Page 1: Audio System
SYS2500E-64 6/21/99 HME# 400421 Rev - System 2500E Wireless Drive-Thru Audio System Operating Instructions... -
Page 2: Table Of Contents
Fasten clips to your clothing behind your back ............. 6 Latching feature switch inside Communicator battery compartment ....7 System 2500E Base Station Circuit Boards ............11 ® The HME logo and the word COMMUNICATOR are registered trademarks of HM Electronics, Inc. -
Page 3: General
SECTION 1. SYSTEM DESCRIPTION GENERAL The System 2500E is a wireless audio system primarily for use at drive-thru, quick-service restaurants. EQUIPMENT IDENTIFICATION A. Main Components Base station COMMUNICATOR ® (plus one spare battery) Battery charger Figure 1. Base Station Figure 2. Communicator... -
Page 4: Controls, Switches, Connectors And Lights
IN and leave IN for 5 seconds, then push again and leave OUT for normal vehicle detection. Left Side WIRED/WIRELESS button; must be OUT when using the wireless System 2500E, IN when using a wired backup system. Figure 4. Base station features... -
Page 5: Communicator Features
® COMMUNICATOR Button “A” is used to communicate with the customer. Button “B” is used to communicate with other personnel wearing Communicators. ON/POWER light indicates the Communicator is on and receiving power from the battery. On standard Com- municators, this light is red. On latching Communica- tors, this light is yellow. -
Page 6: Battery Charging
III. BATTERY CHARGING A. When to Charge the Batteries New Batteries It is recommended that new batteries be placed in the battery charger to be certain they are fully charged before they are used. Follow the instructions inside the lid of the battery charger case. Weak Batteries When a fully charged battery is placed in the COMMUNICATOR ®... -
Page 7: How To Charge The Batteries
Installation Installation of the battery is simply the opposite of its removal. Insert the battery into the battery compartment with the arrow pointing toward the opening. Hold the battery in, and slide the compartment cover into the grooves on either side of the compart- ment opening until its catch clicks Figure 7. -
Page 8: Wearing The Communicator
® WEARING THE COMMUNICATOR With the Communicator in its pouch and the strap buckled over it, locate the head- set receptacle on its top corner. Align the key and pins of the headset connector with the receptacle, and plug the connector into the receptacle as shown in Figure 9. -
Page 9: Operation
OPERATION In single or dual drive-thru operations, COMMUNICATOR button “A” is for com- ® munication with the customer, and button “B” is for communication with other crew members wearing Communicators. A. Full-Duplex Operation ACTION RESULT If you are using the Communicator latching Customer hears your voice and you hear feature: Press and release button "A”... -
Page 10: Cleaning And Caring For The Equipment
The foam muff on the headset earpiece is easily removed and replaced for sanitary purposes. To order extra foam muffs, call your local HME sales representative. B. How to Care for the Headset Cable and Connector... -
Page 11: In Case Of Problems
VII. IN CASE OF PROBLEMS In case of any problems with your System 2500E, refer to the following troublesho- oting checklist and the circuit board illustration on page 11. If you cannot correct any problems using the checklist, call HME Customer Support at 1-800-848-4468. - Page 12 If still not working, call HME. * Feedback heard in Green and white wires of second Reverse wires Communicator headset audio cable reversed. Outside speaker volume (outgoing) Turn volume control control turned too high. counterclockwise. * For assistance, call HME at 1-800-848-4468, or Fax 858-552-0172.
-
Page 13: System 2500E Base Station Circuit Boards
System 2500E Base Station Circuit Boards Figure 12. Transmitter antenna Receiver antenna Transceiver frequency settings switch - S1 Vehicle detector override switch - S7 Channel “A” light - DS4 Channel “B” light - DS5 Vehicle present light - DS6 Configuration switch - S4... -
Page 14: System 2500E Specifications
VIII. SYSTEM 2500E SPECIFICATIONS Base Station Voltage input 16VAC ±2.5V AC current input 350mA nominal, 1.4A maximum Audio distortion <5% maximum level Outside speaker output 3 watts RMS into 8 ohms Ceiling speaker power 3 watts RMS into 8 ohms... -
Page 15: Optional Equipment
OPTIONAL EQUIPMENT Equipment Model Number Battery, Spare for COMMUNICATOR BAT2000 ® Belt Extender BE20B Headset, Lightweight HS3, HS5, HS5A Headset Earmuff Headset Earmuff and Microphone Cap Lapel Microphone with Earpiece Pocket Receiver (battery operated) Portable Receiver (battery operated) Antenna (remote) ANT3000 Antenna Diversity System AD3000...
