Service Manual

Model : iDP-3210
Rev.
Issued
0.01
May 7, 1997
Japan CBM Corporation
Information Systems Div.

Advertisement

Table of Contents
loading

Summary of Contents for Citizen iDP-3210

  • Page 1: Service Manual

    Service Manual Model : iDP-3210 Rev. Issued 0.01 May 7, 1997 Japan CBM Corporation Information Systems Div.
  • Page 2: Preface

    Service Manual Preface This manual, which describes the operational principles and procedures for maintenance, is to be read by service personnel. Features This printer, a small-sized line thermal printer, has been developed to be applicable with various data communication terminals, POS terminals, kitchen printers, etc..
  • Page 3: Table Of Contents

    Circuit Diagram iDP-3210-PF........................... 17 Chapter 5 Trouble-Shooting............................20 5.1 Procedure for Repair ............................20 Exploded View IDP-3210 1 ............................25 Exploded View IDP-3210 2 ............................26 Appendix 1. Outer Drawing of Printer.......................... 36 Appendix 2. Outer Drawing of AC Adapter Model : 30AD ..................37 Appendix 3.
  • Page 4 Service Manual Chapter 1 Handling and Maintenance of Printer Chapter 2 Specifications and Operational principle CITIZEN 4/46...
  • Page 5: Chapter 1 Handling And Maintenance Of Printer

    Service Manual Chapter 1 Handling and Maintenance of Printer Please refer to “Item 2 Prior to use” and “Item 3 In using” described in the User’s manual contained in printer package. Chapter 2 Specifications and Operation Principle 2-1 General Specifications...
  • Page 6: Mechanism And Operational Principle

    Service Manual 2.2 Mechanism and Operational Principle The basic construction and operational principle of the printer are divided into the following blocks for explanation. * Power Transmission and Paper Feed Mechanism. * Sensor Mechanism. * Print Head Mechanism. 2.2.1 Power Transmission and Paper Feed Mechanism.
  • Page 7: Sensor Mechanism

    Service Manual 2.2.3 Sensor Mechanism (1) Paper Sensor The paper sensor detects the presence/absence of paper in front of the thermal head. Activation of the thermal head when paper is not inserted could cause damage or shorten the life of the head significantly. This sensor is used...
  • Page 8: Print Head Mechanism

    Service Manual 2.2.4 Print Head Mechanism A thermal head is used for this printer. The head is composed of the heating element and the head drive for the drive and control of the element. (1) Outline of Drive and Control...
  • Page 9 Service Manual Chapter 3 Disassembling / Assembling CITIZEN 9/46...
  • Page 10: Chapter 3 Dismantling And Assembling

    Service Manual Chapter 3 Dismantling and Assembling For maintenance, pay attention to the following matters. Caution (1) If printer performs well, do not dismantle, reassemble, nor adjust the printer without reasons. (2) Upon the completion of an inspection, be sure to check the printer again for abnormality before turning on the power.
  • Page 11 Service Manual Remove the black mark sensor (option) from the upper cover. (1) Remove the upper cover. (2) Bend the claw on the reverse side of the upper cover shown by an arrow mark to remove the edge of the circuit board on the cable side, (3) Remove the cable from the upper cover.
  • Page 12 Service Manual 5. Remove the bottom plate from the chassis. (1) Unfasten two M3 x 8 screws. (2) Slide the bottom plate slightly in the direction of the arrow mark (1) to remove the power supply connector from the housing.
  • Page 13 Service Manual Remove the thermal head from the control board. (1) Insert a (-) screwdriver between the heat sink of the thermal head and the head BK (at one end of the arrow mark) to lift the head slightly so that it may float a little from the connector.
  • Page 14: Procedure For Assembling

    Service Manual 3.2 Procedure for Assembling For assembling, mount each part according to the procedures shown in the article 3.1, "Procedure for Dismantling" in the opposite order. CITIZEN 14/46...
  • Page 15 Service Manual Chapter 4 Circuit diagram CITIZEN 15/46...
  • Page 16: Chapter 4 Circuit Diagram

    Service Manual Chapter 4 Circuit Diagram Circuit Diagram iDP-3210-RF D/N. 3210-08 CITIZEN 16/46...
  • Page 17: Circuit Diagram Idp-3210-Pf

    Service Manual Circuit Diagram iDP-3210-PF D/N.3210-05 CITIZEN 17/46...
  • Page 18 Service Manual Block Diagram CITIZEN 18/46...
  • Page 19 Service Manual Chapter 5 Trouble Shooting CITIZEN 19/46...
  • Page 20: Chapter 5 Trouble-Shooting

    Service Manual Chapter 5 Trouble-Shooting 5.1 Procedure for Repair If a failure occurs, observe the cause of the failure carefully, locate the point of the failure, and repair it following the prescribed procedures. Problem : Seek the cause of the failure from items in this column.
  • Page 21 Service Manual Phenomenon Cause Check method Repair method Poor paper feed Defect in connection of Check connection of Connect connector Paper feed motor motor connector. connector. correctly. does not work, or Poor power supply. Check if specified AC Use specified AC adapter.
  • Page 22 Service Manual Chapter 6 Parts List CITIZEN 22/46...
  • Page 23: Service Parts List

