Owner's Manual
GAS-FIRED DIRECT VENT INSERT
FOR YOUR SAFETY:
gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
FOR YOUR SAFETY:
Smell Gas:
Do not touch electrical switches.
Do not try to light any appliance.
Do not use the phone in your building.
Immediately call your gas supplier from a
neighbor's phone.
Follow your gas supplier's instructions.
If you cannot reach your gas supplier, call the fire
department.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Refer to this manual. For assistance
or additional information consult a qualified, service
agency, or the gas supplier. In the Commonwealth of
Massachusetts, all installation of gas lines and gas
fitting shall only be done by a licensed gas fitter or
licensed plumber.
DVI-Ht (8890)
HEATER
Do not store or use
What To Do If You
Manufactured by HearthStone
317 Stafford Avenue
Morrisville, Vermont 05661
E-Mail-Inquiry@HearthStoneStoves.com
READ THIS OWNER'S MANUAL
Operate and maintain this gas heater
according to instructions in this manual.
Read this manual in its entirety.
POUR VOTRE SÉCURITÉ:
ni utiliser d'essence ni d'autre vaperurs ou liquides
inflammables dans le voisinage de cet apprareil ou de
tout autre appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous
sentez une odeur de gaz
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur.
servir des téléphones se trouvant dans le
batiment où vous vous trouvez.
Evacuez la pièce, le bâtiment ou la zone.
Appelez immédiatement votre fournisseur de gaz depuis un
voisin. Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
AVERTISSEMENT:
une modification, un entretien ou une maintenance
incorrects peuvent entrâiner des dommages matériels,
des lésions corporelles ou la perte de vies humaines.
Consulter le manuel des usagers fourn avec ce
générateur d'air chaud.
Ne pas entresposer
:
Ne pas vous
Une installation, un réglage,
6400-40452
4/19/06
Advertisement
Table of Contents
Related Manuals for HearthStone DVI-Ht 8890
Summary of Contents for HearthStone DVI-Ht 8890
- Page 1 DVI-Ht (8890) GAS-FIRED DIRECT VENT INSERT HEATER Manufactured by HearthStone 317 Stafford Avenue Morrisville, Vermont 05661 E-Mail-Inquiry@HearthStoneStoves.com READ THIS OWNER’S MANUAL Operate and maintain this gas heater according to instructions in this manual. Read this manual in its entirety. FOR YOUR SAFETY: POUR VOTRE SÉCURITÉ:...
- Page 2 INFORMATION SHEET Record on this page, all relevant information concerning the purchase, installation, and maintenance of your Gas-Fired Direct Vent Insert. This information will facilitate servicing, purchase of replacement parts, and warranty claims (if necessary). Keep your original receipt in a safe place as proof of purchase. Serial Number: _______________________ Fuel type (check one) Natural Gas...
-
Page 3: Table Of Contents
OWNER’S MANUAL Model # 8890 DVI-Ht TABLE OF CONTENTS TABLE OF CONTENTS ..............................2 CODES ......................................2 INTRODUCTION ..................................3 SAFETY INFORMATION ..............................3 SPECIFICATIONS ..................................5 UNPACKING ....................................6 CLEARANCES TO COMBUSTIBLES ........................7 HEARTH REQUIREMENTS /FLOOR PROTECTION ........ Error! Bookmark not defined. VENTING COMPONENTS & CONFIGURATION ..................7... -
Page 4: Introduction
HearthStone Gas-Fired Direct Vent Insert. The DVI-Ht wall-mounted thermostat. Also available through your incorporates the latest in energy and gas technology, local HearthStone dealer is an optional front door screen which will provide you with clean, efficient heat for (Kit #98-69700) which enhances the realistic flame. - Page 5 Use of any components not supplied ou en partie. Appeler un l’eau, complètement by HearthStone on the stove voids all warranties. Do technicien qualifié pour inspector l’appareil et not substitute components. remplacer toute partie du système de contrôle et toute commande qui ont été...
-
Page 6: Specifications
OWNER’S MANUAL Model # 8890 DVI-Ht SPECIFICATIONS Listed: Direct Vent Gas Fireplace Model: DVI-Ht Room Heater Testing Agency: Intertek Testing Services NA Inc. Figure 1: FireboxDimensions (ITS) Tested to: ANSI Z21.88-2002 CSA 2.33-M02 CAN/CGA2.17-M91 Certified for use by: Board of State Examiners of Plumbers and Gasfitters... -
Page 7: Unpacking
OWNER’S MANUAL Model # 8890 DVI-Ht UNPACKING Install “AA” battery in the pilot igniter box Inspect for Damage under the gas component tray before trying to light the unit. Inspect the DVI-Ht for visible and/or concealed damage. The unit should appear to be square and true. The sheet... -
Page 8: Clearances To Combustibles
OWNER’S MANUAL Model # 8890 DVI-Ht CLEARANCES TO Figure 2: Clearance To Combustibles (* Insulation is recommended) COMBUSTIBLES high surface temperatures, unit should be located away from furniture 8" - TO ALL SIDE WALLS draperies. Clothing 13" - WITH 1" TRIM 15"... - Page 9 5. Four 3-1/2" Hose Clamps (all steel or stainless) over the ends of both flexible vent pipes. Place the *Available through your local HearthStone dealer. flexible vent pipe marked “intake” onto the intake collar, place the flexible vent pipe marked “exhaust”...
- Page 10 OWNER’S MANUAL Model # 8890 DVI-Ht CAUTION A reverse flue condition may occur if the venting is not attached correctly, or if the unit is lit before the glass front is secured. A reverse flue condition may damage the unit.
