KIB 644 C E IT English Operating Instructions Contents Operating Instructions,1 WARNING,2 Description of the appliance-Control Panel,3 Installation,3 Start-up and use,5 Precautions and tips,10 Care and maintenance,11 Technical description of the models,11 Italiano Istruzioni per l’uso PIANO COTTURA Sommario Istruzioni per l’uso,1 ATTENZIONE,12 Descrizione dell’apparecchio- Pannello di controllo,13...
WARNING! KIB 644 C E IT • WARNING: The appliance and its accessible parts become hot during use. • Care should be taken to avoid touching heating elements. • Children less than 8 years of age shall be kept away unless continuously supervised.
Installation Description of the appliance Control panel Before operating your new appliance please read this instruction booklet carefully. It contains important information concerning the safe operation, installation and maintenance of the appliance. Please keep these operating instructions for future reference. Pass them on to any new owners of the appliance.
Page 4
Installation of the safety washer CABINET DIMENSIONS Min. 30/Max.50 SAFETY DISTANCES WITH FURNITURE Min 5mm Min 20mm 30mm Min 5mm 30mm Min 20mm...
Start-up and use Fix the hob as follows: 1. Use short flat-bottomed screws to fix the 4 alignment springs in the holes provided at the central point of each side of the hob. 2. Place the hob in the cavity, make sure it is in a central Before connecting the appliance to the power supply, make position and push down on the whole perimeter until the sure that:...
Page 6
ays „FL” error and the calibration is suspended. The • Loud whistle: heard when two induction elements of error will disappear when satisfactory ambient ligh- the same group function simultaneously at maximum ting is detected and the touch control calibration pro- power and/or when the booster function is set on cedure will now complete satisfactorily the larger element while the other is auto-adjusted.
Page 7
Switching on the cooking zones 1. Select the cooking zone using the corresponding selector button. Each cooking zone is controlled using a selector button 2. Adjust the power level of the cooking zone. and a power adjustment device consisting of a 3.When required power level is selected, touching again double(-) and (+) button.
The “u” sign on the display appears if after Switching off the hob selecting the cooking zone the pan is not placed on a Press the button to switch off the appliance - do not heater , or in case of: rely solely on the pan sensor.
Power level Maximum operating time in hours Practical cooking advice ª Pressure cooking Frying Pressure cooker • Grilling Boiling • ¶ Crêpes Cooking on a high flame and browning (roasts, steaks, escalopes, fish fillets, fried eggs) ¶ § Fast thickening (liquid juices) Boiling water (pasta, rice, vegetables) Milk §...
Precautions and tips This appliance has been designed and manufactured • Never perform any cleaning or maintenance work in compliance with international safety standards. The without having disconnected the appliance from the following warnings are provided for safety reasons and electricity mains.
Do not attempt to repair the appliance yourself. If the appliance breaks down, contact a Service Centre. Technical description of the models Hobs KIB 644 C E IT Cooking zone Power (W) Back Left I 1200 - B1600 Back Right...
ATTENZIONE! • ATTENZIONE: Questo apparecchio e KIB 644 C E IT le sue parti accessibili diventano molto caldi durante l’uso. • Bisogna fare attenzione ed evitare di toccare gli elementi riscaldanti. • Tenere lontani i bambini inferiori agli 8 anni se non continuamente sorvegliati.
Installazione Descrizione dell'apparecchio Manopole del piano di cottura Prima di usare il nuovo dispositivo leggere con attenzione questo libretto di istruzioni. Contiene informazioni importanti relativamente al corretto funzionamento, alla giusta installazione e alla buona manutenzione del dispositivo. Conservi le presenti istruzioni per una futura consultazione. In caso di trasferimento dell'apparecchiatura, consegnarle ai futuri proprietari.
Page 14
Installazione della rondella di sicurezza DIMENSIONI ARMADIETTO Min. 30/Max.50 DISTANZE DI SICUREZZA DAI MOBILI Min 5mm Min 20mm 30mm Min 5mm 30mm Min 20mm...
Avvio e uso Installare il piano cottura come segue: 1. Usare delle viti a testa piatta per fi ssare le 4 molle di allineamento nei fori al centro di ogni lato del piano cottura. 2. Mettere il piano cottura nella cavità, verifi care che sia centrato, quindi premerlo verso il basso lungo tutto il perimetro, fi...
Page 16
(induzione); può essere più o meno intenso a seconda re le eventuali cappe come si fa normalmente. Questa del materiale di cui è composta la parte inferiore della operazione non infl uirà sul funzionamento del controllo pentola, e diminuisce con l'aumentare delle dimensioni touch.
Page 17
Col riscaldatore sul livello Booster, se viene toccato il pulsante [+], si sente un suono simile a un bip di errore e il livello di potenza non cambia. Col riscaldatore sul livello Booster, se viene toccato il pulsante [-], si sente un suono simile a un bip e il livello di potenza viene portato a 9.
Page 18
Fine del conto alla rovescia del timer. Inoltre, per ottenere i risultati migliori dal proprio piano cottura: Quando il tempo restante è scaduto, il riscaldatore con • Usare pentole con una base spessa e piatta per utilizzare timer viene spento, il display del riscaldatore visualizza al meglio la zona di cottura.
Page 19
Interruttore di sicurezza Livello di potenza Tempo limite di funzionamento in ore Il dispositivo ha un interruttore di sicurezza che disattiva automaticamente le zone di cottura dopo che sono state in funzione per un po' di tempo a una determinata potenza. Quando l'interruttore di sicurezza viene avviato, sul display compare “0”.
Precauzioni e consigli L’apparecchio è stato progettato e costruito • Non staccare la spina dalla presa della corrente in conformità alle norme internazionali di sicurezza. Queste tirando il cavo, bensì afferrando la spina. avvertenze sono fornite per ragioni di sicurezza e devono •...
è la zona di cottura che si riscalda: il calore viene generato direttamente all’interno della pentola, la quale dovrà possedere necessariamente un fondo in materiale ferromagnetico. Legenda: Piani cottura KIB 644 C E IT I = zona di cottura a induzione semplice B = booster: la zona di cottura può essere Zone di cottura...