    Service Manual Parts List MODEL IDP-3210 EXPLODED VIEW Service Parts List Ref. Parts No. Description QTY' E 4002-490 Chassis E 62020190 Bottom case-RF E 62020200 Bottom case-PF E 6302-370 Foot E 6601-330 Protector E 62010730 Top case assy E 62010731...
  • Page 24 Service Manual Parts List MODEL IDP-3210 EXPLODED VIEW Service Parts List Ref. Parts No. Description QTY' E 6100-735 AC cord for 120V E 6100-730 AC cord for 230V 23G57459 Screw M2x3 23G57481 Screw M2.6x6 23G29538 Screw M3x5 23G22821 Screw M3x8...
  • Page 25: Exploded View Idp-3210 1

    Service Manual Exploded View IDP-3210 1 CITIZEN 25/46...
  • Page 26: Exploded View Idp-3210 2

    Service Manual Exploded View IDP-3210 2 D/N. 3210-02 CITIZEN 26/46...
  • Page 27 Service Manual Parts List MODEL IDP-3210 IDP-3210 IDP-3210 Service Parts List CONTROL BOARD ASSY Ref. Parts No. Description 1 E 107-280 CPU HD6413002F16 2 E 104-530 Gate array CBM202LA-00 3 E 107-290 RAM LC36256AML-10-TRM 4 E 202-920 Reset IC M51953A(B)L 5 E 4101-720 DC-DC com.
  • Page 28 Service Manual Parts List MODEL IDP-3210 IDP-3210 IDP-3210 Service Parts List CONTROL BOARD ASSY Ref. Parts No. Description 15,26 E 3900-440 Chip Re. RK73K2A82K 18,19,23 E 3900-450 Chip Re. RK73K2A1KJ 20 E 3900-460 Chip Re. RK73K2A220J 21 E 3900-470 Chip Re.
  • Page 29 Service Manual Parts List MODEL IDP-3210 Service Parts List IDP-3210 IDP-3210 CONTROL BOARD ASSY Ref. Parts No. Description 1 E 501-360 X'tal CST16.00MXW0C3 L 2,3,14 - 20 E 4009-480 Fe. beads BLM41P800S 22,26,27 104 - 106 2,3,14-20 E 4009-480 Fe.
  • Page 30 Service Manual Parts Layout on Control Board CITIZEN 30/46...
  • Page 31 Service Manual CITIZEN 31/46...
  • Page 32 Service Manual CITIZEN 32/46...
  • Page 33 Service Manual CITIZEN 33/46...
  • Page 34 Service Manual CITIZEN 34/46...
  • Page 35 Service Manual CITIZEN 35/46...
  • Page 36: Appendix 1. Outer Drawing Of Printer

    Service Manual Appendix 1. Outer Drawing of Printer CITIZEN 36/46...
  • Page 37: Appendix 2. Outer Drawing Of Ac Adapter Model : 30Ad

    Service Manual Appendix 2. Outer Drawing of AC Adapter Model : 30AD CITIZEN 37/46...
  • Page 38: Appendix 3. Acs-130 Service Manual

    Service Manual Appendix 3. ACS-130 Service Manual SERVICE MANUAL AUTO CUTTER UNIT MODEL :ACS-130/120 (132/134) Japan CBM Corporation Information Systems Div. CITIZEN 38/46...
  • Page 39 Service Manual 1. Maintenance and Handling 1.1 Attention to Handling (1) Precaution for use l Do not cut paper other than the specified recording paper, nor pull recording paper while paper is being cut, or the blade will be damaged to shorten the life.
  • Page 40 Service Manual 2. Mechanism and Operational Principle 2.1 Outline of Mechanism ACS-130 is designed for compact printers, and offers major advantage of ultra slim design and light weight. Its mechanism is composed of a frame, transmission mechanism, sensor and blade mechanism blocks.
  • Page 41 Service Manual 2.2.3 Blade Mechanism Block The blade cuts recording paper by its linear motion converted by the crank pin. (1) Full cut For full cut, the crank pin returns to the home position after one revolution. The blade moves 11 mm.
  • Page 42 Service Manual 3. Repairs (Trouble shooting) Trouble shooting is divided into the following items to explain how to repair. In accordance with the following items to check and repair. (1) Trouble ………….. Find the trouble in this item. (2) Conditions ………..The same trouble can show different conditions.
  • Page 43 Service Manual 4. Disassembling and Reassembling (1) Disassembling procedures Disassemble the unit according to the assembling procedures in the reverse order. (2) Assembling procedures Assemble the unit according to the assembling procedures shown in the separate table. CITIZEN 43/46...
  • Page 44 Service Manual CITIZEN 44/46...
  • Page 45 Service Manual Exploded View ACS-131 CITIZEN 45/46...
  • Page 46 Service Manual Parts List MODEL ACS-131 Service Parts List AUTO PAPER CUTTER Ref. Parts No. Description QTY' E 8010-250 Cutter frame assy E 8022-060 Paper stopper E 8021-110 Lraf spring E 8015-020 Cutter gear assy E 8020-020 W gear...
