562RSL, RSL2/UL CITIZEN...

  • Page 25: Exploded View Model Idp562Cnl/Ep

    Service Manual 5.7 Exploded View Model IDP562CNL/EP CITIZEN...

  • Page 26: Exploded View Model Idp562Rsl, Rsl2/Ep

    Service Manual 5.8 Exploded View Model IDP562RSL, RSL2/EP CITIZEN...

  • Page 27: Parts List

    Service Manual 6. Parts List 6.1 Printer DP575L-12A PARTS LIST DP-575L-12A Ref. No. Description Q'ty Parts No. Rev. A. Ribbon SA T 5501 -010 Ribbon Plate BK T 5502 -010 Ribbon Lever Spring T 5164 -210 Ribbon Feed Lever Spring...
  • Page 28 Service Manual PARTS LIST DP-575L-12A Ref. No. Description Q'ty Parts Rev. A. Ribbon SA T 5002 -020 Ribbon Plate BK T 5119 -030 Ribbon Lever Spring T 5003 -010 Ribbon Feed Lever Spring N 7129 -020 Ribbon Feed Lever BK...
  • Page 29 Service Manual PARTS LIST DP-575L-12A Ref. No. Description Q'ty Parts Rev. A. Ribbon SA T 5000 -210 Ribbon Feed Lever BK T 5112 -010 Color Change Spring T 5130 -010 E rng N 7204 -010 E rng E 2.5...
  • Page 30 Service Manual DP575L-12A Rev.A CITIZEN...
  • Page 31 Service Manual DP575L-12A CITIZEN...

  • Page 32: Idp562-Cnl, Rsl, Rsl2

    Service Manual 6.2 IDP562-CNL, RSL, RSL2 PARTS LIST CONTROL BOARD ASSY iDP562-CNL Ref. No. Parts No. Description Q'ty Remarks E 104-450 uPD40HC E 104-310 uPD8155HC / HC-2 E 104-460 EP-ROM Am27C256-205DC (CNU0) E 201-811 HD74LS373P E 201-450 HD7432P 6, 7...
  • Page 33 Service Manual PARTS LIST CONTROL BOARD ASSY iDP562-CNL Ref. No. Parts No. Description Q'ty Remarks E 3103-130 Re. Arry RGLD8X103J E 3103-220 Re. Arry RGLD9X103J E 3103-230 Re. Arry RGLD9X102J E 3332-180 Re. Arry RGLD4X332J E 501-260 C. Resonator CST12.
  • Page 34 Service Manual PARTS LIST CONTROL BOARD ASSY iDP562-RSL / RSL-2 Q’ty Ref. No. Parts No. Description RSL RSL-2 Remarks E 104-450 uPD40HC E 104-420 uPD50HC-023 E 104-310 uPD8155HC / HC-2 E 104-470 EP-ROM Am27C256-205DC (RSU1) E 390-180 V. Detector...
  • Page 35 Service Manual PARTS LIST CONTROL BOARD ASSY iDP562-RSL / RSL-2 Q'ty Ref. No. Parts No. Description RSL RSL-2 Remarks E 2010-800 El. Cap. 1000uF / 6.3 E 2010-720 El. Cap. 100uF / 25 3, 4 E 2001-650 El. Cap.
  • Page 36 Service Manual PARTS LIST CONTROL BOARD ASSY iDP562-RSL / RSL-2 Q'ty Ref. No. Parts No. Description RSL RSL-2 Remarks R 11, 12 E 3511-041 Resistor 1 / 4W E 3101-041 Resistor 1 / 4W PJ 1-6 E 4800-365 Dic Conn.
  • Page 37 Service Manual PARTS LIST POWER SUPPLY ASSY iDP-562-CNL / -RSL / -RSL-2 Q'ty Ref. No. Parts No. Description 120V 230V Remarks Spacer ABS (15A1B4780) E 450-540 Re. Diode RBA-402 E 359-041 Transistor 2SC945 (QA, PA, KA) 2, 3 E 379-040...
  • Page 38 Service Manual PARTS LIST EXPLODED VIEW iDP-562-CNL / -RSL / -RSL-2 Ref. No. Parts No. Description Q'ty Remarks E 62010450 Top Case E 6202-980 Bottom Case E 6204-850 Printer Cover E 6209-300 Lower Hatch CNL only E 6209-290 Lower Hatch...
  • Page 39 Service Manual PARTS LIST EXPLODED VIEW iDP-562-CNL / -RSL / -RSL-2 Ref. No. Parts No. Description Q'ty Remarks E 6605-100 Head Cover S 90000860 Screw STP3 x 14 Zn SemsA UL / CSA CN S 90000910 Screw BTP3 x 10 Sems...