-
Page 11: Electrical Connections
OWNER’S MANUAL Model # 8890 DVI-Ht switch. The DVI-Ht may also be controlled by the wall mounted thermostat for automatic operation. ELECTRICAL CONNECTIONS recommend installation of the thermostat for more Install “AA” battery in the pilot ignitor box comfortable, automatic performance, however you may... -
Page 12: Gas Supply And Connections
OWNER’S MANUAL Model # 8890 DVI-Ht towards the thermostat. (At the thermostat, the wires gauge connection (immediately upstream of the gas should be connected to the two connection screws on the supply connection). Damage to the valve caused by back of the thermostat per the instructions received with lack of a sediment trap will not be covered by the the thermostat). -
Page 13: Assembling The Unit
OWNER’S MANUAL Model # 8890 DVI-Ht w.c.), the heater must be disconnected from the gas and safety goggles while handling the log set. supply system. Test by connecting a manometer to the supply line. Adjust the incoming pressure, if necessary, 1) To open the firebox, reach over the firebox, and to meet the required supply line pressure. - Page 14 OWNER’S MANUAL Model # 8890 DVI-Ht Log Set Removal To remove the log set, follow the “Log Placement Within the Unit” instructions in the reverse order on page 12. Surround and Façade Installation See instructions included with assemblies. Installing The Unit Place a level on top of the unit.
-
Page 15: Lighting The Unit For The First Time
OWNER’S MANUAL Model # 8890 DVI-Ht Prior to lighting the unit for the first time, wait 5 minutes to allow any residual gas within the unit to dissipate. LIGHTING THE UNIT FOR THE Smell all around the appliance area for gas. Be sure to... -
Page 16: Pilot And Burner Flames
OWNER’S MANUAL Model # 8890 DVI-Ht • position. If the pilot will not stay lit after several tries, 2. If shutting the unit off for the non-heating season, turn the gas control knob “OFF” and call a turn the gas control knob fully clockwise to the qualified service technician or gas supplier. -
Page 17: Maintenance And Care
WARNING: Do not substitute materials Figure 14: Flame Pattern For replacement parts, or for information about parts or service, contact your local HearthStone dealer. NOTE: Label all wires prior to disconnecting when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. - Page 18 Contact your authorized dealer for replacement glass. For replacement parts, or for information about parts or service, contact your authorized HearthStone retailer. For the name of the authorized retailer nearest to you visit our website at www.hearthstonestoves.com, or e- mail us at inquiry@hearthstonestoves.com.
-
Page 19: Parts List
OWNER’S MANUAL Model # 8890 DVI-Ht PARTS LIST Part No. Description 2810-400 GRILLE: TOP,MATTE,KIL 2810-824 HEAT EXCHANGER: 2810-825 HEAT EXCHANGER: BASE 2810-910 GRILLE: BOTTOM 2810-920 HANDLE: FLAME 2810-930 FRAME: CENTER 2810-940 DOOR: LEFT 2810-950 DOOR: RIGHT 3030-021 GLASS: 25-29/32"x13-13/16"x5mm,DVI 3120-890... - Page 20 OWNER’S MANUAL Model # 8890 DVI-Ht PARTS LIST cont. Description Part No. 98-56900 (NG)FUEL CONVERSION 3300-651 LABEL: BAG,NG CONVERSION KIT,WIN/DVI 32 7200-743 ORIFICE: BURNER HOOD,#43 SPUD 7200-752 ORIFICE: BURNER HOOD,#52 SPUD 7211-163 ORIFICE: PILOT,NG,.62mm,CONVERT TOP,SIT 7211-319 REGULATOR:VALVE,NG,SIT, CONVERSION 98-56902 (LP)FUEL...
-
Page 21: Troubleshooting
OWNER’S MANUAL Model # 8890 DVI-Ht TROUBLESHOOTING Symptom Possible Cause Corrective Action 1. Pilot will not A. Insufficient gas pressure, air in A. Using the battery operated igniter, try to light the pilot. If it will not light. the pilot line, or dirty or kinked gas light, check the inlet gas pressure. - Page 22 OWNER’S MANUAL Model # 8890 DVI-Ht Symptom Possible Cause Corrective Action 7. Blue Flames A. A normal result during the first A. Flames should begin to turn more yellowish after 20 minutes of 20 minutes. burning. B. If blue color stays, adjust the air shutter for a proper burn.
-
Page 23: Safety Label
8” / 204 mm UNIT TO SIDE WALLS Several Optional kits are available through HearthStone or your local HearthStone dealer. A spark screen (kit# 98-69700) and two different remote controls (kit #90-56912 & kit #90-56914) are optional as well. This appliance is only for use with the type of gas indicated on this rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where not prohibited by local codes. -
Page 24: Hearthstone Gas-Fired Stove And Insert
All obligations of HearthStone under this document commence on the date the Original Purchaser purchases the Stove (the “Purchase Date”). LIMITED LIFETIME WARRANTY HearthStone warrants the following parts of the Stove against the following occurrences that result from defects in material and workmanship: •... -
Page 25: Limited Warranties
Dealer, as the case may be, will instruct the Original Purchaser to either return the defective part, or the entire Stove (if needed), with shipping prepaid, to HearthStone or a Dealer or allow a Dealer to make a service call at the place where the Stove is located. - Page 26 Stove to and from HearthStone or a Dealer, as the case may be. Notwithstanding any other provision of this document, in no event will HearthStone pay for any Dealer fees or other fees for pick up or delivery of the Stove returned for repair;...
